psnGPCR

Press and hold down the left mouse button and move the mouse to rotate.
Press and hold down the central mouse button and move the mouse to translate.
Use the mouse wheel to zoom in or out.
Click on any atom on your molecule and the corresponding residue label will be placed beneath the viewer.

Color	ConSurf Grade
	No Conservation data available
	1
	2
	3
	4
	5
	6
	7
	8
	9

Index: link id, click on each number to highlight the corresponding link in the 3D visualization.

Node1 Node2: the two nodes of the corresponding link.

Int. Strength: the interaction strength between the two nodes.

Hub1?, Hub2?: "Yes" if the corresponding node has more than 3 links, otherwise "No".

Community: the id of the community the link belong to, otherwise 0.

ConSurf1, ConSurf2: these columns report the ConSurf conservation grades of the two nodes involved in a link.

Index	Node1	Node2	Int. Strength	Hub1?	Hub2?	Community	ConSurf1	ConSurf2
1	A:A:K17	A:A:L12	5.64	No	No	0	4	2
2	A:A:D16	A:A:S13	7.36	No	No	0	5	7
3	A:A:S23	B:B:N88	4.47	No	Yes	0	7	7
4	A:A:S23	B:B:K89	4.59	No	Yes	0	7	9
5	A:A:I26	B:B:K89	7.27	No	Yes	0	9	9
6	A:A:E27	B:B:K89	8.1	No	Yes	0	6	9
7	A:A:L30	B:B:K78	2.82	No	No	0	5	8
8	A:A:L30	B:B:K89	2.82	No	Yes	0	5	9
9	A:A:K34	A:A:Q31	2.71	No	No	0	4	4
10	A:A:K32	A:A:Q35	2.71	No	No	0	4	3
11	A:A:D33	B:B:L55	6.79	No	No	0	5	6
12	A:A:K34	B:B:L55	7.05	No	No	0	4	6
13	A:A:Q35	R:R:R130	8.18	No	No	0	3	6
14	A:A:R42	A:A:Y37	20.58	No	No	0	9	4
15	A:A:H220	A:A:T40	6.85	Yes	No	0	7	7
16	A:A:F219	A:A:H41	7.92	Yes	No	0	8	6
17	A:A:H41	A:A:T242	4.11	No	No	0	6	8
18	A:A:H41	R:R:L123	3.86	No	Yes	0	6	6
19	A:A:F222	A:A:R42	3.21	Yes	No	0	7	9
20	A:A:I245	A:A:L43	4.28	No	No	0	7	7
21	A:A:F238	A:A:L44	9.74	Yes	No	0	9	9
22	A:A:I244	A:A:L44	4.28	Yes	No	0	8	9
23	A:A:K53	A:A:L45	4.23	No	Yes	0	9	8
24	A:A:L45	A:A:M221	7.07	Yes	No	15	8	8
25	A:A:I245	A:A:L45	2.85	No	Yes	15	7	8
26	A:A:L46	A:A:R231	8.5	No	Yes	0	8	9
27	A:A:I276	A:A:L46	2.85	No	No	0	8	8
28	A:A:D49	A:A:N50	2.69	No	Yes	0	8	9
29	A:A:D249	A:A:N50	12.12	No	Yes	10	8	9
30	A:A:D252	A:A:N50	10.77	No	Yes	10	8	9
31	A:A:N50	A:A:R265	6.03	Yes	No	10	9	9
32	A:A:S51	A:A:V247	4.85	No	No	0	9	7
33	A:A:S366	A:A:T55	9.59	No	No	0	9	9
34	A:A:I56	A:A:N292	4.25	No	Yes	0	7	9
35	A:A:T210	A:A:V57	4.76	No	No	0	7	7
36	A:A:I62	A:A:Q59	4.12	No	No	0	9	9
37	A:A:Q59	A:A:Y63	3.38	No	No	0	9	9
38	A:A:F212	A:A:M60	22.39	Yes	No	0	9	9
39	A:A:R61	A:A:T210	21.99	No	No	0	8	7
40	A:A:H64	A:A:Y63	8.71	No	No	0	8	9
41	A:A:T369	A:A:Y63	6.24	No	No	0	9	9
42	A:A:A372	A:A:H64	2.93	No	No	0	8	8
43	A:A:K203	A:A:T204	4.5	No	No	0	7	9
44	A:A:F208	A:A:S205	5.28	No	No	0	5	7
45	A:A:G206	B:B:N119	5.09	No	No	0	8	9
46	A:A:I207	B:B:W99	3.52	No	Yes	1	9	9
47	A:A:I207	B:B:L117	2.85	No	No	1	9	9
48	A:A:D223	A:A:F208	7.17	No	No	0	9	5
49	A:A:E209	A:A:K211	18.9	No	No	1	9	4
50	A:A:E209	A:A:H220	11.08	No	Yes	1	9	7
51	A:A:E209	A:A:F222	5.83	No	Yes	1	9	7
52	A:A:H220	A:A:K211	11.79	Yes	No	1	7	4
53	A:A:F212	A:A:F219	10.72	Yes	Yes	0	9	8
54	A:A:F212	A:A:M221	3.73	Yes	No	0	9	8
55	A:A:A372	A:A:F212	2.77	No	Yes	0	8	9
56	A:A:K216	A:A:Q213	2.71	No	No	0	4	3
57	A:A:N218	A:A:Q213	2.64	No	No	0	4	3
58	A:A:F219	A:A:V214	2.62	Yes	No	0	8	6
59	A:A:R373	A:A:V214	3.92	No	No	0	5	6
60	A:A:F376	A:A:V214	3.93	Yes	No	0	8	6
61	A:A:D215	A:A:R373	3.57	No	No	0	5	5
62	A:A:D215	A:A:F376	5.97	No	Yes	0	5	8
63	A:A:K216	R:R:R124	3.71	No	No	0	4	4
64	A:A:F219	A:A:V217	3.93	Yes	Yes	0	8	5
65	A:A:F376	A:A:V217	3.93	Yes	Yes	5	8	5
66	A:A:V217	R:R:L123	4.47	Yes	Yes	5	5	6
67	A:A:V217	R:R:R124	2.62	Yes	No	0	5	4
68	A:A:C379	A:A:F219	4.19	No	Yes	0	8	8
69	A:A:F222	A:A:H220	4.53	Yes	Yes	1	7	7
70	A:A:I245	A:A:M221	2.92	No	No	15	7	8
71	A:A:F222	B:B:W99	10.02	Yes	Yes	1	7	9
72	A:A:Q227	A:A:V224	4.3	Yes	No	1	9	9
73	A:A:V224	A:A:W234	9.81	No	Yes	1	9	9
74	A:A:Q227	A:A:W234	3.29	Yes	Yes	1	9	9
75	A:A:Q227	B:B:N119	3.96	Yes	No	0	9	9
76	A:A:Q227	B:B:Y145	7.89	Yes	Yes	1	9	8
77	A:A:E230	A:A:R228	3.49	No	No	0	9	9
78	A:A:R228	B:B:D186	5.96	No	Yes	0	9	9
79	A:A:R231	A:A:W234	5	Yes	Yes	1	9	9
80	A:A:I235	A:A:R231	3.76	Yes	Yes	1	9	9
81	A:A:D272	A:A:R231	3.57	No	Yes	0	8	9
82	A:A:R232	B:B:C204	2.79	No	Yes	1	8	7
83	A:A:R232	B:B:D228	11.91	No	No	1	8	9
84	A:A:K233	B:B:Y145	3.58	Yes	Yes	1	9	8
85	A:A:K233	B:B:D186	2.77	Yes	Yes	1	9	9
86	A:A:K233	B:B:M188	8.64	Yes	No	1	9	8
87	A:A:K233	B:B:C204	4.85	Yes	Yes	1	9	7
88	A:A:K233	B:B:D228	8.3	Yes	No	1	9	9
89	A:A:K233	B:B:N230	5.6	Yes	No	0	9	9
90	A:A:I235	A:A:W234	3.52	Yes	Yes	1	9	9
91	A:A:F238	A:A:W234	4.01	Yes	Yes	0	9	9
92	A:A:W234	B:B:Y145	2.89	Yes	Yes	1	9	8
93	A:A:I235	A:A:N279	4.25	Yes	No	1	9	8
94	A:A:I235	A:A:L282	4.28	Yes	No	1	9	9
95	A:A:Q236	A:A:W281	19.71	No	Yes	1	8	5
96	A:A:Q236	B:B:R314	4.67	No	Yes	1	8	8
97	A:A:C237	B:B:Y59	5.38	No	Yes	1	8	8
98	A:A:C237	B:B:Q75	3.05	No	Yes	1	8	9
99	A:A:C237	B:B:W99	2.61	No	Yes	1	8	9
100	A:A:F238	A:A:V241	3.93	Yes	No	0	9	9
101	A:A:F238	B:B:W99	12.03	Yes	Yes	0	9	9
102	A:A:N239	B:B:K57	8.39	No	Yes	1	8	9
103	A:A:N239	B:B:W332	5.65	No	Yes	1	8	9
104	A:A:D240	B:B:K57	9.68	No	Yes	0	6	9
105	A:A:C379	A:A:T242	3.38	No	No	0	8	8
106	A:A:A243	A:A:I288	3.25	No	Yes	0	8	9
107	A:A:I244	A:A:L282	4.28	Yes	No	0	8	9
108	A:A:I244	A:A:I285	2.94	Yes	No	0	8	7
109	A:A:I244	A:A:V287	3.07	Yes	No	0	8	6
110	A:A:F246	A:A:V248	2.62	No	Yes	0	9	7
111	A:A:F290	A:A:V247	2.62	Yes	No	0	9	7
112	A:A:N292	A:A:V247	2.96	Yes	No	0	9	7
113	A:A:L291	A:A:V248	2.98	No	Yes	0	8	7
114	A:A:F345	A:A:V248	6.55	No	Yes	0	8	7
115	A:A:D249	A:A:D252	6.65	No	No	10	8	8
116	A:A:D249	A:A:K293	11.06	No	No	0	8	9
117	A:A:Q294	A:A:S250	4.33	Yes	No	8	6	6
118	A:A:L297	A:A:S250	6.01	No	No	8	8	6
119	A:A:L296	A:A:S251	7.51	No	No	0	6	9
120	A:A:K300	A:A:S251	3.06	No	No	0	9	9
121	A:A:D252	A:A:R265	4.76	No	No	10	8	9
122	A:A:K300	A:A:Y253	5.97	No	No	0	9	8
123	A:A:I308	A:A:Y253	8.46	No	No	0	7	8
124	A:A:F312	A:A:L266	4.87	Yes	No	0	8	8
125	A:A:I341	A:A:L266	4.28	No	No	0	8	8
126	A:A:L270	A:A:Q267	2.66	Yes	No	0	6	4
127	A:A:N271	A:A:Q267	3.96	No	No	0	5	4
128	A:A:E344	A:A:L270	2.65	No	Yes	0	5	6
129	A:A:F345	A:A:L270	10.96	No	Yes	0	8	6
130	A:A:I348	A:A:L270	5.71	No	Yes	0	4	6
131	A:A:F273	A:A:F345	5.36	No	No	0	9	8
132	A:A:F273	A:A:I348	5.02	No	No	0	9	4
133	A:A:F273	A:A:S349	2.64	No	Yes	0	9	7
134	A:A:I348	A:A:K274	14.54	No	No	0	4	5
135	A:A:V287	A:A:W277	4.9	No	Yes	0	6	6
136	A:A:H357	A:A:W277	22.22	No	Yes	0	7	6
137	A:A:C359	A:A:W277	2.61	No	Yes	0	5	6
138	A:A:N278	A:A:S352	4.47	No	No	0	8	5
139	A:A:L282	A:A:N279	5.49	No	No	1	9	8
140	A:A:W281	B:B:D290	4.47	Yes	Yes	1	5	6
141	A:A:W281	B:B:R314	6	Yes	Yes	1	5	8
142	A:A:W281	B:B:W332	3.75	Yes	Yes	1	5	9
143	A:A:R356	A:A:T284	9.06	No	No	0	2	4
144	A:A:I382	A:A:S286	7.74	No	No	0	6	8
145	A:A:F290	A:A:I288	3.77	Yes	Yes	2	9	9
146	A:A:H362	A:A:I288	2.65	No	Yes	2	9	9
147	A:A:D378	A:A:I288	11.2	Yes	Yes	2	7	9
148	A:A:L289	A:A:L291	4.15	No	No	0	9	8
149	A:A:C359	A:A:L289	3.17	No	No	0	5	9
150	A:A:F290	A:A:H362	6.79	Yes	No	2	9	9
151	A:A:F290	A:A:T364	3.89	Yes	Yes	2	9	9
152	A:A:F290	A:A:N371	6.04	Yes	Yes	2	9	9
153	A:A:F363	A:A:L291	4.87	Yes	No	0	5	8
154	A:A:K293	A:A:N292	5.6	No	Yes	0	9	9
155	A:A:N292	A:A:T364	4.39	Yes	Yes	0	9	9
156	A:A:N292	A:A:S366	5.96	Yes	No	0	9	9
157	A:A:K293	A:A:L296	2.82	No	No	0	9	6
158	A:A:L297	A:A:Q294	5.32	No	Yes	8	8	6
159	A:A:K338	A:A:Q294	5.42	Yes	Yes	8	5	6
160	A:A:F363	A:A:Q294	8.2	Yes	Yes	8	5	6
161	A:A:K300	A:A:S306	4.59	No	No	0	9	7
162	A:A:V301	A:A:V334	3.21	No	Yes	0	7	4
163	A:A:D331	A:A:L302	4.07	Yes	No	0	4	2
164	A:A:K305	A:A:S306	3.06	No	No	0	3	7
165	A:A:D310	A:A:K307	2.77	No	No	0	3	6
166	A:A:F315	A:A:I308	7.54	Yes	No	0	6	7
167	A:A:E309	A:A:F315	10.49	No	Yes	0	4	6
168	A:A:A316	A:A:E309	4.53	No	No	0	2	4
169	A:A:D310	A:A:Y311	12.64	No	No	0	3	6
170	A:A:F312	A:A:F340	4.29	Yes	Yes	0	8	7
171	A:A:E314	A:A:P313	3.14	No	No	0	6	6
172	A:A:F315	A:A:R336	9.62	Yes	No	0	6	5
173	A:A:F315	A:A:F340	8.57	Yes	Yes	0	6	7
174	A:A:P321	A:A:Y318	4.17	No	Yes	0	5	6
175	A:A:R336	A:A:Y318	3.09	No	Yes	0	5	6
176	A:A:F340	A:A:Y318	8.25	Yes	Yes	0	7	6
177	A:A:D343	A:A:Y318	10.34	No	Yes	0	3	6
178	A:A:P321	A:A:T320	3.5	No	No	0	5	1
179	A:A:R336	A:A:T320	3.88	No	No	0	5	1
180	A:A:P321	A:A:Y339	2.78	No	Yes	0	5	3
181	A:A:A324	A:A:Y339	8.01	No	Yes	0	3	3
182	A:A:E327	A:A:P328	4.72	No	No	0	4	1
183	A:A:E330	A:A:P328	4.72	Yes	No	0	3	1
184	A:A:E330	A:A:V334	7.13	Yes	Yes	0	3	4
185	A:A:E330	A:A:T335	4.23	Yes	No	0	3	4
186	A:A:E330	A:A:K338	4.05	Yes	Yes	0	3	5
187	A:A:D331	A:A:P332	11.27	Yes	No	0	4	1
188	A:A:D331	A:A:R333	11.91	Yes	No	0	4	5
189	A:A:K338	A:A:Y339	3.58	Yes	Yes	0	5	3
190	A:A:F363	A:A:K338	7.44	Yes	Yes	8	5	5
191	A:A:R342	A:A:Y339	7.2	Yes	Yes	0	4	3
192	A:A:E344	A:A:F340	8.16	No	Yes	0	5	7
193	A:A:D343	A:A:R342	4.76	No	Yes	0	3	4
194	A:A:P361	A:A:R342	4.32	No	Yes	0	5	4
195	A:A:F363	A:A:R342	6.41	Yes	Yes	0	5	4
196	A:A:E344	A:A:R347	10.47	No	No	0	5	4
197	A:A:L346	A:A:S349	4.5	No	Yes	0	4	7
198	A:A:L346	A:A:P361	6.57	No	No	0	4	5
199	A:A:S349	A:A:T350	4.8	Yes	No	0	7	4
200	A:A:C359	A:A:S349	6.89	No	Yes	0	5	7
201	A:A:R356	A:A:R389	6.4	No	No	0	2	4
202	A:A:Y358	A:A:Y360	12.91	No	Yes	2	4	8
203	A:A:Y358	R:R:S213	6.36	No	Yes	2	4	3
204	A:A:D378	A:A:Y360	13.79	Yes	Yes	2	7	8
205	A:A:D381	A:A:Y360	5.75	Yes	Yes	2	8	8
206	A:A:I382	A:A:Y360	7.25	No	Yes	2	6	8
207	A:A:Y360	R:R:S213	5.09	Yes	Yes	2	8	3
208	A:A:H362	A:A:R374	7.9	No	Yes	2	9	4
209	A:A:D368	A:A:T364	4.34	Yes	Yes	2	9	9
210	A:A:N371	A:A:T364	7.31	Yes	Yes	2	9	9
211	A:A:R374	A:A:T364	5.17	Yes	Yes	2	4	9
212	A:A:D368	A:A:E370	5.2	Yes	No	0	9	4
213	A:A:D368	A:A:N371	10.77	Yes	Yes	2	9	9
214	A:A:D368	A:A:R374	5.96	Yes	Yes	2	9	4
215	A:A:N371	A:A:R374	4.82	Yes	Yes	2	9	4
216	A:A:N377	A:A:R373	4.82	No	No	0	4	5
217	A:A:F376	A:A:R380	4.28	Yes	No	5	8	7
218	A:A:F376	R:R:L123	3.65	Yes	Yes	5	8	6
219	A:A:C379	A:A:D378	3.11	No	Yes	0	8	7
220	A:A:D378	A:A:I382	8.4	Yes	No	2	7	6
221	A:A:R380	R:R:P122	2.88	No	No	5	7	7
222	A:A:R380	R:R:L123	4.86	No	Yes	5	7	6
223	A:A:D381	A:A:Q384	3.92	Yes	No	0	8	6
224	A:A:D381	R:R:S211	5.89	Yes	No	2	8	5
225	A:A:D381	R:R:V212	4.38	Yes	No	0	8	3
226	A:A:D381	R:R:S213	5.89	Yes	Yes	2	8	3
227	A:A:H387	A:A:I383	6.63	Yes	Yes	5	8	8
228	A:A:I383	R:R:P122	3.39	Yes	No	5	8	7
229	A:A:I383	R:R:L123	4.28	Yes	Yes	5	8	6
230	A:A:R385	A:A:R389	8.53	Yes	No	0	5	4
231	A:A:L394	A:A:R385	3.64	No	Yes	2	8	5
232	A:A:R385	R:R:S213	2.64	Yes	Yes	2	5	3
233	A:A:R385	R:R:T214	3.88	Yes	Yes	2	5	3
234	A:A:R385	R:R:E218	5.82	Yes	No	2	5	5
235	A:A:H387	R:R:A118	2.93	Yes	No	0	8	8
236	A:A:H387	R:R:P122	3.05	Yes	No	5	8	7
237	A:A:H387	R:R:R129	3.39	Yes	Yes	5	8	7
238	A:A:L388	A:A:L393	2.77	Yes	No	0	8	8
239	A:A:L388	A:A:L394	4.15	Yes	No	0	8	8
240	A:A:L388	R:R:V119	4.47	Yes	No	0	8	8
241	A:A:L388	R:R:V208	2.98	Yes	No	0	8	8
242	A:A:Q390	A:A:Y391	11.27	No	Yes	0	4	4
243	A:A:Q390	R:R:N50	6.6	No	No	0	4	7
244	A:A:Y391	R:R:E51	3.37	Yes	Yes	5	4	7
245	A:A:Y391	R:R:D114	5.75	Yes	No	5	4	8
246	A:A:Y391	R:R:A118	9.34	Yes	No	0	4	8
247	A:A:Y391	R:R:R129	5.14	Yes	Yes	5	4	7
248	A:A:E392	R:R:Q45	6.37	No	No	0	6	5
249	A:A:E392	R:R:L52	2.65	No	No	0	6	8
250	A:A:E392	R:R:N290	11.83	No	No	0	6	8
251	A:A:L393	R:R:R115	3.64	No	No	0	8	9
252	A:A:L393	R:R:I204	2.85	No	No	0	8	6
253	A:A:L394	R:R:E218	5.3	No	No	2	8	5
254	B:B:E3	B:B:Q6	3.82	No	No	0	5	1
255	B:B:D5	B:B:Q9	10.44	No	No	0	1	3
256	B:B:E10	B:B:Q6	8.92	No	No	0	8	1
257	B:B:E10	B:B:L7	2.65	No	Yes	0	8	8
258	B:B:L7	G:G:A12	4.73	Yes	No	0	8	5
259	B:B:L7	G:G:V16	2.98	Yes	No	0	8	7
260	B:B:E12	B:B:R8	12.79	No	No	0	4	3
261	B:B:L14	B:B:Q17	3.99	Yes	No	0	8	4
262	B:B:L14	G:G:L19	11.07	Yes	No	0	8	9
263	B:B:L14	G:G:A23	3.15	Yes	No	0	8	8
264	B:B:N16	B:B:R19	3.62	No	No	0	1	4
265	B:B:I18	G:G:L19	2.85	No	No	0	7	9
266	B:B:I18	G:G:E22	4.1	No	No	0	7	9
267	B:B:I18	G:G:A23	3.25	No	No	0	7	8
268	B:B:R19	B:B:R22	4.26	No	No	0	4	6
269	B:B:D258	B:B:R22	3.57	Yes	No	0	7	6
270	B:B:Q259	B:B:R22	4.67	No	No	0	6	6
271	B:B:C25	G:G:R27	4.18	No	Yes	0	3	8
272	B:B:A26	B:B:Q259	4.55	No	No	0	3	6
273	B:B:A28	B:B:D27	3.09	No	Yes	0	4	8
274	B:B:D27	G:G:K29	8.3	Yes	No	0	8	4
275	B:B:D27	G:G:V30	2.92	Yes	No	0	8	8
276	B:B:D27	G:G:S31	4.42	Yes	No	0	8	9
277	B:B:L30	B:B:T34	2.95	No	Yes	0	5	5
278	B:B:L261	B:B:L30	4.15	No	No	0	5	5
279	B:B:L30	B:B:M262	9.9	No	Yes	0	5	4
280	B:B:M262	B:B:S31	3.07	Yes	No	0	4	1
281	B:B:I33	B:B:Q32	5.49	No	No	0	3	1
282	B:B:I37	B:B:T34	4.56	No	Yes	16	2	5
283	B:B:K301	B:B:T34	3	No	Yes	0	5	5
284	B:B:T34	G:G:M38	3.01	Yes	No	16	5	4
285	B:B:I37	G:G:M38	5.83	No	No	16	2	4
286	B:B:D38	B:B:P39	6.44	No	No	0	1	1
287	B:B:K301	B:B:P39	8.36	No	No	0	5	1
288	B:B:G41	B:B:V40	3.68	No	Yes	0	1	3
289	B:B:I43	B:B:V40	3.07	No	Yes	0	3	3
290	B:B:R283	B:B:V40	7.85	Yes	Yes	11	9	3
291	B:B:D298	B:B:V40	4.38	Yes	Yes	11	9	3
292	B:B:Q44	B:B:R42	4.67	No	No	0	4	2
293	B:B:I43	B:B:M45	2.92	No	No	0	3	4
294	B:B:I43	B:B:L284	4.28	No	No	0	3	5
295	B:B:L308	B:B:M45	2.83	No	No	0	7	4
296	B:B:M45	G:G:L50	7.07	No	No	0	4	9
297	B:B:R46	B:B:R48	3.2	No	No	0	5	7
298	B:B:K337	B:B:T47	3	Yes	No	0	6	3
299	B:B:N340	B:B:R48	3.62	No	No	0	9	7
300	B:B:R49	G:G:F61	9.62	No	Yes	0	7	8
301	B:B:R52	B:B:T50	10.35	No	No	0	7	3
302	B:B:K337	B:B:T50	3	Yes	No	0	6	3
303	B:B:L51	B:B:W82	15.94	Yes	Yes	0	9	9
304	B:B:L51	B:B:T87	2.95	Yes	No	0	9	5
305	B:B:L336	B:B:L51	6.92	No	Yes	0	7	9
306	B:B:I338	B:B:L51	4.28	No	Yes	0	5	9
307	B:B:F335	B:B:R52	3.21	No	No	0	4	7
308	B:B:H54	B:B:I58	6.63	Yes	No	0	9	9
309	B:B:H54	B:B:S72	6.97	Yes	No	12	9	9
310	B:B:H54	B:B:S74	5.58	Yes	No	0	9	9
311	B:B:H54	B:B:I80	11.93	Yes	No	12	9	8
312	B:B:H54	B:B:W82	3.17	Yes	Yes	12	9	9
313	B:B:D76	B:B:L55	9.5	Yes	No	0	9	6
314	B:B:K57	B:B:Q75	4.07	Yes	Yes	1	9	9
315	B:B:K57	B:B:W332	11.6	Yes	Yes	1	9	9
316	B:B:Q75	B:B:Y59	9.02	Yes	Yes	1	9	8
317	B:B:M101	B:B:Y59	4.79	No	Yes	0	9	8
318	B:B:W332	B:B:Y59	12.54	Yes	Yes	1	9	8
319	B:B:A60	B:B:C103	3.61	No	No	0	7	8
320	B:B:C317	B:B:M61	6.48	No	No	0	7	6
321	B:B:G319	B:B:M61	3.49	No	No	0	5	6
322	B:B:A328	B:B:M61	3.22	No	No	0	5	6
323	B:B:H62	B:B:R150	12.41	No	No	0	6	6
324	B:B:L70	B:B:W63	10.25	No	Yes	0	5	7
325	B:B:S84	B:B:W63	4.94	No	Yes	0	5	7
326	B:B:G319	B:B:W63	2.81	No	Yes	0	5	7
327	B:B:T321	B:B:W63	4.85	Yes	Yes	0	7	7
328	B:B:A328	B:B:W63	3.89	No	Yes	0	5	7
329	B:B:D66	B:B:R68	3.57	No	No	0	8	5
330	B:B:D66	B:B:L69	8.14	No	No	0	8	5
331	B:B:S67	B:B:T321	6.4	No	Yes	13	5	7
332	B:B:D322	B:B:S67	4.42	No	No	13	1	5
333	B:B:D323	B:B:S67	10.31	No	No	13	7	5
334	B:B:D83	B:B:R68	11.91	Yes	No	0	8	5
335	B:B:R68	B:B:Y85	25.72	No	Yes	0	5	4
336	B:B:D83	B:B:L69	2.71	Yes	No	0	8	5
337	B:B:L69	B:B:Y105	5.86	No	Yes	0	5	6
338	B:B:L70	B:B:W82	4.56	No	Yes	0	5	9
339	B:B:S72	B:B:W82	4.94	No	Yes	12	9	9
340	B:B:L336	B:B:S72	3	No	No	0	7	9
341	B:B:A73	B:B:V100	3.39	No	No	0	9	9
342	B:B:D76	B:B:S74	10.31	Yes	No	0	9	9
343	B:B:Q75	B:B:W99	5.48	Yes	Yes	1	9	9
344	B:B:D76	B:B:K78	5.53	Yes	No	0	9	8
345	B:B:K78	B:B:P94	5.02	No	No	0	8	5
346	B:B:I93	B:B:L79	4.28	Yes	No	0	7	7
347	B:B:L79	B:B:L95	2.77	No	Yes	0	7	8
348	B:B:I80	B:B:W82	14.09	No	Yes	12	8	9
349	B:B:I81	B:B:V90	4.61	No	No	19	7	5
350	B:B:H91	B:B:I81	6.63	No	No	19	5	7
351	B:B:I81	B:B:L126	2.85	No	No	0	7	5
352	B:B:K89	B:B:W82	5.8	Yes	Yes	0	9	9
353	B:B:D83	B:B:T86	10.12	Yes	No	14	8	6
354	B:B:D83	B:B:N88	2.69	Yes	Yes	14	8	7
355	B:B:S84	B:B:Y85	5.09	No	Yes	18	5	4
356	B:B:S84	G:G:F61	5.28	No	Yes	18	5	8
357	B:B:Y85	G:G:P60	16.69	Yes	No	0	4	9
358	B:B:Y85	G:G:F61	5.16	Yes	Yes	18	4	8
359	B:B:N88	B:B:T86	10.24	Yes	No	14	7	6
360	B:B:H91	B:B:V90	4.15	No	No	19	5	5
361	B:B:H91	B:B:V133	4.15	No	No	0	5	4
362	B:B:I93	B:B:P94	3.39	Yes	No	0	7	5
363	B:B:I93	B:B:Y124	4.84	Yes	Yes	0	7	6
364	B:B:I93	B:B:V133	6.14	Yes	No	0	7	4
365	B:B:L95	B:B:V100	4.47	Yes	No	0	8	9
366	B:B:C114	B:B:L95	4.76	No	Yes	7	8	8
367	B:B:L95	B:B:Y124	5.86	Yes	Yes	7	8	6
368	B:B:R96	B:B:V135	2.62	No	No	7	6	4
369	B:B:E138	B:B:R96	5.82	No	No	7	6	6
370	B:B:D118	B:B:S97	8.83	No	No	0	9	8
371	B:B:S98	B:B:W99	7.41	No	Yes	0	8	9
372	B:B:L117	B:B:W99	5.69	No	Yes	1	9	9
373	B:B:G116	B:B:M101	3.49	No	No	0	9	9
374	B:B:M101	B:B:Y145	4.79	No	Yes	0	9	8
375	B:B:C148	B:B:T102	3.38	No	No	0	6	8
376	B:B:C149	B:B:T102	5.07	Yes	No	0	8	8
377	B:B:G109	B:B:Y105	2.9	No	Yes	0	5	6
378	B:B:V112	B:B:Y105	3.79	No	Yes	0	8	6
379	B:B:A106	B:B:F151	5.55	No	No	0	6	9
380	B:B:F151	B:B:P107	2.89	No	No	0	9	6
381	B:B:N110	B:B:S108	8.94	No	No	0	4	6
382	B:B:D154	B:B:S108	8.83	No	No	0	6	6
383	B:B:N110	B:B:Y111	4.65	No	Yes	0	4	4
384	B:B:K127	B:B:N110	8.39	No	No	0	4	4
385	B:B:I123	B:B:Y111	3.63	Yes	Yes	0	6	4
386	B:B:N125	B:B:Y111	8.14	No	Yes	0	4	4
387	B:B:D154	B:B:Y111	10.34	No	Yes	0	6	4
388	B:B:V112	B:B:Y124	3.79	No	Yes	0	8	6
389	B:B:C114	B:B:G115	3.92	No	No	0	8	9
390	B:B:C114	B:B:Y124	2.69	No	Yes	7	8	6
391	B:B:L117	B:B:Y145	3.52	No	Yes	1	9	8
392	B:B:D118	B:B:I120	8.4	No	No	0	9	6
393	B:B:G144	B:B:N119	5.09	No	No	0	8	9
394	B:B:E138	B:B:I120	2.73	No	No	0	6	6
395	B:B:C121	B:B:L139	3.17	Yes	Yes	0	8	9
396	B:B:C121	B:B:L146	3.17	Yes	Yes	1	8	7
397	B:B:C121	B:B:T159	3.38	Yes	Yes	1	8	9
398	B:B:S122	B:B:Y124	3.82	No	Yes	0	8	6
399	B:B:I123	B:B:L139	2.85	Yes	Yes	0	6	9
400	B:B:I123	B:B:I157	2.94	Yes	Yes	1	6	7
401	B:B:I123	B:B:I171	4.42	Yes	No	1	6	6
402	B:B:V135	B:B:Y124	5.05	No	Yes	7	4	6
403	B:B:N125	B:B:T128	5.85	No	No	0	4	3
404	B:B:L126	B:B:V133	4.47	No	No	0	5	4
405	B:B:R134	B:B:T128	5.17	No	No	0	3	3
406	B:B:E130	B:B:N132	2.63	Yes	No	0	3	3
407	B:B:E130	B:B:R134	9.3	Yes	No	0	3	3
408	B:B:E138	B:B:V135	4.28	No	No	7	6	4
409	B:B:L139	B:B:W169	11.39	Yes	Yes	0	9	8
410	B:B:H142	B:B:L146	5.14	Yes	Yes	1	9	7
411	B:B:H142	B:B:T159	4.11	Yes	Yes	1	9	9
412	B:B:H142	B:B:S161	15.34	Yes	Yes	1	9	9
413	B:B:D163	B:B:H142	5.04	Yes	Yes	1	9	9
414	B:B:H142	B:B:T165	2.74	Yes	No	1	9	7
415	B:B:A167	B:B:H142	2.93	No	Yes	1	4	9
416	B:B:H142	B:B:W169	3.17	Yes	Yes	1	9	8
417	B:B:D163	B:B:T143	2.89	Yes	No	0	9	5
418	B:B:G162	B:B:Y145	10.14	No	Yes	1	9	8
419	B:B:D186	B:B:Y145	9.2	Yes	Yes	1	9	8
420	B:B:L146	B:B:T159	7.37	Yes	Yes	1	7	9
421	B:B:L146	B:B:S161	3	Yes	Yes	1	7	9
422	B:B:S147	B:B:S160	4.89	No	No	0	9	6
423	B:B:C148	B:B:R150	4.18	No	No	0	6	6
424	B:B:C148	B:B:L190	3.17	No	No	0	6	5
425	B:B:F151	B:B:I157	10.05	No	Yes	0	9	7
426	B:B:L152	B:B:Q156	2.66	Yes	No	0	3	5
427	B:B:L152	B:B:V158	2.98	Yes	No	0	3	5
428	B:B:L152	B:B:L192	5.54	Yes	No	0	3	5
429	B:B:L152	B:B:T196	2.95	Yes	No	0	3	1
430	B:B:D153	B:B:Q156	7.83	No	No	0	5	5
431	B:B:D170	B:B:N155	10.77	No	No	0	9	3
432	B:B:I171	B:B:N155	5.66	No	No	0	6	3
433	B:B:E172	B:B:N155	10.52	No	No	0	6	3
434	B:B:L168	B:B:Q156	5.32	No	No	0	6	5
435	B:B:I157	B:B:W169	3.52	Yes	Yes	1	7	8
436	B:B:I157	B:B:I171	2.94	Yes	No	1	7	6
437	B:B:L190	B:B:V158	4.47	No	No	4	5	5
438	B:B:F199	B:B:V158	2.62	Yes	No	4	9	5
439	B:B:T159	B:B:W169	9.7	Yes	Yes	1	9	8
440	B:B:S160	B:B:V187	6.46	No	No	0	6	9
441	B:B:G162	B:B:S161	3.71	No	Yes	1	9	9
442	B:B:D163	B:B:S161	5.89	Yes	Yes	1	9	9
443	B:B:D186	B:B:G162	3.35	Yes	No	1	9	9
444	B:B:D163	B:B:T165	7.23	Yes	No	1	9	7
445	B:B:H183	B:B:T164	2.74	Yes	No	0	9	6
446	B:B:C166	B:B:F180	4.19	No	Yes	0	8	7
447	B:B:A167	B:B:W169	3.89	No	Yes	1	4	8
448	B:B:A167	B:B:Q176	4.55	No	Yes	1	4	4
449	B:B:L168	B:B:T177	2.95	No	No	0	6	4
450	B:B:L168	B:B:V213	2.98	No	No	0	6	4
451	B:B:Q176	B:B:W169	15.33	Yes	Yes	1	4	8
452	B:B:Q175	B:B:T173	7.09	No	No	0	4	5
453	B:B:Q176	B:B:T179	4.25	Yes	No	0	4	4
454	B:B:T177	B:B:T178	4.71	No	No	0	4	4
455	B:B:F180	B:B:T178	5.19	Yes	No	0	7	4
456	B:B:F180	B:B:F199	9.65	Yes	Yes	4	7	9
457	B:B:F180	B:B:W211	14.03	Yes	Yes	4	7	8
458	B:B:F180	B:B:G216	3.01	Yes	No	0	7	4
459	B:B:H183	B:B:V187	5.54	Yes	No	4	9	9
460	B:B:H183	B:B:S201	5.58	Yes	No	4	9	9
461	B:B:A203	B:B:H183	7.32	No	Yes	4	8	9
462	B:B:D205	B:B:H183	8.82	Yes	Yes	4	9	9
463	B:B:H183	B:B:K209	10.48	Yes	Yes	4	9	6
464	B:B:D205	B:B:T184	7.23	Yes	No	0	9	3
465	B:B:C204	B:B:D186	3.11	Yes	Yes	1	7	9
466	B:B:S201	B:B:V187	3.23	No	No	4	9	9
467	B:B:C204	B:B:M188	3.24	Yes	No	1	7	8
468	B:B:I232	B:B:S189	9.29	Yes	No	0	8	7
469	B:B:F199	B:B:L190	3.65	Yes	No	4	9	5
470	B:B:F234	B:B:S191	7.93	No	No	0	5	8
471	B:B:A193	B:B:D195	3.09	No	No	0	4	5
472	B:B:A193	B:B:F234	2.77	No	No	0	4	5
473	B:B:D195	B:B:P194	3.22	No	No	0	5	4
474	B:B:G238	B:B:P194	4.06	No	No	0	7	4
475	B:B:D195	B:B:R197	10.72	No	No	0	5	5
476	B:B:L198	B:B:L210	11.07	No	No	0	3	5
477	B:B:F199	B:B:W211	13.03	Yes	Yes	4	9	8
478	B:B:L210	B:B:V200	2.98	No	No	0	5	6
479	B:B:I232	B:B:V200	6.14	Yes	No	0	8	6
480	B:B:F234	B:B:V200	9.18	No	No	0	5	6
481	B:B:S201	B:B:W211	6.18	No	Yes	4	9	8
482	B:B:G202	B:B:I229	3.53	No	No	0	6	7
483	B:B:A203	B:B:D205	4.63	No	Yes	4	8	9
484	B:B:C204	B:B:D228	9.34	Yes	No	1	7	9
485	B:B:D205	B:B:S207	4.42	Yes	No	0	9	5
486	B:B:S207	B:B:T223	3.2	No	No	0	5	2
487	B:B:A208	B:B:F222	2.77	No	Yes	3	6	8
488	B:B:A208	B:B:F241	2.77	No	Yes	3	6	6
489	B:B:K209	B:B:W211	5.8	Yes	Yes	4	6	8
490	B:B:C218	B:B:K209	8.08	No	Yes	4	5	6
491	B:B:K209	B:B:T221	7.51	Yes	No	0	6	7
492	B:B:C218	B:B:W211	3.92	No	Yes	4	5	8
493	B:B:D212	B:B:E215	9.09	No	No	0	9	3
494	B:B:D212	B:B:M217	4.16	No	No	0	9	3
495	B:B:D212	B:B:R219	9.53	No	No	0	9	5
496	B:B:M217	G:G:M21	11.55	No	No	0	3	1
497	B:B:C218	G:G:Q18	4.58	No	No	0	5	9
498	B:B:Q220	B:B:R219	4.67	Yes	No	0	7	5
499	B:B:F222	B:B:Q220	3.51	Yes	Yes	3	8	7
500	B:B:D258	B:B:Q220	7.83	Yes	Yes	3	7	7
501	B:B:Q220	G:G:E22	5.1	Yes	No	0	7	9
502	B:B:Q220	G:G:I25	5.49	Yes	No	0	7	2
503	B:B:F222	B:B:F241	12.86	Yes	Yes	3	8	6
504	B:B:F222	B:B:F253	4.29	Yes	Yes	3	8	6
505	B:B:F222	B:B:L255	3.65	Yes	No	0	8	6
506	B:B:D258	B:B:F222	3.58	Yes	Yes	3	7	8
507	B:B:H225	B:B:I229	3.98	Yes	No	3	9	7
508	B:B:H225	B:B:T243	5.48	Yes	Yes	3	9	8
509	B:B:H225	B:B:S245	9.76	Yes	No	3	9	9
510	B:B:D247	B:B:H225	8.82	Yes	Yes	3	9	9
511	B:B:H225	B:B:T249	2.74	Yes	Yes	3	9	6
512	B:B:H225	B:B:R251	18.05	Yes	Yes	3	9	8
513	B:B:E226	B:B:S227	5.75	No	No	3	3	6
514	B:B:D247	B:B:E226	12.99	Yes	No	3	9	3
515	B:B:D247	B:B:S227	4.42	Yes	No	3	9	6
516	B:B:I229	B:B:T243	3.04	No	Yes	3	7	8
517	B:B:D246	B:B:N230	6.73	No	No	0	9	9
518	B:B:A231	B:B:V276	3.39	No	No	0	5	6
519	B:B:F241	B:B:I232	3.77	Yes	Yes	0	6	8
520	B:B:I232	B:B:T243	4.56	Yes	Yes	0	8	8
521	B:B:C233	B:B:F278	2.79	No	Yes	0	3	7
522	B:B:F235	B:B:P236	10.11	Yes	No	20	6	7
523	B:B:A240	B:B:F235	2.77	No	Yes	0	6	6
524	B:B:F235	B:B:F278	9.65	Yes	Yes	0	6	7
525	B:B:F235	B:B:G282	4.52	Yes	No	20	6	9
526	B:B:F235	G:G:L37	3.65	Yes	No	0	6	7
527	B:B:G282	B:B:P236	4.06	No	No	20	9	7
528	B:B:P236	G:G:Y40	5.56	No	No	0	7	6
529	B:B:N237	B:B:N239	8.17	No	No	0	5	2
530	B:B:N237	G:G:Y40	5.81	No	No	0	5	6
531	B:B:N239	B:B:R256	12.05	No	No	0	2	9
532	B:B:F241	B:B:F253	12.86	Yes	Yes	3	6	6
533	B:B:A242	B:B:F278	2.77	No	Yes	0	4	7
534	B:B:G244	B:B:T243	3.64	No	Yes	0	5	8
535	B:B:F253	B:B:T243	3.89	Yes	Yes	3	6	8
536	B:B:G244	B:B:I273	5.29	No	No	0	5	6
537	B:B:D247	B:B:S245	8.83	Yes	No	3	9	9
538	B:B:D247	B:B:T249	11.56	Yes	Yes	3	9	6
539	B:B:R251	B:B:T249	3.88	Yes	Yes	3	8	6
540	B:B:C250	B:B:Y264	4.03	No	Yes	0	8	5
541	B:B:F253	B:B:R251	3.21	Yes	Yes	3	6	8
542	B:B:E260	B:B:R251	13.96	No	Yes	3	6	8
543	B:B:R251	B:B:T263	7.76	Yes	No	3	8	1
544	B:B:L252	B:B:L261	2.77	No	No	0	7	5
545	B:B:L252	B:B:Y264	5.86	No	Yes	0	7	5
546	B:B:A257	B:B:D254	4.63	No	No	0	7	9
547	B:B:D254	B:B:L261	10.86	No	No	0	9	5
548	B:B:R256	G:G:I28	8.77	No	No	0	9	4
549	B:B:R256	G:G:D36	7.15	No	No	0	9	5
550	B:B:D258	G:G:R27	7.15	Yes	Yes	0	7	8
551	B:B:E260	B:B:T263	4.23	No	No	3	6	1
552	B:B:M262	B:B:Y264	5.99	Yes	Yes	1	4	5
553	B:B:A302	B:B:M262	3.22	No	Yes	1	2	4
554	B:B:W297	B:B:Y264	4.82	Yes	Yes	1	8	5
555	B:B:A302	B:B:Y264	2.67	No	Yes	1	2	5
556	B:B:H266	B:B:N268	14.03	No	No	0	4	4
557	B:B:H266	B:B:I269	2.65	No	No	0	4	4
558	B:B:H266	B:B:R304	7.9	No	No	0	4	5
559	B:B:D267	B:B:N268	2.69	No	No	0	3	4
560	B:B:I269	B:B:Y289	7.25	No	Yes	0	4	7
561	B:B:C271	B:B:Y289	4.03	Yes	Yes	1	5	7
562	B:B:C271	B:B:D290	3.11	Yes	Yes	1	5	6
563	B:B:C271	B:B:D291	7.78	Yes	No	1	5	8
564	B:B:I273	B:B:V276	4.61	No	No	0	6	6
565	B:B:A287	B:B:I273	3.25	No	No	0	6	6
566	B:B:S275	B:B:T274	4.8	No	No	0	8	8
567	B:B:D290	B:B:T274	2.89	Yes	No	1	6	8
568	B:B:R314	B:B:T274	3.88	Yes	No	1	8	8
569	B:B:L285	B:B:V276	2.98	No	No	0	6	6
570	B:B:L318	B:B:S277	3	No	No	0	6	5
571	B:B:S277	B:B:V320	4.85	No	No	0	5	7
572	B:B:F278	B:B:L285	4.87	Yes	No	0	7	6
573	B:B:S279	G:G:D48	7.36	No	Yes	17	9	9
574	B:B:S279	G:G:L50	3	No	No	17	9	9
575	B:B:S281	G:G:D48	10.31	No	Yes	0	9	9
576	B:B:D298	B:B:R283	13.1	Yes	Yes	11	9	9
577	B:B:L300	B:B:R283	7.29	No	Yes	11	6	9
578	B:B:R283	G:G:L51	6.07	Yes	Yes	0	9	6
579	B:B:L284	B:B:V296	4.47	No	No	0	5	5
580	B:B:L284	G:G:L51	2.77	No	Yes	0	5	6
581	B:B:L286	B:B:V296	2.98	No	No	0	7	5
582	B:B:L286	B:B:V327	2.98	No	No	0	7	6
583	B:B:D291	B:B:Y289	3.45	No	Yes	1	8	7
584	B:B:N295	B:B:Y289	4.65	Yes	Yes	1	6	7
585	B:B:W297	B:B:Y289	3.86	Yes	Yes	1	8	7
586	B:B:D290	B:B:R314	10.72	Yes	Yes	1	6	8
587	B:B:D291	B:B:N293	9.42	No	No	1	8	5
588	B:B:F292	B:B:N313	3.62	No	No	0	4	7
589	B:B:N293	B:B:N295	12.26	No	Yes	1	5	6
590	B:B:N293	B:B:V307	2.96	No	No	1	5	3
591	B:B:N295	B:B:W297	5.65	Yes	Yes	1	6	8
592	B:B:N295	B:B:R304	12.05	Yes	No	0	6	5
593	B:B:N295	B:B:V307	5.91	Yes	No	1	6	3
594	B:B:D298	B:B:L300	2.71	Yes	No	11	9	6
595	B:B:D298	B:B:K301	5.53	Yes	No	0	9	5
596	B:B:D298	B:B:D303	5.32	Yes	No	0	9	2
597	B:B:L300	G:G:C41	6.35	No	No	0	6	7
598	B:B:L308	B:B:W339	15.94	No	Yes	0	7	9
599	B:B:G310	B:B:W339	2.81	No	Yes	0	5	9
600	B:B:H311	B:B:V315	4.15	Yes	No	9	9	7
601	B:B:H311	B:B:T329	5.48	Yes	No	9	9	8
602	B:B:H311	B:B:S331	12.55	Yes	No	9	9	9
603	B:B:D333	B:B:H311	12.61	No	Yes	9	9	9
604	B:B:H311	B:B:K337	10.48	Yes	Yes	0	9	6
605	B:B:N313	B:B:W332	5.65	No	Yes	0	7	9
606	B:B:R314	B:B:W332	26.99	Yes	Yes	1	8	9
607	B:B:T329	B:B:V315	3.17	No	No	9	8	7
608	B:B:C317	B:B:S316	3.44	No	No	0	7	9
609	B:B:S316	B:B:W332	4.94	No	Yes	0	9	9
610	B:B:V320	B:B:V327	6.41	No	No	0	7	6
611	B:B:D322	B:B:T321	2.89	No	Yes	13	1	7
612	B:B:D323	B:B:T321	7.23	No	Yes	13	7	7
613	B:B:D323	B:B:M325	8.32	No	No	0	7	5
614	B:B:M325	G:G:P49	8.39	No	No	0	5	7
615	B:B:A326	G:G:F61	4.16	No	Yes	0	7	8
616	B:B:V327	B:B:W339	3.68	No	Yes	0	6	9
617	B:B:T329	B:B:W339	4.85	No	Yes	0	8	9
618	B:B:G330	B:B:L336	3.42	No	No	0	5	7
619	B:B:D333	B:B:S331	8.83	No	No	9	9	9
620	B:B:D333	B:B:F335	15.52	No	No	0	9	4
621	B:B:K337	B:B:W339	4.64	Yes	Yes	0	6	9
622	B:B:I338	G:G:F61	5.02	No	Yes	0	5	8
623	B:B:N340	G:G:N59	5.45	No	Yes	0	9	9
624	B:B:N340	G:G:F61	3.62	No	Yes	0	9	8
625	G:G:E17	G:G:M21	2.71	No	No	0	6	1
626	G:G:K20	G:G:N24	6.99	No	No	0	6	1
627	G:G:E22	G:G:R27	3.49	No	Yes	0	9	8
628	G:G:I25	G:G:R27	10.02	No	Yes	0	2	8
629	G:G:E42	G:G:M38	2.71	No	No	0	1	4
630	G:G:H44	G:G:Y40	11.98	No	No	0	6	6
631	G:G:A43	G:G:H44	2.93	No	No	0	4	6
632	G:G:D48	G:G:P49	3.22	Yes	No	0	9	7
633	G:G:D48	G:G:L50	2.71	Yes	No	17	9	9
634	G:G:D48	G:G:L51	9.5	Yes	Yes	0	9	6
635	G:G:P55	G:G:V54	5.3	No	No	21	5	6
636	G:G:E58	G:G:V54	9.98	No	No	21	5	6
637	G:G:N59	G:G:V54	2.96	Yes	No	0	9	6
638	G:G:E58	G:G:P55	9.43	No	No	21	5	5
639	R:R:F19	R:R:V15	2.62	No	No	0	5	4
640	R:R:D16	R:R:H80	8.82	No	No	0	5	4
641	R:R:D16	R:R:H269	17.65	No	No	0	5	5
642	R:R:P20	R:R:P21	7.79	No	No	0	5	7
643	R:R:P20	R:R:Y24	2.78	No	No	0	5	9
644	R:R:F77	R:R:P21	24.56	Yes	No	0	5	7
645	R:R:L23	R:R:V27	2.98	No	No	0	5	7
646	R:R:L23	R:R:L277	5.54	No	No	0	5	5
647	R:R:L70	R:R:Y24	7.03	Yes	No	0	8	9
648	R:R:A273	R:R:Y24	4	No	No	0	5	9
649	R:R:F77	R:R:I25	5.02	Yes	No	0	5	4
650	R:R:F26	R:R:V30	5.24	No	Yes	0	4	6
651	R:R:S276	R:R:V27	3.23	No	No	0	7	7
652	R:R:V27	R:R:V280	3.21	No	No	0	7	8
653	R:R:G29	R:R:I28	3.53	No	No	0	5	7
654	R:R:I28	R:R:L70	7.14	No	Yes	0	7	8
655	R:R:I28	R:R:P71	3.39	No	No	0	7	8
656	R:R:T34	R:R:V30	3.17	No	Yes	0	7	6
657	R:R:V280	R:R:V30	6.41	No	Yes	0	8	6
658	R:R:I67	R:R:L32	2.85	No	No	0	6	6
659	R:R:P283	R:R:T34	3.5	No	No	0	9	7
660	R:R:D63	R:R:N35	10.77	Yes	No	0	9	9
661	R:R:L64	R:R:N35	2.75	No	No	0	8	9
662	R:R:N35	R:R:P283	14.66	No	No	0	9	9
663	R:R:L37	R:R:V297	4.47	No	No	0	7	7
664	R:R:A38	R:R:S60	3.42	No	No	0	9	8
665	R:R:A38	R:R:C287	3.61	No	No	0	9	8
666	R:R:L39	R:R:M57	2.83	No	No	0	7	5
667	R:R:I61	R:R:L39	4.28	No	No	0	5	7
668	R:R:R44	R:R:W40	6	No	No	0	4	4
669	R:R:A300	R:R:W40	3.89	No	No	0	3	4
670	R:R:A41	R:R:D296	4.63	No	No	0	7	4
671	R:R:A42	R:R:M57	3.22	No	No	0	7	5
672	R:R:M57	R:R:Y43	4.79	No	No	0	5	4
673	R:R:D296	R:R:R44	3.57	No	No	0	4	4
674	R:R:N50	R:R:Q45	3.96	No	No	0	7	5
675	R:R:L52	R:R:N50	4.12	No	No	0	8	7
676	R:R:D114	R:R:E51	12.99	No	Yes	5	8	7
677	R:R:E51	R:R:R129	5.82	Yes	Yes	5	7	7
678	R:R:A134	R:R:E51	3.02	No	Yes	0	5	7
679	R:R:L52	R:R:L56	4.15	No	No	0	8	8
680	R:R:G53	R:R:L56	3.42	No	No	0	7	8
681	R:R:A134	R:R:V54	5.09	No	No	0	5	5
682	R:R:C110	R:R:Y55	2.69	No	Yes	0	7	7
683	R:R:I111	R:R:Y55	3.63	No	Yes	0	9	7
684	R:R:D114	R:R:Y55	6.9	No	Yes	0	8	7
685	R:R:A134	R:R:Y55	4	No	Yes	0	5	7
686	R:R:F107	R:R:N58	10.87	Yes	No	6	8	7
687	R:R:N58	R:R:S138	5.96	No	No	0	7	7
688	R:R:N58	R:R:W142	4.52	No	Yes	6	7	9
689	R:R:D63	R:R:L59	2.71	Yes	Yes	6	9	9
690	R:R:L59	R:R:S104	3	Yes	No	6	9	9
691	R:R:L108	R:R:L59	4.15	No	Yes	6	8	9
692	R:R:D282	R:R:L59	10.86	Yes	Yes	6	9	9
693	R:R:D63	R:R:S104	2.94	Yes	No	6	9	9
694	R:R:C279	R:R:D63	4.67	No	Yes	0	9	9
695	R:R:D282	R:R:D63	3.99	Yes	Yes	6	9	9
696	R:R:I96	R:R:L65	2.85	Yes	No	0	5	7
697	R:R:L70	R:R:Y66	3.52	Yes	Yes	22	8	7
698	R:R:F97	R:R:Y66	7.22	Yes	Yes	22	7	7
699	R:R:N100	R:R:Y66	9.3	No	Yes	0	8	7
700	R:R:S276	R:R:Y66	6.36	No	Yes	0	7	7
701	R:R:C279	R:R:Y66	4.03	No	Yes	0	9	7
702	R:R:F97	R:R:L70	3.65	Yes	Yes	22	7	8
703	R:R:F93	R:R:L72	10.96	Yes	No	0	6	7
704	R:R:F93	R:R:W73	24.05	Yes	No	0	6	7
705	R:R:G94	R:R:W73	4.22	No	No	0	8	7
706	R:R:F97	R:R:W73	26.06	Yes	No	0	7	7
707	R:R:F77	R:R:V74	13.11	Yes	No	0	5	7
708	R:R:F93	R:R:Y76	5.16	Yes	No	0	6	6
709	R:R:F77	R:R:L78	8.53	Yes	No	0	5	7
710	R:R:H79	R:R:L78	3.86	No	No	0	4	7
711	R:R:H85	R:R:I84	3.98	No	No	0	7	3
712	R:R:G86	R:R:P87	4.06	No	No	0	8	3
713	R:R:G88	R:R:K91	5.23	No	No	0	2	6
714	R:R:C90	R:R:F93	2.79	No	Yes	0	9	6
715	R:R:K91	R:R:L153	4.23	No	No	0	6	4
716	R:R:F95	R:R:I96	6.28	No	Yes	0	6	5
717	R:R:F95	R:R:T99	6.49	No	No	0	6	5
718	R:R:I96	R:R:N100	5.66	Yes	No	0	5	8
719	R:R:F97	R:R:Y98	6.19	Yes	No	0	7	5
720	R:R:L272	R:R:Y98	5.86	No	No	0	5	5
721	R:R:N149	R:R:T99	11.7	No	No	0	7	5
722	R:R:F237	R:R:I101	7.54	Yes	No	24	8	8
723	R:R:I101	R:R:T275	4.56	No	No	24	8	8
724	R:R:R185	R:R:Y102	9.26	No	No	0	5	7
725	R:R:G189	R:R:Y102	2.9	No	No	0	6	7
726	R:R:H241	R:R:Y102	5.44	Yes	No	0	8	7
727	R:R:I103	R:R:W142	7.05	No	Yes	0	7	9
728	R:R:E145	R:R:I103	5.47	No	No	0	7	7
729	R:R:I105	R:R:P193	3.39	No	No	0	8	9
730	R:R:F237	R:R:I105	5.02	Yes	No	0	8	8
731	R:R:F107	R:R:V141	3.93	Yes	No	0	8	7
732	R:R:F107	R:R:W142	5.01	Yes	Yes	6	8	9
733	R:R:D282	R:R:L108	5.43	Yes	No	6	9	8
734	R:R:L108	R:R:Y286	7.03	No	Yes	6	8	9
735	R:R:C109	R:R:L196	4.76	No	No	0	8	4
736	R:R:I111	R:R:R115	3.76	No	No	0	9	9
737	R:R:I111	R:R:Y286	3.63	No	Yes	0	9	9
738	R:R:S112	R:R:V113	3.23	Yes	No	0	9	6
739	R:R:M197	R:R:S112	3.07	No	Yes	0	7	9
740	R:R:S112	R:R:S200	6.52	Yes	No	0	9	8
741	R:R:S112	R:R:Y201	3.82	Yes	Yes	0	9	8
742	R:R:R115	R:R:Y201	7.2	No	Yes	0	9	8
743	R:R:A120	R:R:Y116	8.01	No	Yes	0	7	8
744	R:R:H121	R:R:Y116	6.53	No	Yes	0	6	8
745	R:R:G203	R:R:Y116	2.9	No	Yes	0	3	8
746	R:R:I204	R:R:Y116	3.63	No	Yes	0	6	8
747	R:R:L128	R:R:R127	4.86	No	No	0	3	4
748	R:R:K132	R:R:R130	13.61	No	No	0	4	6
749	R:R:S138	R:R:V135	3.23	No	No	0	7	4
750	R:R:S138	R:R:S139	3.26	No	No	0	7	5
751	R:R:E145	R:R:T144	2.82	No	No	0	7	5
752	R:R:G147	R:R:S150	3.71	No	No	0	4	4
753	R:R:F154	R:R:S150	2.64	No	No	0	4	4
754	R:R:F154	R:R:L153	6.09	No	No	0	4	4
755	R:R:K171	R:R:P173	3.35	No	No	0	3	4
756	R:R:F172	R:R:P173	4.33	No	No	0	5	4
757	R:R:M174	R:R:Y251	32.33	No	No	0	1	3
758	R:R:N182	R:R:V178	5.91	No	No	0	5	2
759	R:R:L252	R:R:W180	6.83	No	No	0	6	3
760	R:R:M181	R:R:R185	4.96	No	No	0	4	5
761	R:R:L244	R:R:N182	5.49	No	No	0	5	5
762	R:R:N182	R:R:S248	7.45	No	No	0	5	5
763	R:R:V188	R:R:Y184	12.62	No	No	0	4	3
764	R:R:F187	R:R:V186	3.93	No	No	0	5	4
765	R:R:H241	R:R:V186	5.54	Yes	No	0	8	4
766	R:R:F190	R:R:L191	3.65	No	No	0	8	4
767	R:R:F190	R:R:F237	3.22	No	Yes	0	8	8
768	R:R:F190	R:R:H241	11.31	No	Yes	0	8	8
769	R:R:F192	R:R:P193	5.78	No	No	0	5	9
770	R:R:I230	R:R:W194	3.52	Yes	No	0	7	6
771	R:R:L234	R:R:W194	12.53	No	No	0	6	6
772	R:R:I230	R:R:M197	2.92	Yes	No	0	7	7
773	R:R:I230	R:R:L198	4.28	Yes	No	0	7	5
774	R:R:A226	R:R:Y201	4	No	Yes	0	7	8
775	R:R:L229	R:R:Y201	3.52	Yes	Yes	0	8	8
776	R:R:I230	R:R:Y201	3.63	Yes	Yes	0	7	8
777	R:R:G203	R:R:R206	3	No	No	0	3	3
778	R:R:K223	R:R:L205	4.23	No	No	0	6	5
779	R:R:A207	R:R:R206	2.77	No	No	0	3	3
780	R:R:S211	R:R:T214	4.8	No	Yes	2	5	3
781	R:R:K219	R:R:S211	3.06	No	No	2	6	5
782	R:R:E218	R:R:T214	8.47	No	Yes	2	5	3
783	R:R:K219	R:R:T214	4.5	No	Yes	2	6	3
784	R:R:K223	R:R:L227	2.82	No	No	0	6	5
785	R:R:L229	R:R:S228	4.5	Yes	No	0	8	6
786	R:R:L229	R:R:L285	4.15	Yes	No	0	8	5
787	R:R:L229	R:R:Y286	8.21	Yes	Yes	0	8	9
788	R:R:C236	R:R:I232	3.27	No	No	0	8	7
789	R:R:A281	R:R:I232	3.25	No	No	0	5	7
790	R:R:A238	R:R:L234	3.15	No	No	0	5	6
791	R:R:C236	R:R:N278	3.15	No	No	0	8	9
792	R:R:F237	R:R:T275	6.49	Yes	No	24	8	8
793	R:R:F237	R:R:N278	12.08	Yes	No	0	8	9
794	R:R:H241	R:R:Y240	3.27	Yes	Yes	0	8	6
795	R:R:L244	R:R:Y240	8.21	No	Yes	0	5	6
796	R:R:Y240	R:R:Y268	7.94	Yes	Yes	23	6	5
797	R:R:S271	R:R:Y240	5.09	No	Yes	0	7	6
798	R:R:L272	R:R:Y240	8.21	No	Yes	23	5	6
799	R:R:L243	R:R:Y268	4.69	No	Yes	0	6	5
800	R:R:R247	R:R:Y251	9.26	No	No	0	4	3
801	R:R:R247	R:R:Y268	3.09	No	Yes	0	4	5
802	R:R:F265	R:R:H269	13.58	No	No	0	4	5
803	R:R:L272	R:R:Y268	3.52	No	Yes	23	5	5
804	R:R:D282	R:R:N278	2.69	Yes	No	0	9	9
805	R:R:D282	R:R:P283	3.22	Yes	No	0	9	9
806	R:R:D282	R:R:Y286	9.2	Yes	Yes	6	9	9
807	R:R:A293	R:R:N290	4.69	No	No	0	8	8
808	R:R:E291	R:R:R294	10.47	No	No	0	5	8
809	R:R:D296	R:R:V297	4.38	No	No	0	4	7
810	R:R:K299	R:R:N303	2.8	No	No	0	5	3
811	B:B:A287	B:B:W297	2.59	No	Yes	0	6	8
812	R:R:A62	R:R:W142	2.59	No	Yes	0	8	9
813	R:R:F97	R:R:T69	2.59	Yes	No	0	7	7
814	R:R:R130	R:R:T133	2.59	No	No	0	6	3
815	R:R:A179	R:R:W180	2.59	No	No	0	1	3
816	R:R:H17	R:R:L78	2.57	No	No	0	5	7
817	B:B:E12	B:B:Q9	2.55	No	No	0	4	3
818	B:B:V71	B:B:Y105	2.52	No	Yes	0	8	6
819	R:R:D75	R:R:H79	2.52	No	No	0	4	4
820	A:A:I26	A:A:R22	2.51	No	No	0	9	5
821	A:A:F212	A:A:I375	2.51	Yes	No	0	9	9
822	R:R:V233	R:R:W194	2.45	No	No	0	9	6
823	R:R:F107	R:R:L59	2.44	Yes	Yes	6	8	9
824	R:R:F95	R:R:L146	2.44	No	No	0	6	3
825	R:R:F187	R:R:L245	2.44	No	No	0	5	6
826	R:R:F192	R:R:L196	2.44	No	No	0	5	4
827	R:R:F274	R:R:L277	2.44	No	No	0	7	5
828	B:B:L7	G:G:R13	2.43	Yes	No	0	8	6
829	B:B:L139	B:B:R137	2.43	Yes	No	0	9	5
830	R:R:Q48	R:R:R44	2.34	No	No	0	7	4
831	A:A:E314	A:A:R317	2.33	No	No	0	6	2
832	B:B:E130	B:B:R129	2.33	Yes	No	0	3	3
833	R:R:E170	R:R:F265	2.33	No	No	0	4	4
834	R:R:L183	R:R:W180	2.28	No	No	0	4	3
835	R:R:F125	R:R:R124	2.14	No	No	0	6	4
836	A:A:F312	A:A:Y311	2.06	Yes	No	0	8	6
837	A:A:G329	A:A:P328	2.03	No	No	0	7	1
838	B:B:G324	G:G:P49	2.03	No	No	0	9	7
839	R:R:G31	R:R:P33	2.03	No	No	0	8	5
840	B:B:C271	B:B:G272	1.96	Yes	No	0	5	4
841	B:B:C294	B:B:G288	1.96	No	No	0	5	7
842	A:A:A226	A:A:G206	1.95	No	No	0	9	8
843	A:A:A303	A:A:G304	1.95	No	No	0	5	5
844	B:B:A140	B:B:G141	1.95	No	No	0	5	5
845	B:B:A305	B:B:G306	1.95	No	No	0	4	4
846	R:R:A42	R:R:G53	1.95	No	No	0	7	7
847	R:R:A179	R:R:G176	1.95	No	No	0	1	4
848	R:R:A151	R:R:P152	1.87	No	No	0	7	3
849	R:R:A238	R:R:P239	1.87	No	No	0	5	9
850	A:A:G52	A:A:S51	1.86	No	No	0	9	9
851	R:R:G86	R:R:S89	1.86	No	No	0	8	6
852	R:R:G292	R:R:S295	1.86	No	No	0	6	4
853	B:B:G288	B:B:V315	1.84	No	No	0	7	7
854	B:B:G306	B:B:V296	1.84	No	No	0	4	5
855	B:B:G306	B:B:V307	1.84	No	No	0	4	3
856	R:R:G31	R:R:V30	1.84	No	Yes	0	8	6
857	B:B:G115	B:B:T102	1.82	No	No	0	9	8
858	B:B:C121	B:B:C149	1.82	Yes	Yes	1	8	8
859	B:B:G185	B:B:T164	1.82	No	No	0	5	6
860	B:B:G182	B:B:T181	1.82	No	No	0	6	2
861	B:B:G185	B:B:T184	1.82	No	No	0	5	3
862	B:B:A73	B:B:C103	1.81	No	No	0	9	8
863	B:B:A104	B:B:C149	1.81	No	Yes	0	7	8
864	B:B:A113	B:B:C121	1.81	No	Yes	1	9	8
865	B:B:A113	B:B:C149	1.81	No	Yes	1	9	8
866	R:R:A41	R:R:C287	1.81	No	No	0	7	8
867	R:R:A293	R:R:C287	1.81	No	No	0	8	8
868	G:G:P55	G:G:S57	1.78	No	No	0	5	6
869	A:A:P326	A:A:T325	1.75	No	No	0	1	2
870	B:B:P107	B:B:T65	1.75	No	No	0	6	1
871	G:G:P53	G:G:T52	1.75	No	No	0	8	4
872	A:A:G47	A:A:K53	1.74	No	No	0	9	9
873	B:B:G324	B:B:K280	1.74	No	No	0	9	1
874	A:A:L30	B:B:G53	1.71	No	No	0	5	9
875	B:B:A56	B:B:S74	1.71	No	No	0	7	9
876	B:B:G174	B:B:L139	1.71	No	Yes	0	4	9
877	R:R:C110	R:R:V137	1.71	No	No	0	7	5
878	R:R:G147	R:R:L146	1.71	No	No	0	4	3
879	A:A:A269	A:A:V248	1.7	No	Yes	0	9	7
880	A:A:A298	A:A:V334	1.7	No	Yes	0	4	4
881	A:A:A337	A:A:V301	1.7	No	No	0	8	7
882	B:B:A11	G:G:V16	1.7	No	No	0	5	7
883	B:B:A26	G:G:V30	1.7	No	No	0	3	8
884	R:R:A106	R:R:V141	1.7	No	No	0	6	7
885	A:A:D354	A:A:G353	1.68	No	No	0	3	4
886	B:B:D66	B:B:G64	1.68	No	No	0	8	5
887	B:B:D76	B:B:G77	1.68	Yes	No	0	9	8
888	B:B:E130	B:B:G131	1.64	Yes	No	0	3	4
889	B:B:G141	B:B:Q176	1.64	No	Yes	0	5	4
890	B:B:E260	B:B:G224	1.64	No	No	0	6	6
891	R:R:L32	R:R:P33	1.64	No	No	0	6	5
892	R:R:E291	R:R:G292	1.64	No	No	0	5	6
893	A:A:I26	B:B:A92	1.62	No	No	0	9	6
894	A:A:S205	A:A:V202	1.62	No	No	0	7	6
895	B:B:A28	B:B:I33	1.62	No	No	0	4	3
896	B:B:I33	G:G:A34	1.62	No	No	0	3	6
897	R:R:S246	R:R:V242	1.62	No	No	0	4	6
898	R:R:A151	R:R:M181	1.61	No	No	0	7	4
899	B:B:S265	B:B:T249	1.6	No	Yes	0	2	6
900	R:R:V46	R:R:V54	1.6	No	No	0	6	5
901	R:R:V131	R:R:V54	1.6	No	No	0	3	5
902	R:R:T133	R:R:V137	1.59	No	No	0	3	5
903	B:B:A11	G:G:L15	1.58	No	No	0	5	2
904	B:B:A11	G:G:L19	1.58	No	No	0	5	9
905	R:R:A226	R:R:L205	1.58	No	No	0	7	5
906	R:R:A267	R:R:L243	1.58	No	No	0	5	6
907	B:B:T165	B:B:T181	1.57	No	No	0	7	2
908	B:B:T179	B:B:T181	1.57	No	No	0	4	2
909	A:A:A19	B:B:N88	1.56	No	Yes	0	4	7
910	G:G:A56	G:G:N59	1.56	No	Yes	0	4	9
911	R:R:A148	R:R:N149	1.56	No	No	0	5	7
912	B:B:I123	B:B:S136	1.55	Yes	No	0	6	4
913	B:B:A21	B:B:D20	1.54	No	No	0	4	2
914	B:B:D254	G:G:A33	1.54	No	No	0	9	7
915	R:R:I222	R:R:V208	1.54	No	No	0	7	8
916	R:R:I284	R:R:V280	1.54	No	No	0	7	8
917	A:A:C365	A:A:Q294	1.53	No	Yes	0	8	6
918	G:G:A12	G:G:Q11	1.52	No	No	0	5	3
919	A:A:F208	A:A:G225	1.51	No	No	0	5	9
920	B:B:K15	B:B:T223	1.5	No	No	0	6	2
921	R:R:G203	R:R:R202	1.5	No	No	0	3	3
922	R:R:G210	R:R:R209	1.5	No	No	0	4	4
923	R:R:L225	R:R:S228	1.5	No	No	0	8	6
924	R:R:L18	R:R:V15	1.49	No	No	0	4	4
925	R:R:L117	R:R:V113	1.49	No	No	0	6	6
926	R:R:L225	R:R:V289	1.49	No	No	0	8	6
927	R:R:L285	R:R:V289	1.49	No	No	0	5	6
928	A:A:V20	B:B:N88	1.48	No	Yes	0	3	7
929	A:A:D354	A:A:S352	1.47	No	No	0	3	5
930	G:G:L51	G:G:T52	1.47	Yes	No	0	6	4
931	A:A:D331	A:A:V334	1.46	Yes	Yes	0	4	4
932	A:A:I383	A:A:M386	1.46	Yes	No	0	8	3
933	B:B:A206	B:B:H225	1.46	No	Yes	0	4	9
934	R:R:D16	R:R:V15	1.46	No	No	0	5	4
935	G:G:I28	G:G:K32	1.45	No	No	0	4	5
936	A:A:F312	A:A:P313	1.44	Yes	No	0	8	6
937	R:R:F19	R:R:P20	1.44	No	No	0	5	5
938	R:R:I96	R:R:L92	1.43	Yes	No	0	5	5
939	R:R:I284	R:R:L288	1.43	No	No	0	7	7
940	B:B:Q32	B:B:T29	1.42	No	No	0	1	3
941	B:B:I37	B:B:N36	1.42	No	No	0	2	1
942	A:A:G353	A:A:W277	1.41	No	Yes	0	4	6
943	B:B:L14	G:G:K20	1.41	Yes	No	0	8	6
944	G:G:D26	G:G:I28	1.4	No	No	0	1	4
945	B:B:H54	B:B:S334	1.39	Yes	No	0	9	4
946	B:B:A299	B:B:F278	1.39	No	Yes	0	5	7
947	A:A:R38	R:R:A126	1.38	No	No	0	4	8
948	B:B:A21	G:G:R27	1.38	No	Yes	0	4	8
949	R:R:A220	R:R:R224	1.38	No	No	0	5	3
950	A:A:K28	A:A:Q31	1.36	No	No	0	4	4
951	A:A:K32	A:A:Q29	1.36	No	No	0	4	4
952	A:A:D223	A:A:L45	1.36	No	Yes	0	9	8
953	A:A:D295	A:A:L296	1.36	No	No	0	9	6
954	B:B:N35	B:B:N36	1.36	No	No	0	1	1
955	R:R:E175	R:R:M174	1.35	No	No	0	2	1
956	B:B:S334	R:R:R49	1.32	No	No	0	4	6
957	R:R:F19	R:R:S22	1.32	No	No	0	5	5
958	R:R:R247	R:R:V264	1.31	No	No	0	4	4
959	A:A:D16	A:A:E15	1.3	No	No	0	5	6
960	A:A:D229	A:A:E230	1.3	No	No	0	8	9
961	R:R:K221	R:R:R224	1.24	No	No	0	7	3
962	G:G:E47	G:G:H44	1.23	No	No	0	3	6
963	A:A:N254	A:A:R265	1.21	No	No	0	9	9
964	G:G:N59	G:G:R62	1.21	Yes	No	0	9	7
965	R:R:L199	R:R:R202	1.21	No	No	0	4	3
966	R:R:I250	R:R:Y251	1.21	No	No	0	1	3
967	A:A:R38	R:R:R129	1.07	No	Yes	0	4	7
968	R:R:R185	R:R:Y184	1.03	No	No	0	5	3

Color	ConSurf Grade
	No Conservation data available
	1
	2
	3
	4
	5
	6
	7
	8
	9

Index: hub id, click on each number to highlight the corresponding hub in the 3D visualization.

Hub: the hub being considered.

Avg Int. Strength: the average interaction strength of all the links of the corresponding hub.

Num Of Links: the number of links of the corresponding hub.

Community: the id of the community the link belong to, otherwise 0.

ConSurf: this column reports the ConSurf conservation grades of each hub.

Index	Hub	Avg Int. Strength	Num Of Links	Community	ConSurf
1	A:A:L45	3.8775	4	15	8
2	A:A:N50	7.9025	4	10	9
3	A:A:F212	8.424	5	0	9
4	A:A:V217	3.7375	4	5	5
5	A:A:F219	5.876	5	0	8
6	A:A:H220	8.5625	4	1	7
7	A:A:F222	5.8975	4	1	7
8	A:A:Q227	4.86	4	1	9
9	A:A:R231	5.2075	4	1	9
10	A:A:K233	5.62333	6	1	9
11	A:A:W234	4.75333	6	1	9
12	A:A:I235	3.9525	4	1	9
13	A:A:F238	7.4275	4	0	9
14	A:A:I244	3.6425	4	0	8
15	A:A:V248	3.4625	4	0	7
16	A:A:L270	5.495	4	0	6
17	A:A:W277	7.785	4	0	6
18	A:A:W281	8.4825	4	1	5
19	A:A:I288	5.2175	4	2	9
20	A:A:F290	4.622	5	2	9
21	A:A:N292	4.632	5	0	9
22	A:A:Q294	4.96	5	8	6
23	A:A:F312	3.165	4	0	8
24	A:A:F315	9.055	4	0	6
25	A:A:Y318	6.4625	4	0	6
26	A:A:E330	5.0325	4	0	3
27	A:A:D331	7.1775	4	0	4
28	A:A:V334	3.375	4	0	4
29	A:A:K338	5.1225	4	8	5
30	A:A:Y339	5.3925	4	0	3
31	A:A:F340	7.3175	4	0	7
32	A:A:R342	5.6725	4	0	4
33	A:A:S349	4.7075	4	0	7
34	A:A:Y360	8.958	5	2	8
35	A:A:F363	6.73	4	8	5
36	A:A:T364	5.02	5	2	9
37	A:A:D368	6.5675	4	2	9
38	A:A:N371	7.235	4	2	9
39	A:A:R374	5.9625	4	2	4
40	A:A:F376	4.352	5	5	8
41	A:A:D378	9.125	4	2	7
42	A:A:D381	5.166	5	2	8
43	A:A:I383	3.94	4	5	8
44	A:A:R385	4.902	5	2	5
45	A:A:H387	4	4	5	8
46	A:A:L388	3.5925	4	0	8
47	A:A:Y391	6.974	5	5	4
48	B:B:L7	3.1975	4	0	8
49	B:B:L14	4.905	4	0	8
50	B:B:D27	4.6825	4	0	8
51	B:B:T34	3.38	4	16	5
52	B:B:V40	4.745	4	11	3
53	B:B:L51	7.5225	4	0	9
54	B:B:H54	5.945	6	12	9
55	B:B:K57	8.435	4	1	9
56	B:B:Y59	7.9325	4	1	8
57	B:B:W63	5.348	5	0	7
58	B:B:Q75	5.405	4	1	9
59	B:B:D76	6.755	4	0	9
60	B:B:W82	8.08333	6	12	9
61	B:B:D83	6.8575	4	14	8
62	B:B:Y85	13.165	4	18	4
63	B:B:N88	4.088	5	14	7
64	B:B:K89	5.716	5	0	9
65	B:B:I93	4.6625	4	0	7
66	B:B:L95	4.465	4	7	8
67	B:B:W99	6.68	7	1	9
68	B:B:Y105	3.7675	4	0	6
69	B:B:Y111	6.69	4	0	4
70	B:B:C121	2.67	5	1	8
71	B:B:I123	3.078	5	1	6
72	B:B:Y124	4.34167	6	7	6
73	B:B:E130	3.975	4	0	3
74	B:B:L139	4.31	5	0	9
75	B:B:H142	5.49571	7	1	9
76	B:B:Y145	6.00143	7	1	8
77	B:B:L146	4.67	4	1	7
78	B:B:C149	2.6275	4	1	8
79	B:B:L152	3.5325	4	0	3
80	B:B:I157	4.8625	4	1	7
81	B:B:T159	6.14	4	1	9
82	B:B:S161	6.985	4	1	9
83	B:B:D163	5.2625	4	1	9
84	B:B:W169	7.83333	6	1	8
85	B:B:Q176	6.4425	4	1	4
86	B:B:F180	7.214	5	4	7
87	B:B:H183	6.74667	6	4	9
88	B:B:D186	4.878	5	1	9
89	B:B:F199	7.2375	4	4	9
90	B:B:C204	4.666	5	1	7
91	B:B:D205	6.275	4	4	9
92	B:B:K209	7.9675	4	4	6
93	B:B:W211	8.592	5	4	8
94	B:B:Q220	5.32	5	3	7
95	B:B:F222	5.11	6	3	8
96	B:B:H225	7.18429	7	3	9
97	B:B:I232	5.94	4	0	8
98	B:B:F235	6.14	5	20	6
99	B:B:F241	8.065	4	3	6
100	B:B:T243	4.122	5	3	8
101	B:B:D247	9.324	5	3	9
102	B:B:T249	4.945	4	3	6
103	B:B:R251	9.372	5	3	8
104	B:B:F253	6.0625	4	3	6
105	B:B:D258	5.5325	4	3	7
106	B:B:M262	5.545	4	1	4
107	B:B:Y264	4.674	5	1	5
108	B:B:C271	4.22	4	1	5
109	B:B:F278	4.294	5	0	7
110	B:B:R283	8.5775	4	11	9
111	B:B:Y289	4.648	5	1	7
112	B:B:D290	5.2975	4	1	6
113	B:B:N295	8.104	5	1	6
114	B:B:W297	4.23	4	1	8
115	B:B:D298	6.208	5	11	9
116	B:B:H311	9.054	5	9	9
117	B:B:R314	10.452	5	1	8
118	B:B:T321	5.3425	4	13	7
119	B:B:W332	10.16	7	1	9
120	B:B:K337	5.28	4	0	6
121	B:B:W339	6.384	5	0	9
122	G:G:R27	5.244	5	0	8
123	G:G:D48	6.62	5	17	9
124	G:G:L51	4.9525	4	0	6
125	G:G:N59	2.795	4	0	9
126	G:G:F61	5.47667	6	18	8
127	R:R:V30	4.165	4	0	6
128	R:R:E51	6.3	4	5	7
129	R:R:Y55	4.305	4	0	7
130	R:R:L59	4.632	5	6	9
131	R:R:D63	5.016	5	6	9
132	R:R:Y66	6.086	5	22	7
133	R:R:L70	5.335	4	22	8
134	R:R:F77	12.805	4	0	5
135	R:R:F93	10.74	4	0	6
136	R:R:I96	4.055	4	0	5
137	R:R:F97	9.142	5	22	7
138	R:R:F107	5.5625	4	6	8
139	R:R:S112	4.16	4	0	9
140	R:R:Y116	5.2675	4	0	8
141	R:R:L123	4.224	5	5	6
142	R:R:R129	3.855	4	5	7
143	R:R:W142	4.7925	4	6	9
144	R:R:Y201	4.434	5	0	8
145	R:R:S213	4.995	4	2	3
146	R:R:T214	5.4125	4	2	3
147	R:R:L229	5.095	4	0	8
148	R:R:I230	3.5875	4	0	7
149	R:R:F237	6.87	5	24	8
150	R:R:Y240	6.544	5	23	6
151	R:R:H241	6.39	4	0	8
152	R:R:Y268	4.81	4	23	5
153	R:R:D282	5.89833	6	6	9
154	R:R:Y286	7.0175	4	6	9

Color	ConSurf Grade
	No Conservation data available
	1
	2
	3
	4
	5
	6
	7
	8
	9

Index: link id, click on each number to highlight the corresponding link in the 3D visualization.

Node1 Node2: the two nodes of the corresponding link.

Recurrence: the relative Recurrence in the pool of shortest paths.

Int. Strength: the interaction strength between the two nodes.

Hub1?, Hub2?: "Yes" if the corresponding node has more than 3 links, otherwise "No".

Community: the id of the community the link belong to, otherwise 0.

ConSurf1, ConSurf2: these columns report the ConSurf conservation grades of the two nodes involved in a link.

Index	Node1	Node2	Recurrence	Int. Strength	Hub1?	Hub2?	Community	ConSurf1	ConSurf2
1	R:R:I111	R:R:R115	27.8323	3.76	No	No	0	9	9
2	A:A:L393	R:R:R115	31.9394	3.64	No	No	0	8	9
3	A:A:L388	A:A:L393	33.6267	2.77	Yes	No	0	8	8
4	A:A:L388	A:A:L394	34.3026	4.15	Yes	No	0	8	8
5	A:A:L394	A:A:R385	34.4536	3.64	No	Yes	2	8	5
6	A:A:R385	R:R:S213	35.4652	2.64	Yes	Yes	2	5	3
7	A:A:Y360	R:R:S213	35.6165	5.09	Yes	Yes	2	8	3
8	A:A:D378	A:A:Y360	37.0192	13.79	Yes	Yes	2	7	8
9	A:A:D378	A:A:I288	96.1707	11.2	Yes	Yes	2	7	9
10	A:A:F290	A:A:I288	96.4553	3.77	Yes	Yes	2	9	9
11	A:A:F290	A:A:V247	48.3804	2.62	Yes	No	0	9	7
12	A:A:N292	A:A:V247	48.6082	2.96	Yes	No	0	9	7
13	A:A:K293	A:A:N292	97.737	5.6	No	Yes	0	9	9
14	A:A:K293	A:A:L296	98.3256	2.82	No	No	0	9	6
15	A:A:L296	A:A:S251	98.456	7.51	No	No	0	6	9
16	A:A:K300	A:A:S251	98.5212	3.06	No	No	0	9	9
17	A:A:K300	A:A:Y253	98.7164	5.97	No	No	0	9	8
18	A:A:I308	A:A:Y253	98.7814	8.46	No	No	0	7	8
19	A:A:F315	A:A:I308	98.8464	7.54	Yes	No	0	6	7
20	A:A:F315	A:A:F340	97.8707	8.57	Yes	Yes	0	6	7
21	A:A:E344	A:A:F340	97.8131	8.16	No	Yes	0	5	7
22	A:A:E344	A:A:L270	97.9377	2.65	No	Yes	0	5	6
23	A:A:F345	A:A:L270	49.1072	10.96	No	Yes	0	8	6
24	A:A:F273	A:A:F345	49.0209	5.36	No	No	0	9	8
25	A:A:F273	A:A:S349	98.0806	2.64	No	Yes	0	9	7
26	A:A:C359	A:A:S349	98.4974	6.89	No	Yes	0	5	7
27	A:A:C359	A:A:W277	100	2.61	No	Yes	0	5	6
28	A:A:V287	A:A:W277	99.9901	4.9	No	Yes	0	6	6
29	A:A:I244	A:A:V287	99.9883	3.07	Yes	No	0	8	6
30	A:A:I244	A:A:L44	91.4174	4.28	Yes	No	0	8	9
31	A:A:F238	A:A:L44	91.412	9.74	Yes	No	0	9	9
32	A:A:F238	B:B:W99	83.1312	12.03	Yes	Yes	0	9	9
33	A:A:C237	B:B:W99	27.6614	2.61	No	Yes	1	8	9
34	A:A:C237	B:B:Y59	27.6291	5.38	No	Yes	1	8	8
35	B:B:W332	B:B:Y59	56.8409	12.54	Yes	Yes	1	9	8
36	B:B:S316	B:B:W332	21.3822	4.94	No	Yes	0	9	9
37	B:B:C317	B:B:S316	21.2451	3.44	No	No	0	7	9
38	B:B:C317	B:B:M61	21.1109	6.48	No	No	0	7	6
39	B:B:G319	B:B:M61	10.489	3.49	No	No	0	5	6
40	B:B:G319	B:B:W63	10.3561	2.81	No	Yes	0	5	7
41	A:A:F290	A:A:T364	48.3801	3.89	Yes	Yes	2	9	9
42	A:A:N292	A:A:T364	48.8667	4.39	Yes	Yes	0	9	9
43	A:A:I348	A:A:L270	49.0212	5.71	No	Yes	0	4	6
44	A:A:F273	A:A:I348	49.0624	5.02	No	No	0	9	4
45	B:B:Q75	B:B:W99	55.3697	5.48	Yes	Yes	1	9	9
46	B:B:Q75	B:B:Y59	27.6354	9.02	Yes	Yes	1	9	8
47	B:B:K57	B:B:Q75	27.7263	4.07	Yes	Yes	1	9	9
48	B:B:K57	B:B:W332	27.612	11.6	Yes	Yes	1	9	9
49	B:B:A328	B:B:M61	10.489	3.22	No	No	0	5	6
50	B:B:A328	B:B:W63	10.3561	3.89	No	Yes	0	5	7
51	A:A:C379	A:A:F219	41.1629	4.19	No	Yes	0	8	8
52	A:A:C379	A:A:D378	58.7888	3.11	No	Yes	0	8	7
53	A:A:F219	A:A:H41	17.574	7.92	Yes	No	0	8	6
54	A:A:H41	A:A:T242	17.2988	4.11	No	No	0	6	8
55	A:A:C379	A:A:T242	17.4586	3.38	No	No	0	8	8
56	A:A:H41	R:R:L123	34.5399	3.86	No	Yes	0	6	6
57	A:A:F219	A:A:V217	19.1364	3.93	Yes	Yes	0	8	5
58	A:A:V217	R:R:L123	17.4906	4.47	Yes	Yes	5	5	6
59	A:A:W234	B:B:Y145	16.0606	2.89	Yes	Yes	1	9	8
60	A:A:W281	B:B:W332	32.0495	3.75	Yes	Yes	1	5	9
61	B:B:R314	B:B:W332	32.3257	26.99	Yes	Yes	1	8	9
62	A:A:W281	B:B:D290	31.7822	4.47	Yes	Yes	1	5	6
63	B:B:D290	B:B:R314	31.7822	10.72	Yes	Yes	1	6	8
64	A:A:I383	R:R:L123	50.5922	4.28	Yes	Yes	5	8	6
65	A:A:H387	A:A:I383	49.064	6.63	Yes	Yes	5	8	8
66	A:A:H387	R:R:A118	22.0498	2.93	Yes	No	0	8	8
67	A:A:H387	R:R:R129	26.6489	3.39	Yes	Yes	5	8	7
68	A:A:Q390	A:A:Y391	40.6986	11.27	No	Yes	0	4	4
69	A:A:Y391	R:R:A118	21.5345	9.34	Yes	No	0	4	8
70	A:A:Y391	R:R:R129	21.5434	5.14	Yes	Yes	5	4	7
71	A:A:Q390	R:R:N50	39.6558	6.6	No	No	0	4	7
72	A:A:E392	R:R:Q45	14.6107	6.37	No	No	0	6	5
73	R:R:N50	R:R:Q45	15.654	3.96	No	No	0	7	5
74	A:A:E392	R:R:L52	14.6124	2.65	No	No	0	6	8
75	R:R:L52	R:R:N50	22.9591	4.12	No	No	0	8	7
76	A:A:E392	R:R:N290	27.1357	11.83	No	No	0	6	8
77	B:B:C271	B:B:D290	63.3018	3.11	Yes	Yes	1	5	6
78	B:B:C271	B:B:Y289	51.1836	4.03	Yes	Yes	1	5	7
79	B:B:W297	B:B:Y289	38.244	3.86	Yes	Yes	1	8	7
80	B:B:A287	B:B:W297	31.6464	2.59	No	Yes	0	6	8
81	B:B:A287	B:B:I273	31.3709	3.25	No	No	0	6	6
82	B:B:G244	B:B:I273	24.7467	5.29	No	No	0	5	6
83	B:B:G244	B:B:T243	24.4703	3.64	No	Yes	0	5	8
84	B:B:F253	B:B:T243	16.4163	3.89	Yes	Yes	3	6	8
85	B:B:F222	B:B:F253	14.4832	4.29	Yes	Yes	3	8	6
86	B:B:G162	B:B:Y145	15.8747	10.14	No	Yes	1	9	8
87	B:B:N295	B:B:Y289	11.5768	4.65	Yes	Yes	1	6	7
88	B:B:C271	B:B:D291	11.575	7.78	Yes	No	1	5	8
89	B:B:V327	B:B:W339	10.8302	3.68	No	Yes	0	6	9
90	B:B:L286	B:B:V296	13.5387	2.98	No	No	0	7	5
91	B:B:L286	B:B:V327	12.9947	2.98	No	No	0	7	6
92	B:B:D291	B:B:N293	11.3001	9.42	No	No	1	8	5
93	B:B:G306	B:B:V296	20.5565	1.84	No	No	0	4	5
94	B:B:G306	B:B:V307	21.6319	1.84	No	No	0	4	3
95	R:R:I111	R:R:Y286	26.9731	3.63	No	Yes	0	9	9
96	R:R:D282	R:R:Y286	24.1261	9.2	Yes	Yes	6	9	9
97	R:R:D282	R:R:D63	10.8224	3.99	Yes	Yes	6	9	9
98	R:R:C279	R:R:D63	10.1229	4.67	No	Yes	0	9	9
99	R:R:A293	R:R:N290	25.0486	4.69	No	No	0	8	8
100	R:R:A293	R:R:C287	22.9614	1.81	No	No	0	8	8
101	R:R:A41	R:R:C287	16.6996	1.81	No	No	0	7	8
102	R:R:A41	R:R:D296	14.6123	4.63	No	No	0	7	4
103	B:B:G162	B:B:S161	15.821	3.71	No	Yes	1	9	9
104	B:B:N295	B:B:V307	11.146	5.91	Yes	No	1	6	3
105	B:B:N293	B:B:V307	11.0254	2.96	No	No	1	5	3

Download PSN data

2D representation of the global metapath, ligand(s) interactions and
histograms of path distribution according to several parameters
(click on the image to enlarge it 🔍):

A 2D representation of the global communication in the network.

ConSurf Conservation Grade (See documentation):

n/a 1 2 3 4 5 6 7 8 9

Number of shortest communication paths as a function of the average residue correlation.

Number of shortest communication paths as a function of the average interaction strength of their links.

Number of shortest communication paths as a function of the % of hub nodes in each path.

Number of shortest communication paths as a function of the number of nodes in each path.

Number of shortest communication paths as a function of the % of correlated nodes in each path.

there is no ligand in network 8Z3Q

PDB Summary
PDB	8Z3Q
Class	A
SubFamily	Orphan
Type	Orphan
SubType	GPR4
Species	Homo Sapiens
Ligand	-
Other Ligand(s)	-
Protein Partners	chim(NtGi1-Gs)/Beta1/Gamma2
PDB Resolution	2.76
Date	2025-04-23
D.O.I.	To be published

Net Summary
I_min	2.61
Number of Linked Nodes	832
Number of Links	968
Number of Hubs	154
Number of Links mediated by Hubs	550
Number of Communities	24
Number of Nodes involved in Communities	191
Number of Links involved in Communities	268

Path Summary
Number Of Nodes in MetaPath	106
Number Of Links MetaPath	105
Number of Shortest Paths	6065818
Length Of Smallest Path	3
Average Path Length	47.675
Length of Longest Path	72
Minimum Path Strength	1.225
Average Path Strength	5.73738
Maximum Path Strength	25.055
Minimum Path Correlation	0.7
Average Path Correlation	0.994931
Maximum Path Correlation	1
Minimum % Of Corr. Nodes	2.43902
Average % Of Corr. Nodes	30.8609
Maximum % Of Corr. Nodes	100
Minimum Path Hubs %	0
Average Path Hubs %	50.9996
Maximum Path Hubs %	100

Annotation	Type	Links
Gene Ontology	Molecular Function
Gene Ontology	Biological Process
Gene Ontology	Cellular Component
SCOP2	Domain Identifier	• Transducin (heterotrimeric G protein), gamma chain
SCOP2	Family Identifier	• Transducin (heterotrimeric G protein), gamma chain
Membrane Protein Annotations	-	• Orientations of Proteins in Membranes database (OPM) • Protein Data Bank of Transmembrane Proteins (PDBTM) • MemProtMD

Details about the values in these tables can be found in the corresponding documentation page .


PDBsum	Open PDBsum Page
Chain	A
Protein	G Protein α Sub unit
UniProt	P63092
Sequence	>8Z3Q_Chain_A E K A E K I E K Q L Q K D K Q V Y R A T H R L L L L G A S G K S T I V K Q M R I H V V T S G I F E T K F Q V D K V N F H M F D V G Q R D E R R K W I Q C F N D V T A I I F V V S S Y N R L Q E A L N F K S I W N N R W L R T I S V I L F L N K Q D L L A E K V L A G K S K I E D Y F P E F A R Y T T P E D A T P E P G E D P R V T R A K Y F I R D E F L R I S T A S G D G R H Y C Y P H F T C V D T E N R R F N D C R D I I Q R M H L R Q Y E L L T L S A D A V R S M D N Y K A D D D S A I Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

Chain	B
Protein	G Protein β Sub unit
UniProt	P62873
Sequence	>8Z3Q_Chain_B E L D Q L R Q E A E Q L K N Q I R D A R K A C A D A T L S Q I T N N I D P V G R I Q M R T R R T L R G H L A K I Y A M H W G T D S R L L V S A S Q D G K L I I W D S Y T T N K V H A I P L R S S W V M T C A Y A P S G N Y V A C G G L D N I C S I Y N L K T R E G N V R V S R E L A G H T G Y L S C C R F L D D N Q I V T S S G D T T C A L W D I E T G Q Q T T T F T G H T G D V M S L S L A P D T R L F V S G A C D A S A K L W D V R E G M C R Q T F T G H E S D I N A I C F F P N G N A F A T G S D D A T C R L F D L R A D Q E L M T Y S H D N I I C G I T S V S F S K S G R L L L A G Y D D F N C N V W D A L K A D R A G V L A G H D N R V S C L G V T D D G M A V A T G S W D S F L K I W N Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

Chain	G
Protein	G Protein γ Sub unit
UniProt	P59768
Sequence	>8Z3Q_Chain_G Q A R K L V E Q L K M E A N I D R I K V S K A A A D L M A Y C E A H A K E D P L L T P V P A S E N P F R Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

Chain	R
Protein	Receptor
UniProt	P46093
Sequence	>8Z3Q_Chain_R V D H L F P P S L Y I V I G V G L P T N C L A L W A A Y R Q V Q Q R N E L G Y L M L S I A D L Y I C T L P W V D Y F H H I H G P G S C K L F F I F Y T N I Y I S I A F L C C I V D R Y L A V A H P L R F R L R R V T V A V S S V V W A T E L G A N S A P L F E K F P M E G W V A W M N L Y R F V G F F P W A M L S Y R L R V R G S V S T E R Q E K A K I K L A L S L A I V L V C F A P Y H V L L S R S A I Y G E R V F S A Y H S S A F T S L N C V D P I Y L V N E G A R S D A K A L H N L F V N L L L G S A K A V L L L G I A R I L L L A L C V Click on each residue to open a popup with some information about it. ConSurf Conservation Grade (See documentation): n/a 1 2 3 4 5 6 7 8 9

This receptor, from the same or other species and bound to the same or other ligands, is also present in the following networks:
Show	PDB	Class	SubFamily	Type	SubType	Species	Orthosteric Ligand	Other Ligand(s)	Protein Partners	Resolution	Date	DOI
	9JCP	A	Orphan	Orphan	GPR4	Homo sapiens	-	LPC	chim(NtGi1-Gs-CtGq)/β1/γ2	2.55	2025-07-09	doi.org/10.1038/s41421-025-00807-y
	9JCP (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	LPC		2.55	2025-07-09	doi.org/10.1038/s41421-025-00807-y
	9JCO	A	Orphan	Orphan	GPR4	Homo sapiens	-	LPC	chim(NtGi1-Gs)/β1/γ2	2.36	2025-07-09	doi.org/10.1038/s41421-025-00807-y
	9JCO (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	LPC		2.36	2025-07-09	doi.org/10.1038/s41421-025-00807-y
	9JCQ	A	Orphan	Orphan	GPR4	Homo sapiens	-	LPC	chim(NtGi1-Gs)/β1/γ2	2.59	2025-07-09	doi.org/10.1038/s41421-025-00807-y
	9JCQ (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	LPC		2.59	2025-07-09	doi.org/10.1038/s41421-025-00807-y
	8ZD1	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	chim(NtGi1-Gs)/β1/γ2	2.6	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZD1 (No Gprot)	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-		2.6	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZF4	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	-	3.05	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZF6	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	chim(NtGi1-Gs)/β1/γ2	2.98	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZF6 (No Gprot)	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-		2.98	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZF7	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	-	3.15	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZF9	A	Orphan	Orphan	GPR4	Mus musculus	-	-	chim(NtGi1-Gs)/β1/γ2	2.56	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZF9 (No Gprot)	A	Orphan	Orphan	GPR4	Mus musculus	-	-		2.56	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFA	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	chim(NtGi1-Gs)/β1/γ2	2.96	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFA (No Gprot)	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-		2.96	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFB	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	-	3.78	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFC	A	Orphan	Orphan	GPR4	Mus musculus	-	-	chim(NtGi1-Gs)/β1/γ2	2.68	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFC (No Gprot)	A	Orphan	Orphan	GPR4	Mus musculus	-	-		2.68	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFD	A	Orphan	Orphan	GPR4	Mus musculus	-	-	-	2.56	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	8ZFE	A	Orphan	Orphan	GPR4	Mus musculus	-	-	-	2.56	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	9JVG	A	Orphan	Orphan	GPR4	Mus musculus	-	-	chim(NtGi1-Gs)/β1/γ2	2.76	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	9JVG (No Gprot)	A	Orphan	Orphan	GPR4	Mus musculus	-	-		2.76	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	9JVH	A	Orphan	Orphan	GPR4	Mus musculus	-	-	-	2.76	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	9JVM	A	Orphan	Orphan	GPR4	Xenopus tropicalis	-	-	-	2.36	2025-02-26	doi.org/10.1016/j.cell.2024.12.001
	9BIP	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gs/β1/γ2	2.8	2025-01-22	doi.org/10.1016/j.cell.2024.11.036
	9BIP (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.8	2025-01-22	doi.org/10.1016/j.cell.2024.11.036
	8ZCE	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gs/β1/γ2	3.1	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	8ZCE (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		3.1	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	8ZCF	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gs/β1/γ2	2.9	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	8ZCF (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.9	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFU	A	Orphan	Orphan	GPR4	Homo sapiens	NE52-QQ57	-	-	3.23	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFV	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(Gs-CtGq)/β1/γ2	2.67	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFV (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.67	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFW	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gs/β1/γ2	3.13	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFW (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		3.13	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFX	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(Gs-CtGq)/β1/γ2	2.87	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFX (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.87	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFZ	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(Gs-CtGq)/β1/γ2	2.9	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JFZ (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.9	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JHP	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(NtGi2-G13)/β1/γ2	3.35	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9JHP (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		3.35	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9LGM	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gs/β1/γ2	2.84	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	9LGM (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.84	2025-04-23	doi.org/10.1038/s41422-025-01092-w
	8ZFZ	A	Orphan	Orphan	GPR4	Danio rerio	-	-	chim(NtGi1-Gs)/β1/γ2	3.3	2025-01-22	doi.org/10.1038/s41467-025-55901-2
	8ZFZ (No Gprot)	A	Orphan	Orphan	GPR4	Danio rerio	-	-		3.3	2025-01-22	doi.org/10.1038/s41467-025-55901-2
	9J31	A	Orphan	Orphan	GPR4	Danio rerio	-	-	chim(NtGi1-Gs)/β1/γ2	3.05	2025-01-22	doi.org/10.1038/s41467-025-55901-2
	9J31 (No Gprot)	A	Orphan	Orphan	GPR4	Danio rerio	-	-		3.05	2025-01-22	doi.org/10.1038/s41467-025-55901-2
	8Z3M	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(NtGi1-Gs-CtGq)/β1/γ2	2.9	2025-04-23	To be published
	8Z3M (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.9	2025-04-23	To be published
	8Z3Q	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(NtGi1-Gs)/β1/γ2	2.76	2025-04-23	To be published
	8Z3Q (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.76	2025-04-23	To be published
	8Z65	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(NtGi1-Gs)/β1/γ2	2.98	2025-04-23	To be published
	8Z65 (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.98	2025-04-23	To be published
	8Z66	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	-	3.06	2025-04-23	To be published
	8Z67	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	-	3.2	2025-04-23	To be published
	9LMO	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	-	3.2	2025-07-09	To be published
	9LMP	A	Orphan	Orphan	GPR4	Homo sapiens	NE52-QQ57	-	-	2.65	2025-07-02	To be published
	8Z3Y	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(NtGi1-Gs)/β1/γ2	3.2	2025-06-04	To be published
	8Z3Y (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		3.2	2025-06-04	To be published
	8Z9P	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gi1/β1/γ2	2.5	2025-07-09	To be published
	8Z9P (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.5	2025-07-09	To be published
	9IV6	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	chim(NtGi1-Gs)/β1/γ2	2.71	2025-07-30	To be published
	9IV6 (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.71	2025-07-30	To be published
	8Z9O	A	Orphan	Orphan	GPR4	Homo sapiens	-	-	Gs/β1/γ2	2.4	2025-07-16	To be published
	8Z9O (No Gprot)	A	Orphan	Orphan	GPR4	Homo sapiens	-	-		2.4	2025-07-16	To be published

You can download a compressed (zip) file with structure(s), 3D outputs (as PyMol and VMD scripts) and numerical data files (as csv and plain text files).

Download 8Z3Q.zip

You can click to copy the link of this page to easily come back here later

or use this QR code to link and share this page.

You can also read or download a guide explaining the meaning of all files and numerical data.
