psnGPCR

Press and hold down the left mouse button and move the mouse to rotate.
Press and hold down the central mouse button and move the mouse to translate.
Use the mouse wheel to zoom in or out.
Click on any atom on your molecule and the corresponding residue label will be placed beneath the viewer.

Color	ConSurf Grade
	No Conservation data available
	1
	2
	3
	4
	5
	6
	7
	8
	9

Index: link id, click on each number to highlight the corresponding link in the 3D visualization.

Node1 Node2: the two nodes of the corresponding link.

Int. Strength: the interaction strength between the two nodes.

Hub1?, Hub2?: "Yes" if the corresponding node has more than 3 links, otherwise "No".

Community: the id of the community the link belong to, otherwise 0.

ConSurf1, ConSurf2: these columns report the ConSurf conservation grades of the two nodes involved in a link.

Index	Node1	Node2	Int. Strength	Hub1?	Hub2?	Community	ConSurf1	ConSurf2
1	A:A:I19	A:A:R15	2.51	No	No	0	9	5
2	A:A:R15	B:B:H91	2.26	No	Yes	0	5	5
3	A:A:S16	B:B:N88	4.47	No	No	0	7	7
4	A:A:S16	B:B:K89	6.12	No	Yes	0	7	9
5	A:A:I19	B:B:K89	7.27	No	Yes	0	9	9
6	A:A:R21	A:A:R24	6.4	No	No	0	4	3
7	A:A:L23	B:B:L55	2.77	No	No	0	6	6
8	A:A:L23	B:B:I80	2.85	No	Yes	0	6	8
9	A:A:D26	B:B:K78	8.3	No	No	0	5	8
10	A:A:E28	R:R:T149	4.23	No	No	0	4	8
11	A:A:E33	A:A:K197	10.8	No	Yes	0	6	6
12	A:A:F196	A:A:V34	6.55	Yes	No	9	7	5
13	A:A:T219	A:A:V34	6.35	No	No	0	7	5
14	A:A:V339	A:A:V34	3.21	No	No	9	8	5
15	A:A:F199	A:A:K35	6.2	Yes	No	0	5	9
16	A:A:F196	A:A:L36	4.87	Yes	No	0	7	7
17	A:A:I222	A:A:L36	4.28	Yes	No	0	7	7
18	A:A:L37	A:A:L39	6.92	No	Yes	1	9	9
19	A:A:F215	A:A:L37	9.74	Yes	No	1	9	9
20	A:A:I221	A:A:L37	2.85	Yes	No	1	8	9
21	A:A:K46	A:A:L38	5.64	Yes	Yes	8	9	8
22	A:A:L38	A:A:M198	5.65	Yes	No	0	8	7
23	A:A:D200	A:A:L38	6.79	No	Yes	8	9	8
24	A:A:I222	A:A:L38	2.85	Yes	Yes	8	7	8
25	A:A:I221	A:A:L39	2.85	Yes	Yes	1	8	9
26	A:A:F223	A:A:L39	2.44	Yes	Yes	1	9	9
27	A:A:I253	A:A:L39	4.28	Yes	Yes	1	8	9
28	A:A:G40	A:A:K46	5.23	No	Yes	0	9	9
29	A:A:A41	A:A:S44	3.42	No	No	0	7	9
30	A:A:E43	A:A:R242	2.33	No	Yes	0	9	9
31	A:A:A226	A:A:S44	3.42	No	No	0	8	9
32	A:A:G45	A:A:T48	3.64	No	No	0	9	9
33	A:A:D200	A:A:K46	8.3	No	Yes	8	9	9
34	A:A:C224	A:A:K46	3.23	No	Yes	0	7	9
35	A:A:I49	A:A:M53	4.37	No	Yes	0	7	8
36	A:A:C224	A:A:I49	3.27	No	No	0	7	7
37	A:A:I49	A:A:N269	8.5	No	Yes	0	7	9
38	A:A:T187	A:A:V50	4.76	No	No	0	6	6
39	A:A:M53	A:A:Q52	6.8	Yes	No	0	8	9
40	A:A:N331	A:A:Q52	11.88	Yes	No	0	8	9
41	A:A:F189	A:A:M53	11.2	Yes	Yes	0	9	8
42	A:A:M53	A:A:V332	3.04	Yes	No	0	8	7
43	A:A:I55	A:A:K54	2.91	No	No	0	8	7
44	A:A:T182	B:B:N119	4.39	No	No	0	7	9
45	A:A:F199	A:A:I184	2.51	Yes	Yes	1	5	9
46	A:A:I184	A:A:V201	4.61	Yes	No	1	9	9
47	A:A:I184	B:B:W99	4.7	Yes	Yes	1	9	9
48	A:A:I184	B:B:L117	7.14	Yes	Yes	1	9	9
49	A:A:E186	A:A:K197	2.7	No	Yes	1	9	6
50	A:A:E186	A:A:F199	7	No	Yes	1	9	5
51	A:A:E186	B:B:W99	2.18	No	Yes	1	9	9
52	A:A:F189	A:A:T187	7.78	Yes	No	0	9	6
53	A:A:H188	A:A:K197	10.48	No	Yes	0	3	6
54	A:A:F189	A:A:F196	2.14	Yes	Yes	0	9	7
55	A:A:F189	A:A:M198	3.73	Yes	No	0	9	7
56	A:A:H195	A:A:T190	6.85	No	No	0	4	3
57	A:A:F191	A:A:K192	13.65	Yes	No	9	5	4
58	A:A:F191	A:A:V332	9.18	Yes	No	0	5	7
59	A:A:F191	A:A:Q333	3.51	Yes	No	9	5	5
60	A:A:F191	A:A:F336	3.22	Yes	Yes	9	5	8
61	A:A:K192	A:A:Q333	5.42	No	No	9	4	5
62	A:A:F336	A:A:K192	2.48	Yes	No	9	8	4
63	A:A:F196	A:A:L194	9.74	Yes	No	9	7	4
64	A:A:F336	A:A:L194	3.65	Yes	No	9	8	4
65	A:A:L194	R:R:V145	4.47	No	No	0	4	6
66	A:A:F196	A:A:F336	2.14	Yes	Yes	9	7	8
67	A:A:F196	A:A:V339	9.18	Yes	No	9	7	8
68	A:A:F199	A:A:K197	3.72	Yes	Yes	1	5	6
69	A:A:F199	B:B:W99	13.03	Yes	Yes	1	5	9
70	A:A:V201	A:A:W211	6.13	No	Yes	1	9	9
71	A:A:F215	A:A:V201	3.93	Yes	No	1	9	9
72	A:A:Q204	A:A:S206	5.78	No	No	1	9	8
73	A:A:Q204	A:A:W211	4.38	No	Yes	1	9	9
74	A:A:R205	A:A:R208	2.13	No	Yes	0	9	9
75	A:A:S206	A:A:W211	4.94	No	Yes	1	8	9
76	A:A:S206	B:B:Y145	5.09	No	Yes	1	8	8
77	A:A:E207	A:A:K209	4.05	Yes	No	0	9	8
78	A:A:E207	A:A:K210	4.05	Yes	No	0	9	9
79	A:A:E207	B:B:C204	4.56	Yes	Yes	1	9	7
80	A:A:E207	B:B:D228	3.9	Yes	No	1	9	9
81	A:A:R208	A:A:W211	8	Yes	Yes	0	9	9
82	A:A:I212	A:A:R208	5.01	Yes	Yes	0	8	9
83	A:A:L249	A:A:R208	4.86	No	Yes	0	9	9
84	A:A:K210	B:B:M188	5.76	No	Yes	0	9	8
85	A:A:K210	B:B:N230	4.2	No	No	0	9	9
86	A:A:F215	A:A:W211	4.01	Yes	Yes	1	9	9
87	A:A:W211	B:B:L117	2.28	Yes	Yes	1	9	9
88	A:A:I212	A:A:N256	4.25	Yes	Yes	1	8	8
89	A:A:I212	A:A:W258	2.35	Yes	Yes	1	8	5
90	A:A:F259	A:A:I212	5.02	Yes	Yes	1	9	8
91	A:A:H213	A:A:W258	10.58	No	Yes	1	8	5
92	A:A:H213	B:B:Y59	2.18	No	Yes	1	8	8
93	A:A:H213	B:B:W332	5.29	No	Yes	1	8	9
94	A:A:C214	B:B:Y59	6.72	No	Yes	1	7	8
95	A:A:C214	B:B:Q75	3.05	No	No	1	7	9
96	A:A:C214	B:B:W99	2.61	No	Yes	1	7	9
97	A:A:F215	A:A:V218	2.62	Yes	No	1	9	9
98	A:A:F215	A:A:F259	2.14	Yes	Yes	1	9	9
99	A:A:F215	B:B:W99	7.02	Yes	Yes	1	9	9
100	A:A:F215	B:B:L117	2.44	Yes	Yes	1	9	9
101	A:A:E216	A:A:W258	3.27	No	Yes	0	7	5
102	A:A:F259	A:A:V218	2.62	Yes	No	1	9	9
103	A:A:T262	A:A:V218	3.17	No	No	1	7	9
104	A:A:I221	A:A:I253	2.94	Yes	Yes	1	8	8
105	A:A:F259	A:A:I221	8.79	Yes	Yes	1	9	8
106	A:A:I221	A:A:T262	4.56	Yes	No	1	8	7
107	A:A:I222	A:A:I265	2.94	Yes	Yes	8	7	8
108	A:A:F267	A:A:I222	2.51	Yes	Yes	8	9	7
109	A:A:F223	A:A:V225	2.62	Yes	No	1	9	7
110	A:A:F223	A:A:L249	6.09	Yes	No	1	9	9
111	A:A:F223	A:A:F250	15	Yes	Yes	0	9	9
112	A:A:F223	A:A:I253	2.51	Yes	Yes	1	9	8
113	A:A:F223	A:A:L266	3.65	Yes	No	0	9	9
114	A:A:L268	A:A:V225	2.98	Yes	No	1	8	7
115	A:A:F307	A:A:V225	2.62	Yes	No	1	8	7
116	A:A:A226	A:A:D229	4.63	No	No	0	8	8
117	A:A:L227	A:A:L268	8.3	No	Yes	0	7	8
118	A:A:F274	A:A:L227	7.31	Yes	No	0	9	7
119	A:A:K270	A:A:S228	3.06	No	No	16	9	9
120	A:A:L273	A:A:S228	6.01	No	No	16	6	9
121	A:A:D229	A:A:R242	8.34	No	Yes	0	8	9
122	A:A:M243	A:A:Y230	2.39	Yes	Yes	1	8	8
123	A:A:F274	A:A:Y230	7.22	Yes	Yes	1	9	8
124	A:A:K277	A:A:Y230	4.78	No	Yes	0	9	8
125	A:A:L283	A:A:Y230	2.34	No	Yes	1	7	8
126	A:A:C286	A:A:Y230	5.38	Yes	Yes	1	6	8
127	A:A:D231	A:A:K277	4.15	No	No	0	9	9
128	A:A:L232	A:A:L234	2.77	No	No	15	8	8
129	A:A:L232	A:A:R242	13.36	No	Yes	15	8	9
130	A:A:N241	A:A:V233	7.39	No	No	0	9	5
131	A:A:L234	A:A:R242	7.29	No	Yes	15	8	9
132	A:A:C286	A:A:M243	3.24	Yes	Yes	1	6	8
133	A:A:M243	A:A:Y287	2.39	Yes	Yes	1	8	7
134	A:A:F307	A:A:M243	3.73	Yes	Yes	1	8	8
135	A:A:M247	A:A:Q306	6.8	No	No	0	6	5
136	A:A:I253	A:A:L249	7.14	Yes	No	1	8	9
137	A:A:F250	A:A:I264	5.02	Yes	No	0	9	6
138	A:A:F250	A:A:L310	3.65	Yes	No	0	9	4
139	A:A:F250	A:A:I319	3.77	Yes	No	0	9	5
140	A:A:D251	A:A:N255	9.42	No	No	18	5	8
141	A:A:D251	A:A:L310	2.71	No	No	0	5	4
142	A:A:D251	A:A:K312	2.77	No	No	18	5	5
143	A:A:C254	A:A:I264	3.27	No	No	17	5	6
144	A:A:C254	A:A:K317	6.47	No	No	17	5	7
145	A:A:K312	A:A:N255	8.39	No	No	18	5	8
146	A:A:K257	A:A:N256	2.8	No	Yes	1	4	8
147	A:A:N256	A:A:W258	12.43	Yes	Yes	1	8	5
148	A:A:F259	A:A:N256	6.04	Yes	Yes	1	9	8
149	A:A:K257	A:A:W258	10.44	No	Yes	1	4	5
150	A:A:F259	A:A:T262	10.38	Yes	No	1	9	7
151	A:A:R313	A:A:T260	6.47	No	No	0	4	3
152	A:A:D261	A:A:T316	4.34	No	No	0	4	3
153	A:A:D261	A:A:N346	5.39	No	No	0	4	4
154	A:A:S263	A:A:Y320	2.54	No	Yes	0	7	7
155	A:A:S263	A:A:V342	4.85	No	No	0	7	7
156	A:A:I264	A:A:K317	2.91	No	No	17	6	7
157	A:A:F267	A:A:I265	3.77	Yes	Yes	8	9	8
158	A:A:I265	A:A:Y320	2.42	Yes	Yes	8	8	7
159	A:A:F334	A:A:I265	2.51	Yes	Yes	8	3	8
160	A:A:A338	A:A:I265	3.25	No	Yes	8	6	8
161	A:A:F307	A:A:L266	3.65	Yes	No	0	8	9
162	A:A:L266	A:A:T321	7.37	No	No	0	9	5
163	A:A:F267	A:A:H322	5.66	Yes	No	8	9	9
164	A:A:F267	A:A:T324	6.49	Yes	No	8	9	9
165	A:A:F267	A:A:N331	4.83	Yes	Yes	8	9	8
166	A:A:F267	A:A:F334	2.14	Yes	Yes	8	9	3
167	A:A:F267	A:A:V335	2.62	Yes	No	0	9	8
168	A:A:F307	A:A:L268	2.44	Yes	Yes	1	8	8
169	A:A:F323	A:A:L268	4.87	Yes	Yes	0	4	8
170	A:A:K270	A:A:N269	2.8	No	Yes	0	9	9
171	A:A:N269	A:A:T324	8.77	Yes	No	0	9	9
172	A:A:K270	A:A:L273	11.28	No	No	16	9	6
173	A:A:K271	A:A:Y296	4.78	No	Yes	0	5	4
174	A:A:F323	A:A:K271	7.44	Yes	No	0	4	5
175	A:A:C325	A:A:K271	3.23	No	No	0	7	5
176	A:A:D272	A:A:E276	9.09	No	No	0	9	5
177	A:A:F274	A:A:I278	10.05	Yes	No	1	9	6
178	A:A:F274	A:A:Y296	4.13	Yes	Yes	1	9	4
179	A:A:A299	A:A:F274	2.77	No	Yes	0	7	9
180	A:A:E275	A:A:K279	16.2	No	No	0	5	2
181	A:A:E275	A:A:Y296	2.24	No	Yes	0	5	4
182	A:A:I278	A:A:Y296	3.63	No	Yes	1	6	4
183	A:A:P282	A:A:S281	3.56	No	No	0	5	7
184	A:A:P282	A:A:T284	3.5	No	No	0	5	4
185	A:A:L283	A:A:Y287	3.52	No	Yes	1	7	7
186	A:A:L283	A:A:Y290	2.34	No	Yes	1	7	7
187	A:A:C286	A:A:Y287	6.72	Yes	Yes	1	6	7
188	A:A:Y287	A:A:Y290	1.99	Yes	Yes	1	7	7
189	A:A:Y287	A:A:Y302	3.97	Yes	No	1	7	6
190	A:A:I303	A:A:Y287	4.84	No	Yes	0	7	7
191	A:A:Q306	A:A:Y287	13.53	No	Yes	1	5	7
192	A:A:G292	A:A:Y290	4.35	No	Yes	0	7	7
193	A:A:E298	A:A:Y290	10.1	No	Yes	1	4	7
194	A:A:Y290	A:A:Y302	34.75	Yes	No	1	7	6
195	A:A:S293	A:A:T295	7.99	No	No	1	3	5
196	A:A:E298	A:A:S293	5.75	No	No	1	4	3
197	A:A:E298	A:A:T295	4.23	No	No	1	4	5
198	A:A:E297	A:A:Y296	5.61	No	Yes	0	4	4
199	A:A:A300	A:A:F323	2.77	No	Yes	0	5	4
200	A:A:Q306	A:A:Y302	3.38	No	No	1	5	6
201	A:A:F307	A:A:I303	7.54	Yes	No	0	8	7
202	A:A:E308	A:A:Q304	3.82	No	No	19	3	5
203	A:A:Q304	A:A:T321	7.09	No	No	19	5	5
204	A:A:F323	A:A:Q304	2.34	Yes	No	0	4	5
205	A:A:E308	A:A:I319	2.73	No	No	0	3	5
206	A:A:E308	A:A:T321	4.23	No	No	19	3	5
207	A:A:K314	A:A:N311	8.39	No	No	0	3	8
208	A:A:I319	A:A:N311	5.66	No	No	0	5	8
209	A:A:K317	A:A:R313	4.95	No	No	0	7	4
210	A:A:D315	R:R:M335	11.09	No	No	20	3	4
211	A:A:D315	R:R:R339	4.76	No	No	20	3	7
212	A:A:E318	A:A:K345	2.7	No	No	0	4	5
213	A:A:F334	A:A:Y320	2.06	Yes	Yes	8	3	7
214	A:A:A338	A:A:Y320	2.67	No	Yes	8	6	7
215	A:A:D341	A:A:Y320	2.3	No	Yes	0	8	7
216	A:A:K345	A:A:Y320	4.78	No	Yes	0	5	7
217	A:A:H322	A:A:N331	2.55	No	Yes	8	9	8
218	A:A:F334	A:A:H322	20.36	Yes	No	8	3	9
219	A:A:N331	A:A:T324	7.31	Yes	No	8	8	9
220	A:A:K330	A:A:T327	7.51	No	No	0	4	8
221	A:A:D328	A:A:T329	5.78	No	No	0	9	9
222	A:A:D337	A:A:Q333	7.83	No	No	0	4	5
223	A:A:F336	A:A:T340	7.78	Yes	No	0	8	6
224	A:A:I343	A:A:V339	3.07	No	No	9	7	8
225	A:A:T340	R:R:P141	3.5	No	No	0	6	8
226	A:A:D341	R:R:R225	9.53	No	No	0	8	7
227	A:A:N346	A:A:V342	4.43	No	No	0	4	7
228	A:A:I343	A:A:N347	4.25	No	No	9	7	8
229	A:A:I343	R:R:Y144	2.42	No	No	9	7	8
230	A:A:I344	A:A:L348	2.85	No	Yes	0	6	9
231	A:A:I344	R:R:P141	8.47	No	No	0	6	8
232	A:A:I344	R:R:R225	6.26	No	No	0	6	7
233	A:A:F354	A:A:K345	4.96	Yes	No	0	5	5
234	A:A:N347	R:R:Y144	22.1	No	No	9	8	8
235	A:A:L348	A:A:L353	4.15	Yes	Yes	0	9	7
236	A:A:F354	A:A:L348	2.44	Yes	Yes	0	5	9
237	A:A:L348	R:R:I138	8.56	Yes	No	0	9	9
238	A:A:F354	A:A:K349	8.69	Yes	No	0	5	5
239	A:A:C351	A:A:L353	6.35	No	Yes	0	4	7
240	A:A:C351	R:R:R134	6.96	No	No	0	4	9
241	A:A:L353	R:R:T343	5.9	Yes	No	0	7	8
242	A:A:L353	R:R:T346	2.95	Yes	No	0	7	8
243	A:A:L353	R:R:L347	4.15	Yes	No	0	7	8
244	A:A:F354	R:R:I226	3.77	Yes	No	0	5	6
245	A:A:F354	R:R:R339	22.45	Yes	No	0	5	7
246	G:G:E22	G:G:Q18	10.19	No	No	0	9	9
247	B:B:C218	G:G:E22	6.08	No	No	0	5	9
248	G:G:I25	G:G:R27	5.01	No	Yes	0	2	8
249	B:B:Q220	G:G:I25	4.12	No	No	0	7	2
250	B:B:A21	G:G:R27	2.77	No	Yes	0	4	8
251	B:B:R22	G:G:R27	2.13	Yes	Yes	5	6	8
252	B:B:D258	G:G:R27	10.72	Yes	Yes	5	7	8
253	B:B:R256	G:G:I28	15.03	No	No	0	9	4
254	G:G:K29	G:G:S31	4.59	No	No	21	4	9
255	B:B:D27	G:G:K29	11.06	No	No	21	8	4
256	B:B:D27	G:G:S31	4.42	No	No	21	8	9
257	G:G:D36	G:G:K32	12.44	No	No	0	5	5
258	B:B:D254	G:G:A33	3.09	Yes	No	0	9	7
259	B:B:L30	G:G:A34	4.73	Yes	No	0	5	6
260	B:B:F235	G:G:L37	4.87	Yes	No	0	6	7
261	B:B:I33	G:G:M38	4.37	No	Yes	0	3	4
262	B:B:T34	G:G:M38	3.01	Yes	Yes	11	5	4
263	B:B:I37	G:G:M38	5.83	No	Yes	0	2	4
264	B:B:L300	G:G:M38	2.83	Yes	Yes	11	6	4
265	G:G:H44	G:G:Y40	6.53	No	Yes	0	6	6
266	B:B:F235	G:G:Y40	4.13	Yes	Yes	6	6	6
267	B:B:P236	G:G:Y40	4.17	Yes	Yes	6	7	6
268	B:B:N237	G:G:Y40	10.47	No	Yes	6	5	6
269	B:B:R283	G:G:C41	4.18	Yes	No	0	9	7
270	G:G:A43	G:G:H44	2.93	No	No	0	4	6
271	G:G:E47	G:G:K46	8.1	No	No	0	3	1
272	G:G:D48	G:G:L51	2.71	Yes	No	0	9	6
273	B:B:S279	G:G:D48	2.94	No	Yes	0	9	9
274	B:B:K280	G:G:D48	2.77	No	Yes	0	1	9
275	B:B:S281	G:G:D48	10.31	No	Yes	0	9	9
276	B:B:G324	G:G:P49	2.03	No	No	0	9	7
277	B:B:V320	G:G:L50	2.98	No	No	0	7	9
278	B:B:R283	G:G:L51	2.43	Yes	No	0	9	6
279	G:G:P55	G:G:V54	3.53	No	Yes	3	5	6
280	G:G:E58	G:G:V54	4.28	No	Yes	3	5	6
281	G:G:N59	G:G:V54	7.39	Yes	Yes	3	9	6
282	B:B:N340	G:G:V54	4.43	Yes	Yes	3	9	6
283	G:G:E58	G:G:P55	9.43	No	No	3	5	5
284	G:G:A56	G:G:R62	2.77	No	No	0	4	7
285	G:G:N59	G:G:P60	6.52	Yes	No	3	9	9
286	G:G:F61	G:G:N59	6.04	Yes	Yes	3	8	9
287	B:B:M325	G:G:N59	2.8	Yes	Yes	3	5	9
288	B:B:N340	G:G:N59	6.81	Yes	Yes	3	9	9
289	B:B:Y85	G:G:P60	4.17	No	No	3	4	9
290	B:B:M325	G:G:P60	10.06	Yes	No	3	5	9
291	B:B:R49	G:G:F61	8.55	No	Yes	0	7	8
292	B:B:S84	G:G:F61	7.93	No	Yes	0	5	8
293	B:B:M325	G:G:F61	3.73	Yes	Yes	3	5	8
294	B:B:A326	G:G:F61	4.16	No	Yes	3	7	8
295	B:B:I338	G:G:F61	5.02	No	Yes	0	5	8
296	B:B:N340	G:G:F61	3.62	Yes	Yes	3	9	8
297	R:R:Q36	R:R:Y35	2.25	No	No	0	4	4
298	R:R:L41	R:R:V37	2.98	No	No	0	4	5
299	R:R:A94	R:R:L43	4.73	No	Yes	7	7	7
300	R:R:L43	R:R:W387	10.25	Yes	Yes	7	7	8
301	R:R:L46	R:R:S391	6.01	No	No	0	7	5
302	R:R:L394	R:R:L46	2.77	No	No	0	7	7
303	R:R:I47	R:R:L90	4.28	No	Yes	0	7	8
304	R:R:F48	R:R:L52	13.4	No	No	0	4	4
305	R:R:A50	R:R:S86	3.42	No	Yes	0	8	8
306	R:R:A50	R:R:L394	3.15	No	No	0	8	7
307	R:R:L83	R:R:V51	2.98	No	No	0	8	7
308	R:R:S86	R:R:V51	3.23	Yes	No	0	8	7
309	R:R:G53	R:R:Y402	2.9	No	Yes	0	9	6
310	R:R:D82	R:R:N54	6.73	Yes	Yes	2	9	9
311	R:R:L83	R:R:N54	6.87	No	Yes	0	8	9
312	R:R:N54	R:R:S86	2.98	Yes	Yes	0	9	8
313	R:R:N54	R:R:P397	4.89	Yes	No	2	9	9
314	R:R:C56	R:R:Y402	2.69	No	Yes	2	8	6
315	R:R:C56	R:R:F411	2.79	No	Yes	2	8	8
316	R:R:I61	R:R:V57	3.07	No	Yes	0	8	9
317	R:R:A79	R:R:V57	3.39	No	Yes	0	9	9
318	R:R:A401	R:R:V57	3.39	No	Yes	2	8	9
319	R:R:V57	R:R:Y402	5.05	Yes	Yes	2	9	6
320	R:R:F407	R:R:V57	6.55	Yes	Yes	2	8	9
321	R:R:A60	R:R:F407	2.77	No	Yes	2	8	8
322	R:R:A60	R:R:F411	4.16	No	Yes	2	8	8
323	R:R:A410	R:R:E64	4.53	No	No	0	8	7
324	R:R:E64	R:R:K413	8.1	No	No	0	7	6
325	R:R:E64	R:R:I414	12.3	No	No	0	7	7
326	R:R:Q68	R:R:R65	3.5	No	No	0	8	7
327	B:B:F335	R:R:R65	3.21	Yes	No	0	4	7
328	R:R:L67	R:R:S66	3	Yes	No	0	8	6
329	R:R:L67	R:R:N72	4.12	Yes	No	0	8	9
330	R:R:F407	R:R:L67	2.44	Yes	Yes	0	8	8
331	R:R:A410	R:R:L67	4.73	No	Yes	0	8	8
332	R:R:Q68	R:R:Y73	6.76	No	No	0	8	6
333	R:R:N69	R:R:N72	6.81	No	No	0	8	9
334	R:R:R148	R:R:V70	14.38	No	No	0	8	7
335	R:R:P150	R:R:Y73	4.17	No	No	0	5	6
336	R:R:I130	R:R:L74	4.28	Yes	Yes	0	9	8
337	R:R:D133	R:R:L74	5.43	No	Yes	0	9	8
338	R:R:A153	R:R:L74	3.15	No	Yes	0	7	8
339	R:R:L156	R:R:L74	4.15	No	Yes	0	6	8
340	R:R:H126	R:R:S77	9.76	Yes	No	2	8	9
341	R:R:I157	R:R:S77	9.29	Yes	No	2	8	9
342	R:R:D82	R:R:L78	2.71	Yes	Yes	2	9	9
343	R:R:L78	R:R:S123	3	Yes	No	2	9	9
344	R:R:H126	R:R:L78	2.57	Yes	Yes	2	8	9
345	R:R:L127	R:R:L78	6.92	Yes	Yes	0	8	9
346	R:R:I130	R:R:L78	2.85	Yes	Yes	0	9	9
347	R:R:S122	R:R:T81	6.4	No	No	2	8	9
348	R:R:H126	R:R:T81	6.85	Yes	No	2	8	9
349	R:R:D82	R:R:S123	2.94	Yes	No	2	9	9
350	R:R:D82	R:R:N396	2.69	Yes	No	0	9	9
351	R:R:D82	R:R:P397	4.83	Yes	No	2	9	9
352	R:R:L83	R:R:V87	2.98	No	No	0	8	6
353	R:R:C119	R:R:M84	3.24	No	No	0	7	7
354	R:R:M84	R:R:W161	2.33	No	Yes	0	7	9
355	R:R:L90	R:R:V85	2.98	Yes	No	0	8	8
356	R:R:C119	R:R:V85	3.42	No	No	0	7	8
357	R:R:S393	R:R:V85	3.23	No	No	0	9	8
358	R:R:L90	R:R:S86	3	Yes	Yes	0	8	8
359	R:R:L88	R:R:V87	2.98	No	No	0	6	6
360	R:R:L115	R:R:L88	4.15	No	No	0	5	6
361	R:R:F112	R:R:V89	3.93	Yes	No	0	6	8
362	R:R:L115	R:R:V89	4.47	No	No	0	5	8
363	R:R:D116	R:R:V89	7.3	No	No	0	8	8
364	R:R:L90	R:R:Y390	4.69	Yes	Yes	0	8	8
365	R:R:M92	R:R:W102	2.33	No	Yes	7	6	9
366	R:R:F112	R:R:M92	9.95	Yes	No	7	6	6
367	R:R:A93	R:R:F112	2.77	No	Yes	7	7	6
368	R:R:A93	R:R:W387	2.59	No	Yes	7	7	8
369	R:R:A93	R:R:Y390	2.67	No	Yes	7	7	8
370	R:R:A94	R:R:W387	2.59	No	Yes	7	7	8
371	R:R:L95	R:R:L99	6.92	No	No	7	6	5
372	R:R:W102	R:R:Y96	3.86	Yes	No	0	9	6
373	R:R:Q97	R:R:W387	6.57	No	Yes	0	7	8
374	R:R:K101	R:R:T103	4.5	No	No	0	5	5
375	R:R:D185	R:R:K101	9.68	No	No	0	4	5
376	R:R:L104	R:R:W102	6.83	No	Yes	7	7	9
377	R:R:T108	R:R:W102	3.64	No	Yes	7	6	9
378	R:R:C109	R:R:W102	6.53	No	Yes	7	9	9
379	R:R:F112	R:R:W102	5.01	Yes	Yes	7	6	9
380	R:R:C187	R:R:W102	7.84	No	Yes	7	9	9
381	R:R:L104	R:R:T108	7.37	No	No	7	7	6
382	R:R:C109	R:R:I113	3.27	No	No	7	9	7
383	R:R:C109	R:R:C187	7.28	No	No	7	9	9
384	R:R:D110	R:R:M172	6.93	No	No	0	7	6
385	R:R:C187	R:R:I113	3.27	No	No	7	9	7
386	R:R:I113	R:R:I189	4.42	No	No	0	7	6
387	R:R:C119	R:R:L115	3.17	No	No	0	7	5
388	R:R:C120	R:R:D116	4.67	No	No	0	7	8
389	R:R:D116	R:R:Y390	12.64	No	Yes	0	8	8
390	R:R:L118	R:R:W161	3.42	No	Yes	0	6	9
391	R:R:F165	R:R:L118	9.74	No	No	0	5	6
392	R:R:L118	R:R:S168	4.5	No	No	0	6	8
393	R:R:C120	R:R:W358	5.22	No	Yes	0	7	8
394	R:R:T121	R:R:W125	2.43	Yes	Yes	0	8	7
395	R:R:G164	R:R:T121	3.64	No	Yes	0	8	8
396	R:R:I167	R:R:T121	7.6	No	Yes	0	8	8
397	R:R:H126	R:R:S122	8.37	Yes	No	2	8	8
398	R:R:S122	R:R:W161	13.59	No	Yes	2	8	9
399	R:R:I124	R:R:P207	3.39	Yes	Yes	2	8	9
400	R:R:F354	R:R:I124	3.77	Yes	Yes	2	9	8
401	R:R:I124	R:R:W358	7.05	Yes	Yes	2	8	8
402	R:R:F362	R:R:I124	2.51	Yes	Yes	2	7	8
403	R:R:C128	R:R:W125	3.92	No	Yes	2	7	7
404	R:R:T160	R:R:W125	2.43	Yes	Yes	2	8	7
405	R:R:I163	R:R:W125	7.05	No	Yes	0	5	7
406	R:R:P207	R:R:W125	6.76	Yes	Yes	2	9	7
407	R:R:H126	R:R:I157	6.63	Yes	Yes	2	8	8
408	R:R:H126	R:R:T160	10.95	Yes	Yes	2	8	8
409	R:R:H126	R:R:W161	5.29	Yes	Yes	2	8	9
410	R:R:F354	R:R:L127	2.44	Yes	Yes	0	9	8
411	R:R:L127	R:R:N396	8.24	Yes	No	0	8	9
412	R:R:L127	R:R:Y400	5.86	Yes	Yes	0	8	9
413	R:R:C128	R:R:P207	3.77	No	Yes	2	7	9
414	R:R:C128	R:R:L210	4.76	No	No	0	7	7
415	R:R:I130	R:R:R134	3.76	Yes	No	0	9	9
416	R:R:I130	R:R:Y400	6.04	Yes	Yes	0	9	9
417	R:R:A131	R:R:M211	3.22	No	No	2	9	9
418	R:R:A131	R:R:Y215	4	No	Yes	2	9	9
419	R:R:L132	R:R:W136	15.94	No	No	0	6	5
420	R:R:L132	R:R:L214	4.15	No	No	0	6	7
421	R:R:D133	R:R:R148	9.53	No	No	0	9	8
422	R:R:W136	R:R:Y135	3.86	No	Yes	0	5	9
423	R:R:T139	R:R:Y135	16.23	No	Yes	0	8	9
424	R:R:L214	R:R:Y135	5.86	No	Yes	0	7	9
425	R:R:R217	R:R:Y135	13.38	No	Yes	0	7	9
426	R:R:I218	R:R:Y135	3.63	No	Yes	0	9	9
427	R:R:R152	R:R:W136	6	No	No	0	7	5
428	R:R:I138	R:R:I218	4.42	No	No	0	9	9
429	R:R:D140	R:R:P141	3.22	No	No	0	7	8
430	R:R:D140	R:R:D143	9.31	No	No	0	7	6
431	R:R:I142	R:R:N146	4.25	No	No	0	6	5
432	R:R:D143	R:R:K147	8.3	No	No	0	6	5
433	R:R:R148	R:R:Y144	5.14	No	No	0	8	8
434	R:R:I157	R:R:T160	3.04	Yes	Yes	2	8	8
435	R:R:I157	R:R:W161	2.35	Yes	Yes	2	8	9
436	R:R:T160	R:R:W161	2.43	Yes	Yes	2	8	9
437	R:R:F165	R:R:I169	6.28	No	No	0	5	6
438	R:R:L166	R:R:Y198	2.34	No	No	0	5	5
439	R:R:I167	R:R:Y198	6.04	No	No	0	8	5
440	R:R:I169	R:R:P170	3.39	No	No	0	6	8
441	R:R:I169	R:R:L173	2.85	No	No	0	6	6
442	R:R:P170	R:R:P171	5.84	No	No	0	8	7
443	R:R:P171	R:R:Y195	12.52	No	No	0	7	8
444	R:R:G174	R:R:L173	3.42	No	No	0	5	6
445	R:R:S190	R:R:W175	11.12	No	No	0	6	6
446	R:R:K191	R:R:T188	3	No	No	0	5	5
447	R:R:K191	R:R:P369	3.35	No	Yes	0	5	7
448	R:R:D192	R:R:G194	3.35	No	No	0	6	5
449	R:R:D192	R:R:Y195	3.45	No	No	0	6	8
450	R:R:F370	R:R:H193	10.18	No	No	0	5	4
451	R:R:E372	R:R:H193	2.46	No	No	0	3	4
452	R:R:P369	R:R:T196	6.99	Yes	No	0	7	7
453	R:R:F201	R:R:I197	5.02	No	No	0	5	7
454	R:R:F201	R:R:T200	3.89	No	No	2	5	7
455	R:R:T200	R:R:Y205	4.99	No	Yes	2	7	7
456	R:R:L366	R:R:T200	5.9	No	No	2	7	7
457	R:R:F201	R:R:Y205	10.32	No	Yes	2	5	7
458	R:R:F204	R:R:Y205	5.16	Yes	Yes	2	8	7
459	R:R:F204	R:R:L208	3.65	Yes	No	0	8	7
460	R:R:F204	R:R:F354	6.43	Yes	Yes	2	8	9
461	R:R:F204	R:R:W358	3.01	Yes	Yes	2	8	8
462	R:R:F204	R:R:L359	8.53	Yes	Yes	0	8	7
463	R:R:F204	R:R:F362	24.65	Yes	Yes	2	8	7
464	R:R:L366	R:R:Y205	5.86	No	Yes	2	7	7
465	R:R:I206	R:R:P207	3.39	No	Yes	0	6	9
466	R:R:L208	R:R:L212	4.15	No	No	0	7	6
467	R:R:I355	R:R:L208	2.85	No	No	0	7	7
468	R:R:L210	R:R:L214	5.54	No	No	0	7	7
469	R:R:M211	R:R:Y215	4.79	No	Yes	2	9	9
470	R:R:F354	R:R:M211	8.71	Yes	No	2	9	9
471	R:R:L212	R:R:M351	2.83	No	No	0	6	8
472	R:R:R217	R:R:V213	5.23	No	No	0	7	5
473	R:R:L347	R:R:Y215	4.69	No	Yes	0	8	9
474	R:R:I350	R:R:Y215	8.46	No	Yes	2	8	9
475	R:R:M351	R:R:Y215	4.79	No	Yes	0	8	9
476	R:R:Y215	R:R:Y400	1.99	Yes	Yes	2	9	9
477	R:R:E340	R:R:F219	2.33	Yes	No	0	8	6
478	R:R:R220	R:R:R223	6.4	No	No	0	5	7
479	R:R:R223	R:R:R227	10.66	No	No	0	7	6
480	R:R:E340	R:R:R223	6.98	Yes	No	0	8	7
481	R:R:A329	R:R:R333	4.15	No	No	0	5	4
482	R:R:E330	R:R:R333	5.82	No	No	0	4	4
483	R:R:M335	R:R:R339	11.17	No	No	20	4	7
484	R:R:I349	R:R:K345	4.36	No	No	0	7	7
485	R:R:I350	R:R:T346	3.04	No	No	0	8	8
486	R:R:I349	R:R:I399	2.94	No	Yes	0	7	8
487	R:R:I350	R:R:Y400	3.63	No	Yes	2	8	9
488	R:R:L395	R:R:T353	2.95	No	No	0	6	7
489	R:R:I399	R:R:T353	4.56	Yes	No	0	8	7
490	R:R:F354	R:R:W358	2	Yes	Yes	2	9	8
491	R:R:I355	R:R:L359	2.85	No	Yes	0	7	7
492	R:R:C357	R:R:N392	9.45	No	Yes	0	8	9
493	R:R:F361	R:R:W358	5.01	No	Yes	2	8	8
494	R:R:F362	R:R:W358	4.01	Yes	Yes	2	7	8
495	R:R:G389	R:R:W358	8.44	No	Yes	0	8	8
496	R:R:N392	R:R:W358	7.91	Yes	Yes	0	9	8
497	R:R:L359	R:R:P360	3.28	Yes	No	0	7	9
498	R:R:I363	R:R:L359	7.14	No	Yes	0	7	7
499	R:R:F361	R:R:F362	2.14	No	Yes	2	8	7
500	R:R:F361	R:R:N386	7.25	No	No	0	8	7
501	R:R:L368	R:R:V364	2.98	No	No	14	4	6
502	R:R:M377	R:R:V364	4.56	Yes	No	14	4	6
503	R:R:I385	R:R:V364	3.07	Yes	No	0	6	6
504	R:R:L368	R:R:M377	4.24	No	Yes	14	4	4
505	R:R:F370	R:R:P369	2.89	No	Yes	0	5	7
506	R:R:C371	R:R:S374	3.44	No	No	0	5	5
507	R:R:S373	R:R:S374	3.26	No	No	0	3	5
508	R:R:M377	R:R:P378	3.35	Yes	No	14	4	7
509	R:R:L381	R:R:M377	2.83	No	Yes	14	6	4
510	R:R:L381	R:R:P378	3.28	No	No	14	6	7
511	R:R:I385	R:R:L381	7.14	Yes	No	0	6	6
512	R:R:N386	R:R:Y390	6.98	No	Yes	0	7	8
513	R:R:W387	R:R:Y390	6.75	Yes	Yes	7	8	8
514	R:R:L395	R:R:N392	4.12	No	Yes	0	6	9
515	R:R:N392	R:R:N396	8.17	Yes	No	0	9	9
516	R:R:L394	R:R:L395	2.77	No	No	0	7	6
517	R:R:F403	R:R:V398	2.62	No	No	0	8	6
518	R:R:I399	R:R:Y400	3.63	Yes	Yes	0	8	9
519	R:R:F403	R:R:I399	7.54	No	Yes	0	8	8
520	R:R:A401	R:R:F407	4.16	No	Yes	2	8	8
521	R:R:F407	R:R:Y402	4.13	Yes	Yes	2	8	6
522	R:R:F411	R:R:Y402	11.35	Yes	Yes	2	8	6
523	R:R:D406	R:R:N404	10.77	No	No	0	7	9
524	R:R:F407	R:R:N404	6.04	Yes	No	0	8	9
525	R:R:K405	R:R:Q408	5.42	No	No	0	6	9
526	R:R:F407	R:R:F411	8.57	Yes	Yes	2	8	8
527	R:R:K412	R:R:N409	6.99	No	No	0	6	6
528	B:B:D312	R:R:K413	5.53	No	No	0	5	6
529	B:B:K15	B:B:R19	2.48	No	No	0	6	4
530	B:B:N16	B:B:R19	3.62	No	No	0	1	4
531	B:B:I18	B:B:R22	3.76	No	Yes	0	7	6
532	B:B:D20	B:B:K23	8.3	No	No	0	2	2
533	B:B:D258	B:B:R22	8.34	Yes	Yes	5	7	6
534	B:B:Q259	B:B:R22	7.01	No	Yes	0	6	6
535	B:B:A26	B:B:Q259	4.55	No	No	0	3	6
536	B:B:A28	B:B:D27	3.09	No	No	0	4	8
537	B:B:A28	B:B:Q32	3.03	No	No	0	4	1
538	B:B:S31	B:B:T29	3.2	No	No	0	1	3
539	B:B:L30	B:B:T34	2.95	Yes	Yes	11	5	5
540	B:B:L30	B:B:M262	2.83	Yes	No	0	5	4
541	B:B:L30	B:B:L300	4.15	Yes	Yes	11	5	6
542	B:B:L300	B:B:T34	5.9	Yes	Yes	11	6	5
543	B:B:I37	B:B:R283	2.51	No	Yes	0	2	9
544	B:B:D38	B:B:P39	4.83	No	No	0	1	1
545	B:B:I43	B:B:V40	3.07	No	Yes	0	3	3
546	B:B:R283	B:B:V40	9.15	Yes	Yes	11	9	3
547	B:B:D298	B:B:V40	8.76	Yes	Yes	11	9	3
548	B:B:I43	B:B:M45	4.37	No	Yes	0	3	4
549	B:B:L308	B:B:M45	4.24	Yes	Yes	3	7	4
550	B:B:M45	B:B:W339	3.49	Yes	Yes	3	4	9
551	B:B:M45	B:B:N340	4.21	Yes	Yes	3	4	9
552	B:B:K337	B:B:T47	9.01	Yes	No	3	6	3
553	B:B:T47	B:B:W339	8.49	No	Yes	3	3	9
554	B:B:N340	B:B:R48	7.23	Yes	No	0	9	7
555	B:B:R49	B:B:T87	2.59	No	No	0	7	5
556	B:B:R52	B:B:T50	7.76	No	No	0	7	3
557	B:B:K337	B:B:T50	4.5	Yes	No	0	6	3
558	B:B:L51	B:B:W82	6.83	No	Yes	0	9	9
559	B:B:L51	B:B:T87	2.95	No	No	0	9	5
560	B:B:F335	B:B:R52	6.41	Yes	No	0	4	7
561	B:B:G53	B:B:K89	3.49	No	Yes	0	9	9
562	B:B:H54	B:B:I58	6.63	Yes	Yes	10	9	9
563	B:B:H54	B:B:S72	4.18	Yes	Yes	10	9	9
564	B:B:H54	B:B:S74	12.55	Yes	No	10	9	9
565	B:B:D76	B:B:H54	2.52	Yes	Yes	10	9	9
566	B:B:H54	B:B:I80	13.26	Yes	Yes	10	9	8
567	B:B:H54	B:B:W82	7.41	Yes	Yes	10	9	9
568	B:B:A56	B:B:D76	4.63	No	Yes	0	7	9
569	B:B:K57	B:B:Y59	13.14	No	Yes	1	9	8
570	B:B:K57	B:B:W332	16.24	No	Yes	1	9	9
571	B:B:I58	B:B:S72	6.19	Yes	Yes	10	9	9
572	B:B:I58	B:B:S74	3.1	Yes	No	10	9	9
573	B:B:I58	B:B:L336	4.28	Yes	Yes	10	9	7
574	B:B:Q75	B:B:Y59	24.8	No	Yes	1	9	8
575	B:B:M101	B:B:Y59	2.39	No	Yes	0	9	8
576	B:B:W332	B:B:Y59	4.82	Yes	Yes	1	9	8
577	B:B:A60	B:B:C103	3.61	No	No	0	7	8
578	B:B:M61	B:B:W63	5.82	No	Yes	10	6	7
579	B:B:L70	B:B:M61	4.24	No	No	10	5	6
580	B:B:M61	B:B:S72	4.6	No	Yes	10	6	9
581	B:B:H62	B:B:Y105	4.36	No	Yes	0	6	6
582	B:B:H62	B:B:R150	4.51	No	Yes	0	6	6
583	B:B:L70	B:B:W63	10.25	No	Yes	10	5	7
584	B:B:S84	B:B:W63	6.18	No	Yes	0	5	7
585	B:B:G319	B:B:W63	2.81	No	Yes	0	5	7
586	B:B:T321	B:B:W63	9.7	No	Yes	0	7	7
587	B:B:A328	B:B:W63	3.89	No	Yes	0	5	7
588	B:B:G64	B:B:Y105	2.9	No	Yes	0	5	6
589	B:B:D66	B:B:R68	7.15	No	Yes	0	8	5
590	B:B:S67	B:B:T321	4.8	No	No	0	5	7
591	B:B:D323	B:B:S67	2.94	No	No	0	7	5
592	B:B:L69	B:B:R68	2.43	Yes	Yes	3	5	5
593	B:B:D83	B:B:R68	9.53	Yes	Yes	3	8	5
594	B:B:R68	B:B:Y85	8.23	Yes	No	3	5	4
595	B:B:I81	B:B:L69	4.28	Yes	Yes	3	7	5
596	B:B:D83	B:B:L69	2.71	Yes	Yes	3	8	5
597	B:B:L69	B:B:Y105	2.34	Yes	Yes	3	5	6
598	B:B:L70	B:B:W82	3.42	No	Yes	10	5	9
599	B:B:L79	B:B:V71	2.98	Yes	Yes	3	7	8
600	B:B:I81	B:B:V71	4.61	Yes	Yes	3	7	8
601	B:B:V71	B:B:Y105	5.05	Yes	Yes	3	8	6
602	B:B:V112	B:B:V71	4.81	No	Yes	3	8	8
603	B:B:S72	B:B:W82	6.18	Yes	Yes	10	9	9
604	B:B:L336	B:B:S72	3	Yes	Yes	10	7	9
605	B:B:A73	B:B:V100	3.39	No	No	0	9	9
606	B:B:A73	B:B:C103	3.61	No	No	0	9	8
607	B:B:D76	B:B:S74	5.89	Yes	No	10	9	9
608	B:B:Q75	B:B:W99	4.38	No	Yes	1	9	9
609	B:B:D76	B:B:K78	6.91	Yes	No	0	9	8
610	B:B:G77	B:B:L95	3.42	No	Yes	0	8	8
611	B:B:I93	B:B:L79	9.99	Yes	Yes	0	7	7
612	B:B:L79	B:B:L95	4.15	Yes	Yes	3	7	8
613	B:B:C114	B:B:L79	3.17	Yes	Yes	3	8	7
614	B:B:I80	B:B:W82	16.44	Yes	Yes	10	8	9
615	B:B:I81	B:B:V90	3.07	Yes	No	3	7	5
616	B:B:H91	B:B:I81	3.98	Yes	Yes	3	5	7
617	B:B:I81	B:B:L126	4.28	Yes	Yes	3	7	5
618	B:B:K89	B:B:W82	6.96	Yes	Yes	0	9	9
619	B:B:L336	B:B:W82	3.42	Yes	Yes	10	7	9
620	B:B:D83	B:B:Y85	5.75	Yes	No	3	8	4
621	B:B:D83	B:B:T86	7.23	Yes	No	0	8	6
622	B:B:N88	B:B:T86	11.7	No	No	0	7	6
623	B:B:H91	B:B:V90	5.54	Yes	No	3	5	5
624	B:B:H91	B:B:L126	2.57	Yes	Yes	3	5	5
625	B:B:I93	B:B:P94	3.39	Yes	No	0	7	5
626	B:B:I93	B:B:Y124	8.46	Yes	Yes	0	7	6
627	B:B:I93	B:B:V133	7.68	Yes	No	0	7	4
628	B:B:C114	B:B:L95	4.76	Yes	Yes	3	8	8
629	B:B:L95	B:B:Y124	7.03	Yes	Yes	3	8	6
630	B:B:E138	B:B:R96	5.82	No	No	0	6	6
631	B:B:D118	B:B:S97	8.83	No	No	0	9	8
632	B:B:S98	B:B:W99	8.65	No	Yes	0	8	9
633	B:B:L117	B:B:W99	7.97	Yes	Yes	1	9	9
634	B:B:G116	B:B:M101	3.49	No	No	0	9	9
635	B:B:M101	B:B:Y145	2.39	No	Yes	0	9	8
636	B:B:C148	B:B:T102	5.07	No	No	0	6	8
637	B:B:G109	B:B:Y105	5.79	No	Yes	0	5	6
638	B:B:V112	B:B:Y105	2.52	No	Yes	3	8	6
639	B:B:L126	B:B:Y105	3.52	Yes	Yes	3	5	6
640	B:B:A106	B:B:F151	2.77	No	Yes	0	6	9
641	B:B:N110	B:B:S108	4.47	No	No	0	4	6
642	B:B:N110	B:B:Y111	2.33	No	Yes	0	4	4
643	B:B:K127	B:B:N110	2.8	No	No	0	4	4
644	B:B:I123	B:B:Y111	2.42	Yes	Yes	12	6	4
645	B:B:N125	B:B:Y111	9.3	No	Yes	0	4	4
646	B:B:F151	B:B:Y111	2.06	Yes	Yes	12	9	4
647	B:B:D154	B:B:Y111	5.75	No	Yes	0	6	4
648	B:B:L126	B:B:V112	4.47	Yes	No	3	5	8
649	B:B:A113	B:B:F151	5.55	No	Yes	0	9	9
650	B:B:C114	B:B:Y124	4.03	Yes	Yes	3	8	6
651	B:B:G115	B:B:G116	2.11	No	No	0	9	9
652	B:B:C121	B:B:G115	1.96	No	No	0	8	9
653	B:B:D118	B:B:I120	8.4	No	No	0	9	6
654	B:B:G144	B:B:N119	3.39	No	No	0	8	9
655	B:B:E138	B:B:I120	9.56	No	No	0	6	6
656	B:B:C121	B:B:C149	7.28	No	No	0	8	8
657	B:B:S122	B:B:Y124	7.63	No	Yes	0	8	6
658	B:B:E138	B:B:S122	2.87	No	No	0	6	8
659	B:B:I123	B:B:R137	2.51	Yes	Yes	12	6	5
660	B:B:F151	B:B:I123	5.02	Yes	Yes	12	9	6
661	B:B:I123	B:B:I157	2.94	Yes	Yes	12	6	7
662	B:B:I123	B:B:I171	2.94	Yes	No	12	6	6
663	B:B:V135	B:B:Y124	3.79	No	Yes	0	4	6
664	B:B:N125	B:B:T128	4.39	No	No	0	4	3
665	B:B:N125	B:B:S136	2.98	No	No	0	4	4
666	B:B:E130	B:B:T128	2.82	No	No	0	3	3
667	B:B:E130	B:B:N132	3.94	No	No	0	3	3
668	B:B:L139	B:B:R137	3.64	No	Yes	0	9	5
669	B:B:I171	B:B:R137	3.76	No	Yes	12	6	5
670	B:B:G174	B:B:R137	3	No	Yes	0	4	5
671	B:B:L139	B:B:W169	13.67	No	Yes	0	9	8
672	B:B:G141	B:B:W169	2.81	No	Yes	0	5	8
673	B:B:H142	B:B:L146	3.86	Yes	No	13	9	7
674	B:B:H142	B:B:T159	5.48	Yes	No	13	9	9
675	B:B:H142	B:B:S161	16.74	Yes	No	13	9	9
676	B:B:H142	B:B:T165	2.74	Yes	No	0	9	7
677	B:B:A167	B:B:H142	2.93	No	Yes	13	4	9
678	B:B:H142	B:B:W169	8.46	Yes	Yes	13	9	8
679	B:B:D163	B:B:T143	5.78	No	No	0	9	5
680	B:B:G144	B:B:G162	2.11	No	No	0	8	9
681	B:B:G162	B:B:Y145	4.35	No	Yes	0	9	8
682	B:B:D186	B:B:Y145	8.05	No	Yes	1	9	8
683	B:B:M188	B:B:Y145	3.59	Yes	Yes	1	8	8
684	B:B:L146	B:B:S161	3	No	No	13	7	9
685	B:B:M188	B:B:S147	3.07	Yes	No	0	8	9
686	B:B:C148	B:B:R150	6.96	No	Yes	0	6	6
687	B:B:C149	B:B:I157	4.91	No	Yes	0	8	7
688	B:B:C149	B:B:T159	3.38	No	No	0	8	9
689	B:B:L190	B:B:R150	2.43	Yes	Yes	4	5	6
690	B:B:L192	B:B:R150	2.43	Yes	Yes	4	5	6
691	B:B:F151	B:B:I157	6.28	Yes	Yes	12	9	7
692	B:B:D153	B:B:L152	2.71	No	Yes	0	5	3
693	B:B:L152	B:B:V158	5.96	Yes	No	4	3	5
694	B:B:L152	B:B:L192	6.92	Yes	Yes	4	3	5
695	B:B:L152	B:B:V213	2.98	Yes	No	0	3	4
696	B:B:D170	B:B:N155	13.46	No	No	0	9	3
697	B:B:L168	B:B:Q156	3.99	Yes	No	0	6	5
698	B:B:I157	B:B:I171	4.42	Yes	No	12	7	6
699	B:B:L192	B:B:V158	4.47	Yes	No	4	5	5
700	B:B:T159	B:B:W169	7.28	No	Yes	13	9	8
701	B:B:C166	B:B:S160	3.44	Yes	No	0	8	6
702	B:B:S160	B:B:V187	6.46	No	Yes	0	6	9
703	B:B:L190	B:B:S160	3	Yes	No	0	5	6
704	B:B:G162	B:B:S161	3.71	No	No	0	9	9
705	B:B:D163	B:B:T165	8.67	No	No	0	9	7
706	B:B:T165	B:B:T181	3.14	No	No	0	7	2
707	B:B:C166	B:B:F180	4.19	Yes	Yes	4	8	7
708	B:B:C166	B:B:F199	2.79	Yes	Yes	4	8	9
709	B:B:C166	B:B:S201	3.44	Yes	Yes	4	8	9
710	B:B:A167	B:B:W169	3.89	No	Yes	13	4	8
711	B:B:L168	B:B:T177	4.42	Yes	No	4	6	4
712	B:B:L168	B:B:T178	5.9	Yes	No	4	6	4
713	B:B:L168	B:B:V213	2.98	Yes	No	0	6	4
714	B:B:Q176	B:B:W169	18.62	No	Yes	0	4	8
715	B:B:D170	B:B:T173	7.23	No	No	0	9	5
716	B:B:E172	B:B:T173	4.23	No	No	0	6	5
717	B:B:Q175	B:B:T173	7.09	No	No	0	4	5
718	B:B:Q176	B:B:T179	5.67	No	No	0	4	4
719	B:B:T177	B:B:T178	4.71	No	No	4	4	4
720	B:B:F180	B:B:T178	6.49	Yes	No	4	7	4
721	B:B:F180	B:B:F199	5.36	Yes	Yes	4	7	9
722	B:B:F180	B:B:W211	20.04	Yes	Yes	4	7	8
723	B:B:F180	B:B:G216	4.52	Yes	No	0	7	4
724	B:B:H183	B:B:V187	6.92	Yes	Yes	4	9	9
725	B:B:H183	B:B:S201	5.58	Yes	Yes	4	9	9
726	B:B:A203	B:B:H183	5.85	No	Yes	4	8	9
727	B:B:H183	B:B:K209	13.1	Yes	Yes	4	9	6
728	B:B:H183	B:B:W211	5.29	Yes	Yes	4	9	8
729	B:B:D205	B:B:T184	10.12	No	No	0	9	3
730	B:B:C204	B:B:G185	1.96	Yes	No	0	7	5
731	B:B:D186	B:B:M188	2.77	No	Yes	1	9	8
732	B:B:C204	B:B:D186	4.67	Yes	No	1	7	9
733	B:B:S201	B:B:V187	3.23	Yes	Yes	4	9	9
734	B:B:A203	B:B:V187	3.39	No	Yes	4	8	9
735	B:B:I232	B:B:S189	4.64	Yes	No	0	8	7
736	B:B:L190	B:B:L192	2.77	Yes	Yes	4	5	5
737	B:B:F199	B:B:L190	8.53	Yes	Yes	4	9	5
738	B:B:F234	B:B:S191	6.61	Yes	No	0	5	8
739	B:B:F199	B:B:L192	2.44	Yes	Yes	4	9	5
740	B:B:A193	B:B:D195	3.09	No	No	0	4	5
741	B:B:A193	B:B:F234	2.77	No	Yes	0	4	5
742	B:B:D195	B:B:R197	8.34	No	No	0	5	5
743	B:B:R197	B:B:R214	3.2	No	No	0	5	9
744	B:B:L198	B:B:L210	8.3	No	Yes	0	3	5
745	B:B:F234	B:B:L198	2.44	Yes	No	0	5	3
746	B:B:F199	B:B:W211	9.02	Yes	Yes	4	9	8
747	B:B:F199	B:B:V213	2.62	Yes	No	0	9	4
748	B:B:L210	B:B:V200	4.47	Yes	Yes	0	5	6
749	B:B:I232	B:B:V200	6.14	Yes	Yes	5	8	6
750	B:B:F234	B:B:V200	9.18	Yes	Yes	0	5	6
751	B:B:F241	B:B:V200	2.62	Yes	Yes	5	6	6
752	B:B:S201	B:B:W211	6.18	Yes	Yes	4	9	8
753	B:B:G202	B:B:I229	3.53	No	No	0	6	7
754	B:B:C204	B:B:D228	12.45	Yes	No	1	7	9
755	B:B:S207	B:B:T221	3.2	No	No	0	5	7
756	B:B:A208	B:B:F241	2.77	No	Yes	0	6	6
757	B:B:K209	B:B:W211	4.64	Yes	Yes	4	6	8
758	B:B:C218	B:B:K209	4.85	No	Yes	4	5	6
759	B:B:K209	B:B:T221	4.5	Yes	No	0	6	7
760	B:B:L210	B:B:R219	3.64	Yes	No	0	5	5
761	B:B:L210	B:B:L255	4.15	Yes	No	0	5	6
762	B:B:C218	B:B:W211	6.53	No	Yes	4	5	8
763	B:B:D212	B:B:E215	9.09	No	No	0	9	3
764	B:B:E215	B:B:R214	12.79	No	No	0	3	9
765	B:B:M217	B:B:R219	9.93	No	No	0	3	5
766	B:B:F222	B:B:Q220	9.37	Yes	No	5	8	7
767	B:B:D258	B:B:Q220	10.44	Yes	No	5	7	7
768	B:B:F222	B:B:F241	5.36	Yes	Yes	5	8	6
769	B:B:F222	B:B:F253	4.29	Yes	Yes	5	8	6
770	B:B:F222	B:B:L255	2.44	Yes	No	5	8	6
771	B:B:D258	B:B:F222	7.17	Yes	Yes	5	7	8
772	B:B:G224	B:B:R251	3	No	Yes	0	6	8
773	B:B:H225	B:B:I229	6.63	Yes	No	0	9	7
774	B:B:H225	B:B:T243	5.48	Yes	Yes	5	9	8
775	B:B:H225	B:B:S245	11.16	Yes	No	0	9	9
776	B:B:H225	B:B:T249	2.74	Yes	Yes	5	9	6
777	B:B:H225	B:B:R251	16.93	Yes	Yes	5	9	8
778	B:B:F253	B:B:H225	4.53	Yes	Yes	5	6	9
779	B:B:D247	B:B:E226	3.9	No	No	0	9	3
780	B:B:D246	B:B:S227	7.36	No	No	0	9	6
781	B:B:D247	B:B:S227	5.89	No	No	0	9	6
782	B:B:D228	B:B:D246	2.66	No	No	0	9	9
783	B:B:D246	B:B:N230	8.08	No	No	0	9	9
784	B:B:A231	B:B:V276	3.39	No	No	0	5	6
785	B:B:F241	B:B:I232	8.79	Yes	Yes	5	6	8
786	B:B:I232	B:B:T243	4.56	Yes	Yes	5	8	8
787	B:B:C233	B:B:F278	2.79	No	Yes	0	3	7
788	B:B:F235	B:B:P236	10.11	Yes	Yes	6	6	7
789	B:B:F235	B:B:N237	2.42	Yes	No	6	6	5
790	B:B:F235	B:B:F278	7.5	Yes	Yes	6	6	7
791	B:B:F235	B:B:G282	3.01	Yes	No	6	6	9
792	B:B:F278	B:B:P236	2.89	Yes	Yes	6	7	7
793	B:B:G282	B:B:P236	4.06	No	Yes	6	9	7
794	B:B:N237	B:B:N239	10.9	No	No	0	5	2
795	B:B:N239	B:B:R256	4.82	No	No	0	2	9
796	B:B:F241	B:B:T243	2.59	Yes	Yes	5	6	8
797	B:B:F241	B:B:F253	9.65	Yes	Yes	5	6	6
798	B:B:F241	B:B:L255	4.87	Yes	No	5	6	6
799	B:B:A242	B:B:F278	4.16	No	Yes	0	4	7
800	B:B:F253	B:B:T243	7.78	Yes	Yes	5	6	8
801	B:B:C250	B:B:G244	3.92	No	No	0	8	5
802	B:B:G244	B:B:I273	3.53	No	Yes	0	5	6
803	B:B:D247	B:B:T249	2.89	No	Yes	0	9	6
804	B:B:A248	B:B:I269	4.87	No	Yes	0	5	4
805	B:B:R251	B:B:T249	5.17	Yes	Yes	5	8	6
806	B:B:S265	B:B:T249	3.2	No	Yes	0	2	6
807	B:B:C250	B:B:Y264	2.69	No	Yes	0	8	5
808	B:B:F253	B:B:R251	5.34	Yes	Yes	5	6	8
809	B:B:E260	B:B:R251	18.61	No	Yes	5	6	8
810	B:B:R251	B:B:T263	3.88	Yes	No	5	8	1
811	B:B:L252	B:B:L261	4.15	No	No	0	7	5
812	B:B:L252	B:B:Y264	2.34	No	Yes	0	7	5
813	B:B:E260	B:B:F253	5.83	No	Yes	5	6	6
814	B:B:D254	B:B:R256	4.76	Yes	No	0	9	9
815	B:B:A257	B:B:D254	4.63	No	Yes	0	7	9
816	B:B:D254	B:B:L261	2.71	Yes	No	0	9	5
817	B:B:E260	B:B:T263	2.82	No	No	5	6	1
818	B:B:M262	B:B:Y264	14.37	No	Yes	0	4	5
819	B:B:L285	B:B:Y264	4.69	Yes	Yes	6	6	5
820	B:B:W297	B:B:Y264	3.86	Yes	Yes	6	8	5
821	B:B:H266	B:B:N268	2.55	No	No	0	4	4
822	B:B:H266	B:B:I269	2.65	No	Yes	6	4	4
823	B:B:H266	B:B:R304	12.41	No	Yes	6	4	5
824	B:B:I269	B:B:Y289	10.88	Yes	Yes	6	4	7
825	B:B:I269	B:B:W297	2.35	Yes	Yes	6	4	8
826	B:B:I269	B:B:R304	2.51	Yes	Yes	6	4	5
827	B:B:C271	B:B:G272	1.96	No	No	22	5	4
828	B:B:C271	B:B:D290	9.34	No	No	22	5	6
829	B:B:C271	B:B:D291	7.78	No	No	0	5	8
830	B:B:D290	B:B:G272	3.35	No	No	22	6	4
831	B:B:I273	B:B:V276	3.07	Yes	No	0	6	6
832	B:B:A287	B:B:I273	3.25	No	Yes	6	6	6
833	B:B:I273	B:B:Y289	7.25	Yes	Yes	6	6	7
834	B:B:S275	B:B:T274	3.2	No	No	0	8	8
835	B:B:L318	B:B:S275	3	No	No	0	6	8
836	B:B:L318	B:B:S277	4.5	No	No	0	6	5
837	B:B:F278	B:B:L285	4.87	Yes	Yes	6	7	6
838	B:B:L284	B:B:S279	4.5	No	No	0	5	9
839	B:B:D298	B:B:R283	8.34	Yes	Yes	11	9	9
840	B:B:L284	B:B:V296	4.47	No	Yes	0	5	5
841	B:B:L285	B:B:W297	2.28	Yes	Yes	6	6	8
842	B:B:L286	B:B:V296	4.47	No	Yes	0	7	5
843	B:B:L286	B:B:V327	4.47	No	No	0	7	6
844	B:B:A287	B:B:Y289	4	No	Yes	6	6	7
845	B:B:G288	B:B:V315	3.68	No	No	0	7	7
846	B:B:N295	B:B:Y289	5.81	No	Yes	6	6	7
847	B:B:W297	B:B:Y289	8.68	Yes	Yes	6	8	7
848	B:B:D290	B:B:R314	15.48	No	No	0	6	8
849	B:B:F292	B:B:N293	4.83	No	No	0	4	5
850	B:B:N293	B:B:V307	4.43	No	No	0	5	3
851	B:B:A309	B:B:N293	3.13	No	No	0	3	5
852	B:B:C294	B:B:L308	4.76	No	Yes	0	5	7
853	B:B:C294	B:B:V315	3.42	No	No	0	5	7
854	B:B:C294	B:B:T329	5.07	No	Yes	0	5	8
855	B:B:N295	B:B:W297	13.56	No	Yes	6	6	8
856	B:B:N295	B:B:R304	15.67	No	Yes	6	6	5
857	B:B:L308	B:B:V296	2.98	Yes	Yes	0	7	5
858	B:B:R304	B:B:W297	13.99	Yes	Yes	6	5	8
859	B:B:D298	B:B:L300	5.43	Yes	Yes	11	9	6
860	B:B:D298	B:B:K301	5.53	Yes	No	0	9	5
861	B:B:D303	B:B:K301	8.3	No	No	0	2	5
862	B:B:R304	B:B:V307	2.62	Yes	No	0	5	3
863	B:B:L308	B:B:W339	22.78	Yes	Yes	3	7	9
864	B:B:H311	B:B:V315	5.54	Yes	No	0	9	7
865	B:B:H311	B:B:T329	6.85	Yes	Yes	0	9	8
866	B:B:H311	B:B:S331	12.55	Yes	No	0	9	9
867	B:B:H311	B:B:K337	2.62	Yes	Yes	0	9	6
868	B:B:D312	B:B:D333	7.98	No	No	0	5	9
869	B:B:N313	B:B:W332	9.04	No	Yes	0	7	9
870	B:B:R314	B:B:W332	18.99	No	Yes	0	8	9
871	B:B:C317	B:B:S316	3.44	No	No	0	7	9
872	B:B:S316	B:B:W332	3.71	No	Yes	0	9	9
873	B:B:C317	B:B:G330	1.96	No	No	0	7	5
874	B:B:L318	B:B:T329	2.95	No	Yes	0	6	8
875	B:B:V320	B:B:V327	4.81	No	No	0	7	6
876	B:B:D323	B:B:M325	2.77	No	Yes	0	7	5
877	B:B:M325	B:B:N340	2.8	Yes	Yes	3	5	9
878	B:B:A326	B:B:N340	6.25	No	Yes	3	7	9
879	B:B:V327	B:B:W339	2.45	No	Yes	0	6	9
880	B:B:T329	B:B:W339	2.43	Yes	Yes	0	8	9
881	B:B:G330	B:B:L336	3.42	No	Yes	0	5	7
882	B:B:D333	B:B:F335	14.33	No	Yes	0	9	4
883	B:B:F335	B:B:S334	2.64	Yes	No	0	4	4
884	B:B:K337	B:B:W339	3.48	Yes	Yes	3	6	9
885	A:A:A41	A:A:G42	1.95	No	No	0	7	8
886	R:R:A79	R:R:G76	1.95	No	No	0	9	6
887	B:B:A309	B:B:G310	1.95	No	No	0	3	5
888	B:B:A106	B:B:P107	1.87	No	No	0	6	6
889	B:B:A193	B:B:P194	1.87	No	No	0	4	4
890	B:B:G306	B:B:V296	1.84	No	Yes	0	4	5
891	B:B:G324	B:B:V320	1.84	No	No	0	9	7
892	B:B:G131	B:B:T128	1.82	No	No	0	4	3
893	B:B:G185	B:B:T164	1.82	No	No	0	5	6
894	B:B:G182	B:B:T181	1.82	No	No	0	6	2
895	B:B:G185	B:B:T184	1.82	No	No	0	5	3
896	B:B:G224	B:B:T223	1.82	No	No	0	6	2
897	B:B:A104	B:B:A113	1.79	No	No	0	7	9
898	R:R:P397	R:R:V57	1.77	No	Yes	2	9	9
899	R:R:G202	R:R:I206	1.76	No	No	0	5	6
900	R:R:G352	R:R:I355	1.76	No	No	0	6	7
901	G:G:P53	G:G:T52	1.75	No	No	0	8	4
902	R:R:P150	R:R:T149	1.75	No	No	0	5	8
903	R:R:G382	R:R:M377	1.75	No	Yes	0	4	4
904	B:B:P107	B:B:T65	1.75	No	No	0	6	1
905	A:A:G202	A:A:K46	1.74	No	Yes	0	9	9
906	A:A:C325	A:A:S326	1.72	No	No	0	7	9
907	A:A:G27	B:B:L55	1.71	No	No	0	5	6
908	R:R:G44	R:R:L43	1.71	No	Yes	0	4	7
909	R:R:G53	R:R:L52	1.71	No	No	0	9	4
910	R:R:A114	R:R:S168	1.71	No	No	0	7	8
911	R:R:G348	R:R:L347	1.71	No	No	0	7	8
912	R:R:C371	R:R:V367	1.71	No	No	0	5	6
913	R:R:G389	R:R:L388	1.71	No	No	0	8	8
914	B:B:C103	B:B:V71	1.71	No	Yes	0	8	8
915	B:B:C114	B:B:V100	1.71	Yes	No	0	8	9
916	A:A:G45	A:A:N269	1.7	No	Yes	0	9	9
917	A:A:G183	B:B:N119	1.7	No	No	0	9	9
918	R:R:A79	R:R:V58	1.7	No	No	0	9	7
919	B:B:A305	B:B:V40	1.7	No	Yes	0	4	3
920	A:A:C325	A:A:T327	1.69	No	No	0	7	8
921	R:R:I385	R:R:P360	1.69	Yes	No	0	6	9
922	R:R:A203	R:R:T121	1.68	No	Yes	0	8	8
923	R:R:A129	R:R:T160	1.68	No	Yes	0	8	8
924	R:R:M172	R:R:P171	1.68	No	No	0	6	7
925	R:R:A222	R:R:T343	1.68	No	No	0	8	8
926	A:A:C286	A:A:I285	1.64	Yes	No	0	6	3
927	R:R:L90	R:R:P91	1.64	Yes	No	0	8	9
928	R:R:L368	R:R:P369	1.64	No	Yes	0	4	7
929	A:A:I19	B:B:A92	1.62	No	No	0	9	6
930	A:A:A220	A:A:I265	1.62	No	Yes	0	8	8
931	G:G:S31	G:G:V30	1.62	No	No	0	9	8
932	R:R:S40	R:R:V98	1.62	No	Yes	0	5	6
933	R:R:A401	R:R:I75	1.62	No	No	0	8	8
934	R:R:A336	R:R:I226	1.62	No	No	0	5	6
935	B:B:A92	B:B:I80	1.62	No	Yes	0	6	8
936	B:B:A140	B:B:I120	1.62	No	No	0	5	6
937	R:R:A336	R:R:K332	1.61	No	No	0	5	6
938	B:B:A302	B:B:M262	1.61	No	No	0	2	4
939	R:R:V58	R:R:V80	1.6	No	No	0	7	7
940	B:B:S31	B:B:T34	1.6	No	Yes	0	1	5
941	A:A:T187	A:A:V185	1.59	No	No	0	6	5
942	R:R:T39	R:R:V98	1.59	No	Yes	0	5	6
943	R:R:T121	R:R:V117	1.59	Yes	No	0	8	8
944	B:B:A240	G:G:L37	1.58	No	No	0	6	7
945	R:R:A59	R:R:L63	1.58	No	No	0	5	6
946	B:B:A240	B:B:L252	1.58	No	No	0	6	7
947	B:B:A299	B:B:L285	1.58	No	Yes	0	5	6
948	B:B:A299	B:B:L300	1.58	No	Yes	0	5	6
949	A:A:N347	R:R:A137	1.56	No	No	0	8	8
950	A:A:A30	A:A:D26	1.54	No	No	0	3	5
951	G:G:A45	G:G:D48	1.54	No	Yes	0	4	9
952	R:R:A71	R:R:D133	1.54	No	No	0	8	9
953	R:R:I363	R:R:V367	1.54	No	No	0	7	6
954	B:B:A24	B:B:D20	1.54	No	No	0	3	2
955	A:A:K280	A:A:S281	1.53	No	No	0	1	7
956	R:R:A383	R:R:Q97	1.52	No	No	0	6	7
957	R:R:F219	R:R:G216	1.51	No	No	0	6	3
958	R:R:K342	R:R:T346	1.5	No	No	0	8	8
959	B:B:L261	G:G:V30	1.49	No	No	0	5	8
960	R:R:L43	R:R:V98	1.49	Yes	Yes	7	7	6
961	R:R:L95	R:R:V98	1.49	No	Yes	7	6	6
962	R:R:L99	R:R:V98	1.49	No	Yes	7	5	6
963	A:A:V13	B:B:N88	1.48	No	No	0	3	7
964	R:R:N146	R:R:V145	1.48	No	No	0	5	6
965	A:A:D9	A:A:S6	1.47	No	No	0	4	7
966	G:G:L51	G:G:T52	1.47	No	No	0	6	4
967	R:R:L99	R:R:T103	1.47	No	No	0	5	5
968	R:R:L104	R:R:T103	1.47	No	No	0	7	5
969	R:R:D192	R:R:S190	1.47	No	No	0	6	6
970	R:R:I384	R:R:I385	1.47	No	Yes	0	4	6
971	A:A:D9	A:A:V13	1.46	No	No	0	4	3
972	B:B:A206	B:B:H225	1.46	No	Yes	0	4	9
973	A:A:D328	A:A:T327	1.45	No	No	0	9	8
974	B:B:D153	B:B:T196	1.45	No	No	0	5	1
975	B:B:D170	B:B:T177	1.45	No	No	0	9	4
976	G:G:K20	G:G:M21	1.44	No	No	0	6	1
977	G:G:K29	G:G:K32	1.44	No	No	0	4	5
978	R:R:I414	R:R:L63	1.43	No	No	0	7	6
979	R:R:I163	R:R:L159	1.43	No	No	0	5	3
980	R:R:E340	R:R:V344	1.43	Yes	No	0	8	8
981	A:A:K314	R:R:N328	1.4	No	No	0	3	3
982	R:R:K405	R:R:N409	1.4	No	No	0	6	6
983	B:B:K301	B:B:N35	1.4	No	No	0	5	1
984	A:A:P288	A:A:Y287	1.39	No	Yes	0	5	7
985	B:B:L14	G:G:L19	1.38	No	No	0	8	9
986	R:R:A338	R:R:R341	1.38	No	No	0	5	6
987	R:R:E340	R:R:I226	1.37	Yes	No	0	8	6
988	R:R:N325	R:R:N328	1.36	No	No	0	5	3
989	A:A:E33	A:A:K29	1.35	No	No	0	6	1
990	A:A:D200	A:A:N47	1.35	No	No	0	9	9
991	A:A:E276	A:A:K280	1.35	No	No	0	5	1
992	B:B:K280	G:G:E47	1.35	No	No	0	1	3
993	A:A:E276	A:A:L273	1.33	No	No	0	5	6
994	G:G:E22	G:G:L19	1.33	No	No	0	9	9
995	R:R:A186	R:R:Y96	1.33	No	No	0	4	6
996	B:B:L14	B:B:Q17	1.33	No	No	0	8	4
997	R:R:R151	R:R:T149	1.29	No	No	0	6	8
998	A:A:H244	A:A:N241	1.28	No	No	0	4	9
999	A:A:F189	A:A:K54	1.24	Yes	No	0	9	7
1000	A:A:E33	A:A:H195	1.23	No	No	0	6	4
1001	A:A:R32	R:R:N146	1.21	No	No	0	4	5
1002	A:A:E28	A:A:R24	1.16	No	No	0	4	3
1003	B:B:E130	B:B:R134	1.16	No	No	0	3	3
1004	B:B:R48	G:G:R62	1.07	No	No	0	7	7

Color	ConSurf Grade
	No Conservation data available
	1
	2
	3
	4
	5
	6
	7
	8
	9

Index: hub id, click on each number to highlight the corresponding hub in the 3D visualization.

Hub: the hub being considered.

Avg Int. Strength: the average interaction strength of all the links of the corresponding hub.

Num Of Links: the number of links of the corresponding hub.

Community: the id of the community the link belong to, otherwise 0.

ConSurf: this column reports the ConSurf conservation grades of each hub.

Index	Hub	Avg Int. Strength	Num Of Links	Community	ConSurf
1	A:A:L38	5.2325	4	8	8
2	A:A:L39	4.1225	4	1	9
3	A:A:K46	4.828	5	8	9
4	A:A:M53	6.3525	4	0	8
5	A:A:I184	4.74	4	1	9
6	A:A:F189	5.218	5	0	9
7	A:A:F191	7.39	4	9	5
8	A:A:F196	5.77	6	9	7
9	A:A:K197	6.925	4	1	6
10	A:A:F199	6.492	5	1	5
11	A:A:E207	4.14	4	1	9
12	A:A:R208	5	4	0	9
13	A:A:W211	4.95667	6	1	9
14	A:A:I212	4.1575	4	1	8
15	A:A:F215	4.55714	7	1	9
16	A:A:I221	4.398	5	1	8
17	A:A:I222	3.145	4	8	7
18	A:A:F223	5.385	6	1	9
19	A:A:Y230	4.422	5	1	8
20	A:A:R242	7.83	4	15	9
21	A:A:M243	2.9375	4	1	8
22	A:A:F250	6.86	4	0	9
23	A:A:I253	4.2175	4	1	8
24	A:A:N256	6.38	4	1	8
25	A:A:W258	7.814	5	1	5
26	A:A:F259	5.83167	6	1	9
27	A:A:I265	2.75167	6	8	8
28	A:A:F267	4.00286	7	8	9
29	A:A:L268	4.6475	4	1	8
30	A:A:N269	5.4425	4	0	9
31	A:A:F274	6.296	5	1	9
32	A:A:C286	4.245	4	1	6
33	A:A:Y287	4.79375	8	1	7
34	A:A:Y290	10.706	5	1	7
35	A:A:Y296	4.078	5	1	4
36	A:A:F307	3.996	5	1	8
37	A:A:Y320	2.795	6	8	7
38	A:A:F323	4.355	4	0	4
39	A:A:N331	6.6425	4	8	8
40	A:A:F334	6.7675	4	8	3
41	A:A:F336	3.854	5	9	8
42	A:A:L348	4.5	4	0	9
43	A:A:L353	4.7	5	0	7
44	A:A:F354	8.462	5	0	5
45	G:G:R27	5.1575	4	5	8
46	G:G:M38	4.01	4	11	4
47	G:G:Y40	6.325	4	6	6
48	G:G:D48	4.054	5	0	9
49	G:G:V54	4.9075	4	3	6
50	G:G:N59	5.912	5	3	9
51	G:G:F61	5.57857	7	3	8
52	R:R:L43	4.545	4	7	7
53	R:R:N54	5.3675	4	2	9
54	R:R:V57	3.87	6	2	9
55	R:R:L67	3.5725	4	0	8
56	R:R:L74	4.2525	4	0	8
57	R:R:L78	3.61	5	2	9
58	R:R:D82	3.98	5	2	9
59	R:R:S86	3.1575	4	0	8
60	R:R:L90	3.318	5	0	8
61	R:R:V98	1.536	5	7	6
62	R:R:W102	5.14857	7	7	9
63	R:R:F112	5.415	4	7	6
64	R:R:T121	3.388	5	0	8
65	R:R:I124	4.18	4	2	8
66	R:R:W125	4.518	5	2	7
67	R:R:H126	7.20286	7	2	8
68	R:R:L127	5.865	4	0	8
69	R:R:I130	4.2325	4	0	9
70	R:R:Y135	8.592	5	0	9
71	R:R:I157	5.3275	4	2	8
72	R:R:T160	4.106	5	2	8
73	R:R:W161	4.90167	6	2	9
74	R:R:F204	8.57167	6	2	8
75	R:R:Y205	6.5825	4	2	7
76	R:R:P207	4.3275	4	2	9
77	R:R:Y215	4.78667	6	2	9
78	R:R:E340	3.0275	4	0	8
79	R:R:F354	4.67	5	2	9
80	R:R:W358	5.33125	8	2	8
81	R:R:L359	5.45	4	0	7
82	R:R:F362	8.3275	4	2	7
83	R:R:P369	3.7175	4	0	7
84	R:R:M377	3.346	5	14	4
85	R:R:I385	3.3425	4	0	6
86	R:R:W387	5.75	5	7	8
87	R:R:Y390	6.746	5	7	8
88	R:R:N392	7.4125	4	0	9
89	R:R:I399	4.6675	4	0	8
90	R:R:Y400	4.23	5	2	9
91	R:R:Y402	5.224	5	2	6
92	R:R:F407	4.95143	7	2	8
93	R:R:F411	6.7175	4	2	8
94	B:B:R22	5.31	4	5	6
95	B:B:L30	3.665	4	11	5
96	B:B:T34	3.365	4	11	5
97	B:B:V40	5.67	4	11	3
98	B:B:M45	4.0775	4	3	4
99	B:B:H54	7.75833	6	10	9
100	B:B:I58	5.05	4	10	9
101	B:B:Y59	9.00833	6	1	8
102	B:B:W63	6.44167	6	10	7
103	B:B:R68	6.835	4	3	5
104	B:B:L69	2.94	4	3	5
105	B:B:V71	3.832	5	3	8
106	B:B:S72	4.83	5	10	9
107	B:B:D76	4.9875	4	10	9
108	B:B:L79	5.0725	4	3	7
109	B:B:I80	8.5425	4	10	8
110	B:B:I81	4.044	5	3	7
111	B:B:W82	7.23714	7	10	9
112	B:B:D83	6.305	4	3	8
113	B:B:K89	5.96	4	0	9
114	B:B:H91	3.5875	4	3	5
115	B:B:I93	7.38	4	0	7
116	B:B:L95	4.84	4	3	8
117	B:B:W99	6.3175	8	1	9
118	B:B:Y105	3.78286	7	3	6
119	B:B:Y111	4.372	5	12	4
120	B:B:C114	3.4175	4	3	8
121	B:B:L117	4.9575	4	1	9
122	B:B:I123	3.166	5	12	6
123	B:B:Y124	6.188	5	3	6
124	B:B:L126	3.71	4	3	5
125	B:B:R137	3.2275	4	12	5
126	B:B:H142	6.70167	6	13	9
127	B:B:Y145	4.694	5	1	8
128	B:B:R150	4.0825	4	4	6
129	B:B:F151	4.336	5	12	9
130	B:B:L152	4.6425	4	4	3
131	B:B:I157	4.6375	4	12	7
132	B:B:C166	3.465	4	4	8
133	B:B:L168	4.3225	4	4	6
134	B:B:W169	9.12167	6	13	8
135	B:B:F180	8.12	5	4	7
136	B:B:H183	7.348	5	4	9
137	B:B:V187	5	4	4	9
138	B:B:M188	3.7975	4	1	8
139	B:B:L190	4.1825	4	4	5
140	B:B:L192	3.806	5	4	5
141	B:B:F199	5.12667	6	4	9
142	B:B:V200	5.6025	4	5	6
143	B:B:S201	4.6075	4	4	9
144	B:B:C204	5.91	4	1	7
145	B:B:K209	6.7725	4	4	6
146	B:B:L210	5.14	4	0	5
147	B:B:W211	8.61667	6	4	8
148	B:B:F222	5.726	5	5	8
149	B:B:H225	6.99	7	5	9
150	B:B:I232	6.0325	4	5	8
151	B:B:F234	5.25	4	0	5
152	B:B:F235	5.34	6	6	6
153	B:B:P236	5.3075	4	6	7
154	B:B:F241	5.23571	7	5	6
155	B:B:T243	5.1025	4	5	8
156	B:B:T249	3.5	4	5	6
157	B:B:R251	8.82167	6	5	8
158	B:B:F253	6.23667	6	5	6
159	B:B:D254	3.7975	4	0	9
160	B:B:D258	9.1675	4	5	7
161	B:B:Y264	5.59	5	6	5
162	B:B:I269	4.652	5	6	4
163	B:B:I273	4.275	4	6	6
164	B:B:F278	4.442	5	6	7
165	B:B:R283	5.322	5	11	9
166	B:B:L285	3.355	4	6	6
167	B:B:Y289	7.324	5	6	7
168	B:B:V296	3.44	4	0	5
169	B:B:W297	7.45333	6	6	8
170	B:B:D298	7.015	4	11	9
171	B:B:L300	3.978	5	11	6
172	B:B:R304	9.44	5	6	5
173	B:B:L308	8.69	4	3	7
174	B:B:H311	6.89	4	0	9
175	B:B:M325	4.432	5	3	5
176	B:B:T329	4.325	4	0	8
177	B:B:W332	9.68167	6	1	9
178	B:B:F335	6.6475	4	0	4
179	B:B:L336	3.53	4	10	7
180	B:B:K337	4.9025	4	3	6
181	B:B:W339	7.18667	6	3	9
182	B:B:N340	5.05	7	3	9

Color	ConSurf Grade
	No Conservation data available
	1
	2
	3
	4
	5
	6
	7
	8
	9

Index: link id, click on each number to highlight the corresponding link in the 3D visualization.

Node1 Node2: the two nodes of the corresponding link.

Recurrence: the relative Recurrence in the pool of shortest paths.

Int. Strength: the interaction strength between the two nodes.

Hub1?, Hub2?: "Yes" if the corresponding node has more than 3 links, otherwise "No".

Community: the id of the community the link belong to, otherwise 0.

ConSurf1, ConSurf2: these columns report the ConSurf conservation grades of the two nodes involved in a link.

Index	Node1	Node2	Recurrence	Int. Strength	Hub1?	Hub2?	Community	ConSurf1	ConSurf2
1	B:B:L51	B:B:W82	23.637	6.83	No	Yes	0	9	9
2	B:B:L51	B:B:T87	23.633	2.95	No	No	0	9	5
3	B:B:R49	B:B:T87	23.6542	2.59	No	No	0	7	5
4	B:B:R49	G:G:F61	23.7064	8.55	No	Yes	0	7	8
5	B:B:N340	G:G:F61	69.6143	3.62	Yes	Yes	3	9	8
6	B:B:M45	B:B:N340	100	4.21	Yes	Yes	3	4	9
7	B:B:M45	B:B:W339	83.901	3.49	Yes	Yes	3	4	9
8	B:B:K337	B:B:W339	82.2413	3.48	Yes	Yes	3	6	9
9	B:B:K337	B:B:T50	82.1562	4.5	Yes	No	0	6	3
10	B:B:R52	B:B:T50	82.0217	7.76	No	No	0	7	3
11	B:B:F335	B:B:R52	81.887	6.41	Yes	No	0	4	7
12	B:B:L70	B:B:W82	23.8483	3.42	No	Yes	10	5	9
13	B:B:L70	B:B:W63	23.8346	10.25	No	Yes	10	5	7
14	B:B:S84	B:B:W63	47.0837	6.18	No	Yes	0	5	7
15	B:B:S84	G:G:F61	47.1001	7.93	No	Yes	0	5	8
16	B:B:W332	B:B:Y59	56.2752	4.82	Yes	Yes	1	9	8
17	B:B:S316	B:B:W332	75.0675	3.71	No	Yes	0	9	9
18	B:B:C317	B:B:S316	75.1714	3.44	No	No	0	7	9
19	B:B:C317	B:B:G330	75.2751	1.96	No	No	0	7	5
20	B:B:G330	B:B:L336	75.3788	3.42	No	Yes	0	5	7
21	B:B:L336	B:B:W82	51.7586	3.42	Yes	Yes	10	7	9
22	R:R:R148	R:R:Y144	10.4421	5.14	No	No	0	8	8
23	R:R:D133	R:R:R148	10.8095	9.53	No	No	0	9	8
24	R:R:D133	R:R:L74	11.1784	5.43	No	Yes	0	9	8
25	R:R:I130	R:R:L74	11.7345	4.28	Yes	Yes	0	9	8
26	R:R:I130	R:R:L78	30.1348	2.85	Yes	Yes	0	9	9
27	R:R:D82	R:R:L78	48.2467	2.71	Yes	Yes	2	9	9
28	R:R:D82	R:R:P397	66.8608	4.83	Yes	No	2	9	9
29	R:R:P397	R:R:V57	76.1185	1.77	No	Yes	2	9	9
30	R:R:F407	R:R:V57	76.7234	6.55	Yes	Yes	2	8	9
31	R:R:F407	R:R:L67	78.7562	2.44	Yes	Yes	0	8	8
32	R:R:A410	R:R:L67	79.3056	4.73	No	Yes	0	8	8
33	R:R:A410	R:R:E64	79.4426	4.53	No	No	0	8	7
34	R:R:E64	R:R:K413	79.9895	8.1	No	No	0	7	6
35	B:B:D312	R:R:K413	80.1255	5.53	No	No	0	5	6
36	B:B:D312	B:B:D333	80.262	7.98	No	No	0	5	9
37	B:B:D333	B:B:F335	80.3982	14.33	No	Yes	0	9	4
38	R:R:I130	R:R:R134	15.8542	3.76	Yes	No	0	9	9
39	A:A:C351	R:R:R134	15.6745	6.96	No	No	0	4	9
40	A:A:C351	A:A:L353	15.5016	6.35	No	Yes	0	4	7
41	A:A:L348	A:A:L353	15.9213	4.15	Yes	Yes	0	9	7
42	A:A:F354	A:A:L348	12.5207	2.44	Yes	Yes	0	5	9
43	A:A:H213	B:B:W332	17.9302	5.29	No	Yes	1	8	9
44	A:A:H213	A:A:W258	17.927	10.58	No	Yes	1	8	5
45	A:A:I212	A:A:W258	16.4609	2.35	Yes	Yes	1	8	5
46	A:A:F223	A:A:L249	17.4856	6.09	Yes	No	1	9	9
47	A:A:L249	A:A:R208	17.8111	4.86	No	Yes	0	9	9
48	A:A:I212	A:A:R208	15.5335	5.01	Yes	Yes	0	8	9
49	B:B:M101	B:B:Y59	49.3715	2.39	No	Yes	0	9	8
50	B:B:M101	B:B:Y145	44.19	2.39	No	Yes	0	9	8
51	A:A:K210	B:B:M188	21.7842	5.76	No	Yes	0	9	8
52	B:B:M188	B:B:Y145	22.0867	3.59	Yes	Yes	1	8	8
53	B:B:C204	B:B:D186	22.4165	4.67	Yes	No	1	7	9
54	B:B:D186	B:B:Y145	22.5669	8.05	No	Yes	1	9	8
55	B:B:C204	B:B:D228	21.3378	12.45	Yes	No	1	7	9
56	A:A:K210	B:B:N230	21.3124	4.2	No	No	0	9	9
57	R:R:L127	R:R:L78	10.2447	6.92	Yes	Yes	0	8	9
58	R:R:D82	R:R:N396	18.6455	2.69	Yes	No	0	9	9
59	R:R:L127	R:R:N396	10.0603	8.24	Yes	No	0	8	9
60	B:B:H62	B:B:Y105	19.1752	4.36	No	Yes	0	6	6
61	B:B:H62	B:B:R150	18.9726	4.51	No	Yes	0	6	6
62	B:B:D228	B:B:D246	21.2025	2.66	No	No	0	9	9
63	B:B:D246	B:B:S227	42.0497	7.36	No	No	0	9	6
64	B:B:D247	B:B:S227	41.737	5.89	No	No	0	9	6
65	B:B:D247	B:B:T249	41.1112	2.89	No	Yes	0	9	6
66	B:B:H225	B:B:T249	26.6686	2.74	Yes	Yes	5	9	6
67	B:B:F253	B:B:H225	12.2221	4.53	Yes	Yes	5	6	9
68	B:B:D246	B:B:N230	21.1604	8.08	No	No	0	9	9
69	B:B:R251	B:B:T249	13.8162	5.17	Yes	Yes	5	8	6
70	B:B:F253	B:B:R251	12.2206	5.34	Yes	Yes	5	6	8
71	B:B:I43	B:B:M45	20.3419	4.37	No	Yes	0	3	4
72	B:B:I43	B:B:V40	20.1585	3.07	No	Yes	0	3	3
73	B:B:D298	B:B:V40	17.3253	8.76	Yes	Yes	11	9	3
74	B:B:D298	B:B:L300	16.6564	5.43	Yes	Yes	11	9	6
75	B:B:A299	B:B:L300	11.1295	1.58	No	Yes	0	5	6
76	B:B:A299	B:B:L285	10.9411	1.58	No	Yes	0	5	6
77	B:B:L69	B:B:R68	15.2822	2.43	Yes	Yes	3	5	5
78	B:B:R68	B:B:Y85	15.4261	8.23	Yes	No	3	5	4
79	B:B:Y85	G:G:P60	31.3248	4.17	No	No	3	4	9
80	B:B:D83	B:B:L69	15.3752	2.71	Yes	Yes	3	8	5
81	B:B:D83	B:B:Y85	15.8747	5.75	Yes	No	3	8	4
82	R:R:F354	R:R:L127	14.9408	2.44	Yes	Yes	0	9	8
83	R:R:F204	R:R:F354	12.7111	6.43	Yes	Yes	2	8	9
84	R:R:F204	R:R:L359	13.8775	8.53	Yes	Yes	0	8	7
85	B:B:M61	B:B:S72	23.4707	4.6	No	Yes	10	6	9
86	B:B:L79	B:B:V71	13.2202	2.98	Yes	Yes	3	7	8
87	B:B:H225	B:B:T243	12.8658	5.48	Yes	Yes	5	9	8
88	B:B:F234	B:B:V200	12.8794	9.18	Yes	Yes	0	5	6
89	B:B:F241	B:B:V200	14.485	2.62	Yes	Yes	5	6	6
90	B:B:F241	B:B:F253	14.1553	9.65	Yes	Yes	5	6	6
91	G:G:N59	G:G:P60	15.7993	6.52	Yes	No	3	9	9
92	B:B:N340	G:G:N59	15.4677	6.81	Yes	Yes	3	9	9
93	B:B:M325	G:G:P60	15.7982	10.06	Yes	No	3	5	9
94	B:B:M325	B:B:N340	15.5912	2.8	Yes	Yes	3	5	9
95	B:B:L69	B:B:Y105	22.9698	2.34	Yes	Yes	3	5	6
96	B:B:M61	B:B:W63	23.4676	5.82	No	Yes	10	6	7
97	B:B:L336	B:B:S72	23.2814	3	Yes	Yes	10	7	9

Download PSN data

2D representation of the global metapath, ligand(s) interactions and
histograms of path distribution according to several parameters
(click on the image to enlarge it 🔍):

A 2D representation of the global communication in the network.

ConSurf Conservation Grade (See documentation):

n/a 1 2 3 4 5 6 7 8 9

Number of shortest communication paths as a function of the average residue correlation.

Number of shortest communication paths as a function of the average interaction strength of their links.

Number of shortest communication paths as a function of the % of hub nodes in each path.

Number of shortest communication paths as a function of the number of nodes in each path.

Number of shortest communication paths as a function of the % of correlated nodes in each path.

there is no ligand in network 7E2X

PDB Summary
PDB	7E2X
Class	A
SubFamily	Amine
Type	5-Hydroxytryptamine
SubType	5-HT1A
Species	Homo Sapiens
Ligand	-
Other Ligand(s)	-
Protein Partners	Gi1/Beta1/Gamma2
PDB Resolution	3
Date	2021-04-14
D.O.I.	doi.org/10.1038/s41586-021-03376-8

Net Summary
I_min	1.96
Number of Linked Nodes	787
Number of Links	1004
Number of Hubs	182
Number of Links mediated by Hubs	649
Number of Communities	22
Number of Nodes involved in Communities	267
Number of Links involved in Communities	407

Path Summary
Number Of Nodes in MetaPath	98
Number Of Links MetaPath	97
Number of Shortest Paths	2033217
Length Of Smallest Path	3
Average Path Length	34.7263
Length of Longest Path	68
Minimum Path Strength	1.29
Average Path Strength	5.03255
Maximum Path Strength	22.425
Minimum Path Correlation	0.7
Average Path Correlation	0.979435
Maximum Path Correlation	1
Minimum % Of Corr. Nodes	2
Average % Of Corr. Nodes	35.8693
Maximum % Of Corr. Nodes	100
Minimum Path Hubs %	0
Average Path Hubs %	53.9383
Maximum Path Hubs %	100

Annotation	Type	Links
Gene Ontology	Molecular Function	• D2 dopamine receptor binding • protein binding • binding • signaling receptor binding • G protein-coupled receptor binding • dopamine receptor binding • enzyme regulator activity • adenylate cyclase inhibitor activity • cyclase regulator activity • molecular function inhibitor activity • cyclase inhibitor activity • molecular function regulator activity • enzyme inhibitor activity • adenylate cyclase regulator activity • guanyl nucleotide binding • GTP binding • nucleotide binding • guanyl ribonucleotide binding • purine ribonucleotide binding • purine ribonucleoside triphosphate binding • nucleoside phosphate binding • ion binding • purine nucleotide binding • anion binding • heterocyclic compound binding • carbohydrate derivative binding • ribonucleotide binding • small molecule binding • cation binding • magnesium ion binding • metal ion binding • GDP binding • G protein-coupled serotonin receptor binding • protein-containing complex binding • G-protein beta/gamma-subunit complex binding • pyrophosphatase activity • GTPase activity • G protein activity • ribonucleoside triphosphate phosphatase activity • hydrolase activity, acting on acid anhydrides, in phosphorus-containing anhydrides • hydrolase activity • hydrolase activity, acting on acid anhydrides • catalytic activity • cellular response to stimulus • regulation of biological process • regulation of cellular process • response to stimulus • signaling • biological regulation • adenylate cyclase-inhibiting serotonin receptor signaling pathway • G protein-coupled serotonin receptor signaling pathway • cell communication • adenylate cyclase-inhibiting G protein-coupled receptor signaling pathway • adenylate cyclase-modulating G protein-coupled receptor signaling pathway • G protein-coupled receptor signaling pathway • cellular process • signal transduction
Gene Ontology	Biological Process	• cellular response to stimulus • regulation of biological process • regulation of cellular process • response to stimulus • signaling • biological regulation • adenylate cyclase-inhibiting serotonin receptor signaling pathway • G protein-coupled serotonin receptor signaling pathway • cell communication • adenylate cyclase-inhibiting G protein-coupled receptor signaling pathway • adenylate cyclase-modulating G protein-coupled receptor signaling pathway • G protein-coupled receptor signaling pathway • cellular process • signal transduction • response to hormone • response to chemical • response to endogenous stimulus • response to peptide hormone • response to oxygen-containing compound • response to nitrogen compound • cell division • leukocyte migration • immune system process • mononuclear cell migration • lymphocyte migration • cell migration • T cell migration • cell motility • regulation of steroid biosynthetic process • regulation of cholesterol biosynthetic process • regulation of cholesterol metabolic process • steroid metabolic process • regulation of lipid metabolic process • sterol metabolic process • positive regulation of biological process • cholesterol metabolic process • lipid biosynthetic process • alcohol metabolic process • regulation of primary metabolic process • positive regulation of metabolic process • regulation of small molecule metabolic process • positive regulation of biosynthetic process • positive regulation of lipid metabolic process • small molecule metabolic process • steroid biosynthetic process • positive regulation of cellular process • regulation of biosynthetic process • secondary alcohol biosynthetic process • regulation of alcohol biosynthetic process • small molecule biosynthetic process • regulation of steroid metabolic process • cholesterol biosynthetic process • positive regulation of cholesterol biosynthetic process • primary metabolic process • secondary alcohol metabolic process • positive regulation of steroid biosynthetic process • biosynthetic process • sterol biosynthetic process • positive regulation of lipid biosynthetic process • regulation of sterol biosynthetic process • alcohol biosynthetic process • positive regulation of cholesterol metabolic process • positive regulation of steroid metabolic process • metabolic process • regulation of lipid biosynthetic process • positive regulation of small molecule metabolic process • regulation of metabolic process • positive regulation of alcohol biosynthetic process • positive regulation of sterol biosynthetic process • lipid metabolic process • negative regulation of protein transport • regulation of localization • establishment of protein localization • nitrogen compound transport • negative regulation of biological process • negative regulation of transport • localization • negative regulation of secretion • negative regulation of hormone secretion • negative regulation of secretion by cell • intracellular protein localization • regulation of biological quality • regulation of peptide hormone secretion • negative regulation of peptide hormone secretion • regulation of hormone levels • establishment of protein localization to extracellular region • negative regulation of establishment of protein localization • protein secretion • establishment of localization • regulation of protein secretion • regulation of secretion • negative regulation of protein secretion • regulation of hormone secretion • regulation of protein localization • regulation of peptide secretion • transport • negative regulation of signaling • hormone secretion • negative regulation of cell communication • protein localization to extracellular region • negative regulation of peptide secretion • peptide secretion • regulation of secretion by cell • secretion by cell • amide transport • signal release • negative regulation of cellular process • negative regulation of protein localization • regulation of signaling • regulation of transport • secretion • regulation of peptide transport • regulation of establishment of protein localization • export from cell • cell-cell signaling • regulation of protein transport • peptide transport • negative regulation of insulin secretion • protein transport • regulation of insulin secretion • peptide hormone secretion • macromolecule localization • hormone transport • regulation of cell communication • insulin secretion • regulation of cytoskeleton organization • regulation of cellular component organization • microtubule cytoskeleton organization • regulation of mitotic spindle organization • mitotic cell cycle • cellular component organization • cell cycle • cellular component organization or biogenesis • regulation of cell cycle • microtubule cytoskeleton organization involved in mitosis • spindle organization • cell cycle process • regulation of cell cycle process • regulation of microtubule-based process • regulation of spindle organization • regulation of organelle organization • mitotic spindle organization • organelle organization • mitotic cell cycle process • microtubule-based process • cytoskeleton organization • regulation of microtubule cytoskeleton organization • positive regulation of protein localization to cell periphery • protein localization to cell periphery • positive regulation of protein localization to cell cortex • regulation of protein localization to cell periphery • regulation of protein localization to cell cortex • positive regulation of protein localization • protein localization to cell cortex • response to ketone • response to prostaglandin • response to lipid • response to alcohol • response to prostaglandin E • cellular response to forskolin • cellular response to oxygen-containing compound • cellular response to chemical stimulus • cellular response to alcohol • response to forskolin • cellular response to lipid • cellular response to ketone • midbody • cellular anatomical structure • membrane-bounded organelle • intracellular anatomical structure • nucleus • membrane-enclosed lumen • intracellular membraneless organelle • intracellular membrane-bounded organelle • nucleolus • intracellular organelle lumen • intracellular organelle • organelle lumen • organelle • membraneless organelle
Gene Ontology	Cellular Component	• midbody • cellular anatomical structure • membrane-bounded organelle • intracellular anatomical structure • nucleus • membrane-enclosed lumen • intracellular membraneless organelle • intracellular membrane-bounded organelle • nucleolus • intracellular organelle lumen • intracellular organelle • organelle lumen • organelle • membraneless organelle • nuclear lumen • cell periphery • cell cortex • cytoplasm • protein-containing complex • extrinsic component of plasma membrane • catalytic complex • plasma membrane protein complex • cytoplasmic side of membrane • membrane • plasma membrane • membrane protein complex • heterotrimeric G-protein complex • side of membrane • cytoplasmic side of plasma membrane • GTPase complex • extrinsic component of membrane • extrinsic component of cytoplasmic side of plasma membrane • extracellular exosome • extracellular vesicle • extracellular organelle • extracellular region • extracellular space • vesicle • extracellular membrane-bounded organelle • centrosome • microtubule organizing center • cytoskeleton • microtubule cytoskeleton • centriolar satellite • cytosol • nucleoplasm • vacuolar membrane • lytic vacuole • vacuole • lytic vacuole membrane • bounding membrane of organelle • lysosomal membrane • organelle membrane • lysosome • Golgi apparatus • endomembrane system • cilium • plasma membrane bounded cell projection • ciliary basal body • cell projection • protein binding • binding • enzyme binding • GTPase binding • protein-containing complex binding • pyrophosphatase activity • GTPase activity • ribonucleoside triphosphate phosphatase activity • hydrolase activity, acting on acid anhydrides, in phosphorus-containing anhydrides • hydrolase activity • hydrolase activity, acting on acid anhydrides • catalytic activity • signaling receptor complex adaptor activity • protein-macromolecule adaptor activity • molecular adaptor activity • signaling adaptor activity • multicellular organismal process • system process • sensory perception of chemical stimulus • sensory perception • nervous system process • sensory perception of taste • developmental process • sensory organ development • eye development • animal organ development • retina development in camera-type eye • visual system development • multicellular organism development • camera-type eye development • anatomical structure development • sensory system development • system development • cell population proliferation • cellular process • cellular response to stimulus • regulation of biological process • regulation of cellular process • response to stimulus • signaling • biological regulation • signal transduction • cell communication • response to ketone • response to prostaglandin • response to lipid • response to endogenous stimulus • response to alcohol • cellular response to prostaglandin stimulus • response to oxygen-containing compound • cellular response to oxygen-containing compound • cellular response to endogenous stimulus • cellular response to prostaglandin E stimulus • cellular response to chemical stimulus • cellular response to alcohol • response to hormone • response to chemical • cellular response to lipid • response to prostaglandin E • cellular response to ketone • cellular response to hormone stimulus • small GTPase-mediated signal transduction • Ras protein signal transduction • intracellular signal transduction • intracellular signaling cassette • phospholipase C-activating G protein-coupled receptor signaling pathway • G protein-coupled receptor signaling pathway • cellular response to nitrogen compound • response to dopamine • cellular response to dopamine • response to monoamine • response to catecholamine • adenylate cyclase-activating dopamine receptor signaling pathway • cellular response to catecholamine stimulus • G protein-coupled dopamine receptor signaling pathway • response to nitrogen compound • adenylate cyclase-activating G protein-coupled receptor signaling pathway • cellular response to monoamine stimulus • adenylate cyclase-modulating G protein-coupled receptor signaling pathway • synaptic signaling • cellular response to acetylcholine • cell-cell signaling • acetylcholine receptor signaling pathway • postsynaptic signal transduction • G protein-coupled acetylcholine receptor signaling pathway • response to acetylcholine • non-motile cilium • 9+0 non-motile cilium • neuron projection • photoreceptor disc membrane • photoreceptor outer segment • photoreceptor cell cilium • synapse • cell junction • G-protein beta-subunit binding • fibroblast proliferation • cation binding • ion binding • serotonin binding • amine binding • heterocyclic compound binding • small molecule binding • G protein-coupled amine receptor activity • G protein-coupled serotonin receptor activity • molecular transducer activity • G protein-coupled receptor activity • transmembrane signaling receptor activity • signaling receptor activity • Gi/o-coupled serotonin receptor activity • neurotransmitter receptor activity • serotonin receptor activity • signaling receptor binding • receptor-receptor interaction • tetrapyrrole binding • heme binding • electron transfer activity • transition metal ion binding • iron ion binding • metal ion binding • adenylate cyclase-inhibiting serotonin receptor signaling pathway • G protein-coupled serotonin receptor signaling pathway • adenylate cyclase-inhibiting G protein-coupled receptor signaling pathway • behavior • exploration behavior • regulation of amine metabolic process • dopamine metabolic process • primary metabolic process • catechol-containing compound metabolic process • regulation of primary metabolic process • amine metabolic process • catecholamine metabolic process • phenol-containing compound metabolic process • metabolic process • regulation of catecholamine metabolic process • regulation of metabolic process • biogenic amine metabolic process • regulation of dopamine metabolic process • regulation of tube diameter • regulation of tube size • regulation of system process • circulatory system process • regulation of blood circulation • regulation of vasoconstriction • vascular process in circulatory system • regulation of multicellular organismal process • blood vessel diameter maintenance • regulation of biological quality • blood circulation • vasoconstriction • regulation of anatomical structure size • gamma-aminobutyric acid signaling pathway • regulation of behavior • serotonin metabolic process • indole-containing compound metabolic process • serotonin receptor signaling pathway • positive regulation of cell population proliferation • regulation of cell population proliferation • positive regulation of biological process • positive regulation of cellular process • regulation of localization • regulation of hormone secretion • transport • hormone secretion • localization • regulation of secretion by cell • secretion by cell • signal release • regulation of signaling • regulation of transport • secretion • regulation of hormone levels • export from cell • establishment of localization • regulation of secretion • regulation of cell communication • hormone transport • monoamine transport • nitrogen compound transport • organic hydroxy compound transport • monoatomic ion transport • serotonin secretion • regulation of monoatomic ion transport • regulation of serotonin secretion • serotonin transport • trans-synaptic signaling • anterograde trans-synaptic signaling • chemical synaptic transmission • behavioral defense response • fear response • behavioral fear response • defense response • response to stress • multicellular organismal response to stress • G protein-coupled receptor signaling pathway, coupled to cyclic nucleotide second messenger • electron transport chain • generation of precursor metabolites and energy • somatodendritic compartment • dendrite • dendritic tree • periplasmic space
SCOP2	Domain Identifier	• Ras-like P-loop GTPases
SCOP2	Family Identifier	• Ras-like P-loop GTPases
Membrane Protein Annotations	-	• Orientations of Proteins in Membranes database (OPM) • Protein Data Bank of Transmembrane Proteins (PDBTM) • MemProtMD

Details about the values in these tables can be found in the corresponding documentation page .


PDBsum	Open PDBsum Page
Chain	A
Protein	G Protein α Sub unit
UniProt	P63096
Sequence	>7E2X_Chain_A T L S A E D K A A V E R S K M I D R N L R E D G E K A A R E V K L L L L G A G E S G K N T I V K Q M K I T G I V E T H F T F K D L H F K M F D V G A Q R S E R K K W I H C F E G V T A I I F C V A L S D Y D L V L N R M H A S M K L F D S I C N N K W F T D T S I I L F L N K K D L F E E K I K K S P L T I C Y P E Y A G S N T Y E E A A A Y I Q C Q F E D L N K R K D T K E I Y T H F T C S T D T K N V Q F V F D A V T D V I I K N N L K D C G L F Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

Chain	G
Protein	G Protein γ Sub unit
UniProt	P59768
Sequence	>7E2X_Chain_G Q L K M E A N I D R I K V S K A A A D L M A Y C E A H A K E D P L L T P V P A S E N P F R Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

Chain	R
Protein	Receptor
UniProt	P08908
Sequence	>7E2X_Chain_R Y Q V I T S L L L G T L I F C A V L G N A C V V A A I A L E R S L Q N V A N Y L I G S L A V T D L M V S V L V L P M A A L Y Q V L N K W T L G Q V T C D L F I A L D V L C C T S S I W H L C A I A L D R Y W A I T D P I D Y V N K R T P R R A A A L I S L T W L I G F L I S I P P M L G W P D A C T I S K D H G Y T I Y S T F G A F Y I P L L L M L V L Y G R I F R A A R F R I R K K N E R N A E A K R K M A L A R E R K T V K T L G I I M G T F I L C W L P F F I V A L V L P F C E S S C H M P T L L G A I I N W L G Y S N S L L N P V I Y A Y F N K D F Q N A F K K I I Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

Chain	B
Protein	G Protein β Sub unit
UniProt	P62873
Sequence	>7E2X_Chain_B Q L K N Q I R D A R K A C A D A T L S Q I T N N I D P V G R I Q M R T R R T L R G H L A K I Y A M H W G T D S R L L V S A S Q D G K L I I W D S Y T T N K V H A I P L R S S W V M T C A Y A P S G N Y V A C G G L D N I C S I Y N L K T R E G N V R V S R E L A G H T G Y L S C C R F L D D N Q I V T S S G D T T C A L W D I E T G Q Q T T T F T G H T G D V M S L S L A P D T R L F V S G A C D A S A K L W D V R E G M C R Q T F T G H E S D I N A I C F F P N G N A F A T G S D D A T C R L F D L R A D Q E L M T Y S H D N I I C G I T S V S F S K S G R L L L A G Y D D F N C N V W D A L K A D R A G V L A G H D N R V S C L G V T D D G M A V A T G S W D S F L K I W N Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

This receptor, from the same or other species and bound to the same or other ligands, is also present in the following networks:
Show	PDB	Class	SubFamily	Type	SubType	Species	Orthosteric Ligand	Other Ligand(s)	Protein Partners	Resolution	Date	DOI
	7E2X (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	-	-		3	2021-04-14	doi.org/10.1038/s41586-021-03376-8
	7E2Y	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Serotonin	-	Gi1/β1/γ2	3	2021-04-14	doi.org/10.1038/s41586-021-03376-8
	7E2Y (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Serotonin	-		3	2021-04-14	doi.org/10.1038/s41586-021-03376-8
	7E2Z	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Aripiprazole	-	Gi1/β1/γ2	3.1	2021-04-14	doi.org/10.1038/s41586-021-03376-8
	7E2Z (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Aripiprazole	-		3.1	2021-04-14	doi.org/10.1038/s41586-021-03376-8
	8W8B	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	SEP-363856	-	Gi1/β1/γ2	3	2023-11-22	doi.org/10.1038/s41586-023-06775-1
	8W8B (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	SEP-363856	-		3	2023-11-22	doi.org/10.1038/s41586-023-06775-1
	8JSP	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Ulotaront	-	Gi1/β1/γ2	3.65	2023-11-15	doi.org/10.1038/s41586-023-06804-z
	8JSP (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Ulotaront	-		3.65	2023-11-15	doi.org/10.1038/s41586-023-06804-z
	8FY8	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	5-MeO-DMT	-	Gi1/β1/γ1	2.79	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FY8 (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	5-MeO-DMT	-		2.79	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYE	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	4-F,5-MeO-PyrT	-	Gi1/β1/γ1	2.85	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYE (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	4-F,5-MeO-PyrT	-		2.85	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYL	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Vilazodone	-	Gi1/β1/γ1	2.94	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYL (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Vilazodone	-		2.94	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYT	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	LSD	-	Gi1/β1/γ1	2.64	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYT (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	LSD	-		2.64	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYX	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Buspirone	-	Gi1/β1/γ1	2.72	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8FYX (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Buspirone	-		2.72	2024-05-15	doi.org/10.1038/s41586-024-07403-2
	8JT6	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	(R)-IHCH-7179	-	Gi1/β1/γ2	3	2024-02-28	doi.org/10.1016/j.cell.2024.02.034
	8JT6 (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	(R)-IHCH-7179	-		3	2024-02-28	doi.org/10.1016/j.cell.2024.02.034
	8PJK	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	ST171	-	Gi1/β1/γ1	2.4	2024-05-29	doi.org/10.1126/sciadv.adv9267
	8PJK (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	ST171	-		2.4	2024-05-29	doi.org/10.1126/sciadv.adv9267
	8PKM	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Befiradol	-	Gi1/β1/γ1	2.9	2024-05-29	doi.org/10.1126/sciadv.adv9267
	8PKM (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Befiradol	-		2.9	2024-05-29	doi.org/10.1126/sciadv.adv9267
	9GL2	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Befiradol	-	Gs/β1/γ2	3.2	2025-07-02	doi.org/10.1126/sciadv.adv9267
	9GL2 (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Befiradol	-		3.2	2025-07-02	doi.org/10.1126/sciadv.adv9267
	9DYF	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Asenapine	-	Gi1/β1/γ2	2.74	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9DYF (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Asenapine	-		2.74	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9DYD	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Asenapine	-	Go/β1/γ2	2.96	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9DYD (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Asenapine	-		2.96	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9DYE	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Buspirone	-	Go/β1/γ2	2.9	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9DYE (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Buspirone	-		2.9	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9MD1	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Buspirone	-	Gz/β1/γ2	3.03	2025-08-13	doi.org/10.1126/sciadv.adu9851
	9MD1 (No Gprot)	A	Amine	5-Hydroxytryptamine	5-HT_1A	Homo sapiens	Buspirone	-		3.03	2025-08-13	doi.org/10.1126/sciadv.adu9851

You can download a compressed (zip) file with structure(s), 3D outputs (as PyMol and VMD scripts) and numerical data files (as csv and plain text files).

Download 7E2X.zip

You can click to copy the link of this page to easily come back here later

or use this QR code to link and share this page.

You can also read or download a guide explaining the meaning of all files and numerical data.
